- Page 1 SEA 1 Subwoofer Ethercon Adapter Operating Manual georg neumann gmbh · ollenhauerstr. 98 · 13403 berlin · germany tel +49 (0)30 / 41 77 24-0 · fax -50 · headoffice@neumann.com · www.neumann.com...
-
Page 2: Table Of Contents
About the SEA 1 ..............4 Package contents ..............4 Product overview ..............5 Using the SEA 1 ............... 6 Cleaning and maintaining the SEA 1 ......... 9 Specifications ................9 Pin assignment of the socket for NRC 1/2 remote control or RS-232 source ........10 Accessories ................ -
Page 3: Important Safety Instructions
• WARNING: To reduce the risk of fire and electric shock, do not expose the product to rain or moisture. • Do not expose the product to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the product. 2 | SEA 1... - Page 4 „Improper use“ means using the product: • other than as described in this operating manual, or • under operating conditions which differ from those described herein. This will invalidate the guarantee. SEA 1 | 3...
-
Page 5: The Sea 1 Subwoofer Ethercon Adapter
RS-232 data source. The subwoofer EtherCon adapter is a small black aluminum box with 4 Neutrik EtherCon® sockets. One SEA 1 can serve as a control data hub for up to 3 subwoofers. For larger systems, several SEA 1 can be used. -
Page 6: Product Overview
Product overview 1 SUBWOOFER 2 socket or next SEA 1 2 SUBWOOFER 3 socket 3 SUBWOOFER 1 socket 4 Socket for Neumann NRC 1/2 remote control or RS-232 source or previous SEA 1 SEA 1 | 5... -
Page 7: Using The Sea 1
Always lower the output level of the audio source before removing a Neumann NRC 1 remote control, either directly connected or via an SEA 1, or – with the NRC 1 remote control connected – before setting the switch VOLUME CONTROL of the subwoofer to “DISABLE”. - Page 8 NRC 1, either directly or via an SEA 1, into a network socket, the network device and the subwoofer can be damaged. Only connect the subwoofer(s) and the SEA 1 to Neumann remote controls or devices that deliver a RS-232 signal using a high-quality Neumann RC CAT5 cable (see below).
- Page 9 It is possible to control more than 9 subwoofers using addi- tional SEA 1. However, the subwoofers connected to later SEA 1 in the chain may suffer from a noticeable latency in volume level changes. It is therefore not recommended to daisy chain more than 9 subwoofers.
-
Page 10: Cleaning And Maintaining The Sea 1
Liquids entering the product can cause a short-circuit in the electronics and damage or even destroy it. Keep all liquids away from the product. Before cleaning, disconnect the SEA 1 from the subwoofer. Use a soft, dry, and lint-free cloth to clean the product. Specifications... -
Page 11: Pin Assignment Of The Socket For Nrc 1/2 Remote Control Or Rs-232 Source
Remote control cable, 10 m (30') RC 15 Remote control cable, 15 m (45') RC 20 Remote control cable, 20 m (60') RC 25 Remote control cable, 25 m (75') RC 30 Remote control cable, 30 m (90') 10 | SEA 1... -
Page 12: Manufacturer Declarations
Declaration of Conformity • Low Voltage Directive (2006/95/EC) • EMC Directive (2004/108/EC) The declaration is available on the product page at www.neumann.com. SEA 1 | 11... - Page 13 05/12 · 549109/a01 printed in germany...
