Tower Hobbies System 3000 Instruction Manual

®
Congratulations on your purchase - and thank you for choosing our Tower Hobbies
you'll enjoy many hours of trouble-free flying because this radio includes many features I knew you would want in a complete,
sensible flight system.
The 6FM offers six-channel control, enough for many sport and even competition planes. As an FM narrow-band system,
it's far less vulnerable to interference than AM radios. The narrow-band transmitter and dual-conversion receiver enhance
strong control by filtering and boosting the signal. Combined, they'll provide you with smooth, glitch-free control even in
today's "noisiest" radio environments.
Those are big pluses, but we went even further to make the 6FM the most complete radio we've ever offered. The case is
ergonomically designed for the best, most comfortable fit for your hands. Add to that one switchable auxiliary channel which
can be used for landing gear and an additional proportional channel - great for use with flaps! Adjustable sticks, complete
trainer system, dual-rates, reversing switches for all channels, a full set of NiCd batteries with charger and more, help round
out this superbly designed system.
Packed with easy-to-use features and complete with a 1-year limited warranty, the 6FM is a valuable investment.
Congratulations on your purchase and happy flying!
QUICK REFERENCE GUIDE
QUICK REFERENCE GUIDE
Note: This Quick Reference Guide is a condensed version of all
information given in this manual. It is strongly recommended
you read this entire manual before operating your 6FM system or
your model.
1. Charge the transmitter and receiver batteries for 15 hours with
the included charger.
2. Connect servos, 4-cell battery pack and switch harness as
shown at right.
3. Turn on transmitter, turn on receiver switch harness.
4. Center all four transmitter trim levers. Make sure all servos
operate according to transmitter stick movements.
5. Turn off the system, receiver first, then transmitter.
6. Wrap the receiver and receiver battery in foam rubber
(HCAQ1000 or HCAQ1050) for protection.
7. Install the entire radio system into the model as shown in the
model's instruction manual.
8. To reverse the direction in which a servo rotates (if necessary),
locate the reversing switch for that channel on the bottom
front of the transmitter and slide it to the "REV" position.
9. Range test the radio system prior to flight.
transmitter antenna collapsed, you should be able to
smoothly control movement of all control surfaces on your
model from at least 100ft on the ground.
• Entire contents © Copyright 2000 • The contents of this manual are subject to change without prior notice • Tower Hobbies is not responsible for the use of this product
6FM 6-CHANNEL FM RADIO CONTROL SYSTEM
INSTRUCTION MANUAL FOR R/C AIRCRAFT USE
With the
®
Sincerely,
Bruce R. Holecek
Founder and Chief Executive Officer,
Tower Hobbies
Dual-rate Switch
Channel 5
Trainer
Switch
Throttle,
Rudder
Stick
Transmitter TX)
Antenna
(ANT)
Receiver (RX)
Charge
Switch
Plug
Harness
(SW)
Battery
Plug
®
™
System 3000 6FM radio! I'm sure
™
Channel 6
Elevator/Aileron
Dual Rate
Adjustments
Elevator,
Aileron
Stick
Power Switch
Reversing Switches
Flaps
CH 6
Gear
CH 5
Rudder
CH 4
Throttle
CH 3
Elevator
CH 2
Aileron
CH 1
