Site Preparation,
Installation and Operator's Manual
for
48 Vdc Extended Battery Cabinet (XBU48)
for use with
Series 1
1500–2000 VA
Uninterruptible Power Systems
www.powerware.com/avaya

Advertisement

Table of Contents
loading

Summary of Contents for Avaya XBU48

  • Page 1 Site Preparation, Installation and Operator’s Manual 48 Vdc Extended Battery Cabinet (XBU48) for use with Series 1 1500–2000 VA Uninterruptible Power Systems www.powerware.com/avaya...
  • Page 2 Avaya and the Avaya logo are trademarks of Avaya Inc. and may be registered in certain jurisdictions. ECopyright 2001–2006 Avaya Inc. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Avaya Inc.
  • Page 3: Table Of Contents

    ..............Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 4 TABLE OF CONTENTS Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 5: Introduction

    (1500–2000 VA) UPS that extends the battery-backup runtimes for the UPS. The XBU48 is a 48 Vdc model with a charger. Up to three XBU48s can be attached to customize the battery runtime for your application. UPS Model and Battery Configurations...
  • Page 6: Xbu48 Battery Times

    1500 1400 1200 1000 Hours) 10.0 10.5 11.0 11.5 12.0 * Based on load power factor of 0.70. NOTE Do not connect more than three XBU48s to the UPS. Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 7: Installation

    UPS and batteries. DO NOT use any other sizes or types of batteries with the XBU48. Read all of the caution and warning statements in “Safety Warnings” of your Avaya UPS operator’s manual before performing the installation.
  • Page 8 Contact with any part of a grounded battery can result in electrical shock. The likelihood of such shock will be reduced if such grounds are removed during installation and maintenance. Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 9: Installing The Xbu48

    NOTE It is recommended to allow a minimum of 4.5” of space from the rear of the cabinet for proper ventilation. If you are using only one XBU48 and want increased stability or a seismic installation, remove the mounting plates from the pallet (see Figure 1).
  • Page 10 INSTALLATION A seismic installation of the XBU48 requires that the mounting plates be bolted to the floor. See Figure 2 for a detailed drill and mounting pattern. NOTE For Zone 4, it is recommended to use 5/16” self-drill bolts and hardware with 1 5/16”...
  • Page 11 INSTALLATION Align the U-shaped mounting bracket with the two holes closest to the front of the XBU48 and secure using two of the countersink screws from the start-up kit. Align the L-shaped mounting bracket with the two holes closest to the rear of the XBU48 and secure using two of the countersink screws from the start-up kit.
  • Page 12 10. Verify that the circuit breaker on all XBU48s is in the OFF (O) position (see Figure 4). 11. Plug the XBU48 battery output cord into the battery connector on the UPS rear panel. All battery connectors are polarized to prevent incorrect connection.
  • Page 13 Battery Connector Charger AC Input Receptacle Battery Circuit Breaker Charger Breaker Tie Charger Air Exhaust Battery Output Cord Charger LED Power Switch Unit Rating Label Figure 4. XBU48 Rear View Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 14: Important Safeguards

    15. Verify that the charger LED on the XBU48 rear panel is illuminated, indicating the charger is on. If the charger LED is not on, turn the power switch on the XBU48 rear panel to the ON position. 16. Remove the breaker tie from the circuit breaker on all XBU48s.
  • Page 15: Alarm Contacts

    Alarm Contacts A set of normally open alarm contacts is provided on the rear panel of the XBU48. The contacts will close if there is an overload or overtemperature condition. Optional: To use the alarm contacts, connect alarm leads to the two contacts on the alarm contact strip.
  • Page 16: Specifications

    UL 1778, CAN/CSA C22.2, No. 107.1-M91, EN 50091-1-1 and IEC 60950 Agency Markings UL, cUL EMC (Class A) FCC Part 15, EN 50091-2, ICES-003 Table 2. Part Number XBU48 Model Avaya Comcode 48 Vdc 700404486 Avaya XBU48 Site Preparation, Installation and Operator’s Manual 700071244 Issue 3...
  • Page 17: Troubleshooting

    Avaya service representative. there is an overload condition. The battery may be fully Plug the UPS and XBU48 into a power outlet for 24 hours discharged. to charge the battery. After charging the battery, press Battery Service and hold the button for 3 seconds;...
  • Page 18: Obtaining Service

    The troubleshooting chart covers most of the difficulties you may encounter during normal operations. If you have any questions or problems with your UPS, call your Avaya service representative or the appropriate telephone number on the service label of your UPS.
