Summary of Contents for Alert-it Care Systems P135
- Page 1 Alert-it Care Systems P135 Personal Alarm Alarm Badge User Handbook Models covered by this handbook P135AB Long range personal monitor badge P135AA Short range personal monitor badge One of a range of Alert-it Care Alarms available from...
- Page 2 A card of 5 batteries is available from iTs Designs Ltd (order code P160) To prevent the fall alarm activating in the post, the P135 is shipped in a de- activated state. The HELP button must be pressed until a beep is heard to activate the unit for the first time.
- Page 3 It can also use It will warn of radio failure when the the regular Safelink Securelink protocol is enabled by a red transmission to warn of light and audible alert wandering or radio failure UH1101A P135 User Handbook page 3 of 8...
-
Page 4: Fall Detection
2 minutes as a further level of protection. The detection value can be adjusted manually on the pager if false alarms occur. For information about pager programming see the P137 Programming Handbook. UH1101A P135 User Handbook page 4 of 8... -
Page 5: Range Test
HELP button (less than 1sec) will cause the P135 to transmit, without setting an alarm In large installations a more convenient method is to have one P135 with the fail- safe capability enabled (see below). This is then positioned where the pager would normally be situated and the pager taken around the whole area to be monitored. - Page 6 Panic Button (less than 1 second so that no beep sounds). If the battery is serviceable than the light will flash. The P135 will also transmit at this time. In Securelink mode the battery status is being monitored continually.
- Page 7 Intermittent tune, + alarm 8 sec Battery Flash every Fault 31 Intermittent tune, + alarm Fail 8 sec Battery The P135 chirps every 0.5 sec with no LED and no transmission Dead UH1101A P135 User Handbook page 7 of 8...
-
Page 8: Battery Replacement
To change the link, open the case and remove the battery as described on page and fit the link as shown below to enable Securelink. To remove Securelink simply Link enables“Securelink” operation. If not required then remove for maximum battery life Programming and enabling failsafe operation UH1101A P135 User Handbook page 8 of 8... -
Page 9: Configuration Changes
Close the case and enable the battery by pressing nthe HELP button until a beep is heard Configuration Changes The P135 uses the standard Alert-iT Programming Data Protocol and all the main features can be changed using the P152 USB Interface and Data Editor Programme. - Page 10 Battery Type: 3v Lithium Coin Cell CR2025 or equivalent (order code P160 for 5 batteries) Reassemble the case. The P135 must now be activated by pressing the red button for 1 second until a beep is heard UH1101A P135 User Handbook page 10 of 8...
- Page 11 10. The fall detection requires the user to lie in a semi prone position. Some falls may not achieve this and hence if the user is at high risk in a fall, there should be frequent obser- vations made on their well being UH1101A P135 User Handbook page 11 of 8...
- Page 12 UV1198 Support Designed by: For technical support please fax or EMail: ITs Designs Ltd HELP: 0845 2179951 Leicester FAX : 0845 2179953 LE9 9FE UK Support@itsdesigns.co.uk ...using technology to care for carers UH1101A P135 User Handbook page 12 of 8...
