POWER ON BOARD Power Series Owner's Manual And Warranty Information

2000000 corded/cordless/rechargeable

Advertisement

VEC184POB Manual 7/15
2,000,000
CORDED • CORDLESS • RECHARGEABLE
IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR
PURCHASE CALL TOLL FREE (866) 584-5504. IN MOST
CASES A SERVICE REPRESENTATIVE CAN RESOLVE
YOUR PROBLEM OVER THE PHONE.
KEY INFORMATION YOU SHOULD KNOW:
• REPLACEABLE 12V BATTERY
• PORTABLE, CORDLESS, RECHARGEABLE
• ULTRA BRIGHT AREA LIGHT
• HIGH INTENSITY QUARTZ BEAM
• BUILT-IN UTILITY WORK STAND
BEFORE RETURNING THIS PRODUCT FOR ANY REASON,
PLEASE CALL TOLL FREE (866) 584-5504
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ
CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.
4140 S.W. 28th Way, Ft. Lauderdale, FL 33312
7/16/04
10:04 AM
Page 1
POWER SERIES
SPOTLIGHT
OWNER'S MANUAL AND
WARRANTY INFORMATION
Toll Free: (866) 584-5504
VEC184POB
TM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POWER ON BOARD Power Series

  • Page 1 VEC184POB Manual 7/15 7/16/04 10:04 AM Page 1 VEC184POB POWER SERIES 2,000,000 SPOTLIGHT CORDED • CORDLESS • RECHARGEABLE IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR PURCHASE CALL TOLL FREE (866) 584-5504. IN MOST CASES A SERVICE REPRESENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE.
  • Page 2: Important Safety Instructions

    1. INTRODUCTION Congratulations on purchasing the Vector 2,000,000 Power Series Spotlight, an advanced design combination spotlight and area light. It instantly converts use from a powerful spotlight to a soft, long-lasting area light. It uses a powerful, proven-technol- ogy, rechargeable, non-spillable, sealed, lead-acid battery that allows for years of dependable use, recharge after recharge.
  • Page 3: Location Diagram

    VEC184POB Manual 7/15 7/16/04 10:04 AM Page 3 Two recharge adapters are supplied with the spotlight. It is rechargeable from either a 12 volt DC accessory outlet, or from any 120 volt 60 Hz AC outlet. This permits recharge flexibility for use around home, business or in the field. 12 volt DC power is available from most vehicles, boats, jump starters and portable battery packs.
  • Page 4: Charging Indicators

    VEC184POB Manual 7/15 7/16/04 10:04 AM Page 4 5.1 AC RECHARGE During Recharge: a) Never turn on while charging. b) Make sure the AC power source is 120 volts, 60 Hz. c) After recharge – disconnect cord and wait 5 minutes before use. 5.2 CHARGING INDICATORS Unit includes charging indicator LED’s that display battery level of charge any time during operation or storage by simply turning ON the area light.
  • Page 5: Periodic Maintenance

    VEC184POB Manual 7/15 7/16/04 10:04 AM Page 5 WARNING: Use the supplied DC recharge adapter, do not substitute. DC recharge requires the use of the supplied DC recharge adapter. 1. Connect the DC recharge adapter’s DC plug to a 12 volt DC source. 2.
  • Page 6: Replacing The Battery Pack

    VEC184POB Manual 7/15 7/16/04 10:04 AM Page 6 FIGURE 5 - BULB ASSEMBLY BULB METAL PRONGS PHILLIPS HEAD SCREW METAL PRONGS PHILLIPS HEAD SCREW REFLECTOR Bulb life can be shortened by installing a bulb with dirt or fingerprints on it. During installation, avoid touching the glass part of the bulb (see Figure 4 and 5 for details).
  • Page 7: Safe Battery Disposal

    VEC184POB Manual 7/15 7/16/04 10:04 AM Page 7 Note polarity of battery. Note which color wire is on which terminal. 5. Disconnect the wires from the battery and set the battery aside. 6. Connect the replacement battery, making sure the correct color wires are on the new battery terminals.
  • Page 8 WARRANTY ACTIVATION: Please complete Warranty Activation Card and mail to Vector Manufacturing. Enter “VEC184POB” as Model and “2,000,000 Power Series” as Product Type. All Vector Manufacturing, Ltd. products must be registered within 30 days of pur- chase to activate this warranty.
