Summary of Contents for SecurityMan SM-401
- Page 1 Converts Wired Camera to Wireless (900 MHz) Model: SM-401...
- Page 3 (normally 1 year) Copyright 2009 by SecurityMan v2.0...
- Page 4 1 feet away from any heart pacemaker. Radio waves might potentially influence heart pacemaker and lead to respiratory disturbance. DO NOT use this product for any illegal activities. SecurityMan shall not be responsible for any consequences of illegal conducts made by users.
- Page 5 Conditions Please read the following messages to make sure whether your working environment is suitable. • Ensure there is enough space around the receiver for ventilation. • The temperature should be kept between –10˚C and 50˚C (14˚F to 122˚F). The relative humidity should remain from 20% to 80%. •...
-
Page 6: Table Of Contents
Table of Contents Introduction Features Package Contents Hardware Basics SM-401T (Transmitter) SM-7034 (Receiver) Installaion Diagram Installation Procedure Product Specifications... -
Page 7: Introduction
Introduction Thank you for purchasing the wireless converter. The wireless converter is a convenient wireless security camera kit for indoor surveillance used to converts any wired cameras to wireless (900MHz). A perfect solution for existing wired cameras ideally for homes and businesses. It consists of a wireless transmitter, a wireless receiver, and all the necessary accessories to put it to work. -
Page 8: Hardware Basics
Hardware Basics SM-401T (Transmitter for the wired camera) Antenna BNC Socket (To Camera) Channel Switches Microphone Power Jacks Front BNC socket: Connect to a wired camera output. Back Antenna: Sends the wireless signal to the receiver. Microphone: Captures audible sound up to 25ft away. Power jacks (x2): Use the existing wired camera’s power adapter to one of the two jacks and then use the mini power cable to connect from the second jack to the camera’s power input socket. -
Page 9: Sm-7034 Receiver
Channel switches: supports up to 2 channels frequency. The manufacture default channel setting is channel number 1. Key notes for channel switches are as follow: - Avoid using the same channel frequency setting in a location. - If channel 1 is not clear or unstable, change to channel 2 or vice versa. -Transmission quality may varies from one location to the next. -
Page 10: Installation Diagram
Receiver manual & loop Switch A) In manual mode use the Channel Switch button located in the front of the receiver to toggle between channel#1 & channel#2 B) In loop mode the receiver will auto dwell by switching between channel#1 &... -
Page 11: Installation Procedure
Installation Procedures 1. Connect the SM-401T transmitter to a wired camera using the BNC connection. 2. Connect the mini power cable from the power socket of SM-401T transmitter to the wired camera power input socket as shown below. 3. Plug the power adapter of the wired camera to the power outlet and connect the power jack to the power socket of the transmitter (SM-401T). - Page 12 4. Connect the power adapter to the power outlet and the power jack to the receiver power input, the receiver will automatically turn on. 5. Connect the receiver to a monitor, TV, LCD, DVR (digital video recorder), or VCR using the AV cable. (Yellow for video; red for audio). 6.
-
Page 13: Product Specifications
Product Specifications SM-401T (Transmitter) FM, CH1=906MHz, CH2=924MHz Transmission Frequency (channel selectable dip switches) Video Input Audio Microphone Built-in Bandwidth 18 MHz Transmission Power 2 mW Power Consumption 100 mA (Max.) 12VDC Max. Power Input (NOT compliant with 24VDC power input) Dimensions (W x D x H) 1.38”...
