Caidrox HD-2000 User Manual

Black box for vehicle (driving recorder)
Hide thumbs
Table of Contents

Advertisement

Quick Links

* Before you start...
Thank you for choosing Caidrox (HD-2000/HD-2100)!
In order to use this product more conveniently, please read the information
contained in this user's guide carefully.
Please read the installation instructions and operating guidelines as well as cautions
contained in this user's guide carefully.
●
(HD-2000/HD-2100) is the brand of CHA Bio & Diostech Co.,
Ltd.(hereinafter to be called Product).
● All rights of the design and S/W of
to CHA Bio & Diostech Co., Ltd and are protected by Copyrights.
● The changes in
can be done without prior notice to the users.
● This user's guide was made based on the present time and there could be
technical and editorial errors or omissions.
● This user's guide can be amended without prior notice to the users.
Contents
10. Instructions for use of program
Black Box for Vehicle (Driving recorder)
(HD-2000/HD-2100) to improve its performance
(HD-2000/HD-2100) belong
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Caidrox HD-2000

Summary of Contents for Caidrox HD-2000

  • Page 1: Table Of Contents

    Please read the installation instructions and operating guidelines as well as cautions contained in this user’s guide carefully. ● (HD-2000/HD-2100) is the brand of CHA Bio & Diostech Co., Ltd.(hereinafter to be called Product). ● All rights of the design and S/W of (HD-2000/HD-2100) belong to CHA Bio &...

  • Page 2: Components

    11. Product Specifications 12. Upgrading firmware 13. Product specifications 14. Before you inquire for A/S 15. Maintenance service 16. Warranty (1) Components Power Cable Fix Clip (8EA) Adhesive Tape Mount User guide Manual Set screw (2EA) SD Memory Card (2) Names and function of components...

  • Page 3: Cautions In Installation

    (lens angle) is aligned. LED Indicator Blinks when the power is connected or image recording is proceeding. GPS LED Blinks when GPS (HD-2000) is connected or electric power (HD-2100) is connected. Microphone For input of audio information. SD Memory Used when SD Memory Card is inserted or removed.

  • Page 4: Cautions In Using The Product

    7. Do not use under a voltage other than the rated voltage, which can cause the damage of the Product or a fire. Caidrox (HD-2000/HD-2100) uses the voltage of DV 12V~DV 24V. 8. Do not leave the Product in a place under high temperature or low temperature for a long time.

  • Page 5: Cautions In Using Sd Memory Card

    (5) Cautions in using SD memory card 1. Note that only SD Memory Card specialized for Caidrox (HD-2000/HD-2100) can be used. Therefore, contact our Customer Support Center if it is lost or damaged. 2. Do not remove the SD Memory Card when using the Product, which can cause an operational problem and the malfunction of SD Memory Card or the Product.

  • Page 6: Cautions About Gps

    where you purchased it or our Customer Support Center to exchange with another SD Memory Card. In case that you purchase a new SD Memory Card after the warranty period is terminated, you are highly recommended to choose our SD Memory Card which is of the best quality as we guarantee.

  • Page 7: Installation Instructions

    congested area because of reception hindrance 5. In some vehicles with special glass coating or sun-proof coating on the windows, GPS receiver may not function in a normal condition due to unstable reception. And also the electromagnetic wave emanating from the various vehicle instruments may cause such problems.

  • Page 8: Instructions For Use

    1. Combine the Mount with the Main Body. 2. Fix firmly the Main Body and the Mount using Setscrews. 3. Adjust the installation angle to align the Main Body vertically. 4. When the angle is properly adjusted, tighten the Setscrew using a coin. 5.
  • Page 9 10 seconds (min.) to 30 seconds (max.). 6. Blue LED will flash on after receipt of GPS (a few seconds ~a few minutes). ※ applied only to the products with GPS built in (HD-2000). 7. All the features of the Product operate normally.
  • Page 10 - Operating LED and BUZZER in each stage of the Product Stage HD-2000 HD-2100 (GPS included) (GPS not included) LED status LED status BLUE BLUE Product On/off On/off On/off On/off Initialization repeating repeating repeating repeating (power supply) Initialization times 5 times in 0.5 completed 0.5 seconds...

  • Page 11: Installation Guide For Program

    5. Caidrox is being installed 6. When installation is completed, click the "Close" button. 7. Click the icon on your desktop or click Caidrox in the program to run the program. (10) Playing the image and the name and functions...
  • Page 12 Name Description of functions Main menu Supporting such functions as Outcall, Capture, and Setting.. Image window Window showing the image display Image control console Control console for displayed image Volume control Volume modulation G-sensor graph. Displaying the change value of G-sensor RECORD Displaying a list of files and event information.
  • Page 13 Configuration Set the configuration for Very Fast Wind fast the using the Product Forward displayed image at 10 seconds interval. Play Play a image Zoom in Zoom map screen Stop Stop the image display Zoom out Zoom our the map screen Pause Pause the image display - Playing the image using play program.
  • Page 14 * File will be saved in the Always Movie folder on a regular mode, in the Event Mode folder on a event mode. 3. Once a file is called out, the file index (save mode, time information, file names) will align on the top of the right hand side. 4.
  • Page 15 5. The graph at the bottom left display the sensitivity of the impact before/after the event, vertically and horizontally. 6. On the event list at the bottom right, the location information at the time of the event is stored. And it moves to the location where the event occurred when double-click the event file.
  • Page 16 7. Click the Information Tab On the top of the right hand side, and the play file information and GPS-related information will be displayed. On the upper right corner of the screen, the information about the file currently being played will be displayed, and on the bottom right of the screen, a map showing the location of vehicle in the GPS-related information is displayed at the same time.
  • Page 17 3. Press " Save" after input of the storage location and file name, and the image is saved. 1. A desired image can be printed while playing the image or at pause. 2. Click the “Print Image” on the programs menu. 3.
  • Page 18 1. Run the play program after connecting the SD Memory Card to PC. 2. Click “ Configuration” in the program menu on the top of play program, and the configuration window as below will be displayed. Function Description Storing Mode ●...
  • Page 19 √ `Buzzer will operate when an event occurs. - Upgrading firmware Upgrading the firmware of HD-2000/HD-2100 and changing the setting value of equipments are all done through the SD Memory Card. Firmware can be downloaded in Caidrox homepage: http://www.caidrox.com...
  • Page 20 640*480(VGA) upto 30fps Sensor Built-in 3D shock sensor against concussion, sudden break/step up Data Storage SD/SDHC memory card(2GB by default,16GB in max supportable) Audio Built-in Mic. Built-in GPS(only for the model supporting GPS [HD-2000]) Rated Voltage DC12V~DC24V Operation DC8V~DC38V Voltage Current...
  • Page 21 ● CHABio & Diostech Co., Ltd.'s Customer Support Center or partner companies will provide services when they received requests from the customers. ● If you have any questions in using the Product, contact our Customer Support Center, or use maintenance Q&A in the Caidrox home page.
  • Page 22 ● Make sure the following before you apply for maintenance service. Sometimes, the data in the Product should be deleted depending on the maintenance situation. Therefore, back up the important data before you apply for the maintenance service. Note that we are not responsible for the data damaged or deleted.
  • Page 23 Free service Types of damage Contents of Compensation Within the warranty After the period warranty period When major problem occurs within Product exchange 10days after purchase refund When the problem on the performance and Free repair functionality occurs in a normal status within 1 month after purchase.
