Summary of Contents for ERA Products Locca Connecta
- Page 1 The Wireless Intercom User & Installation Guide...
- Page 2 What’s in the box? CONNECTA SPEECH PANEL CONNECTA HANDSET HANDSET CHARGING DOCK TRANSFORMER PLUG FOR SPEECH PANEL SCREWDRIVER BIT SECURITY RAWLPLUGS TRANSFORMER PLUG FOR AAA BATTERIES HANDSET CHARGING DOCK The Wireless Intercom User & Installation Guide USER INSTALLATION GUIDE Open Button Features Speaker Call Button...
- Page 3 Fig. 6 Fig. 1 Fig. 7 Fig. 2 Fig. 8 Fig. 3 Fig. 4 Fig. 9 Fig. 5 Fig. 10...
- Page 4 & 4 to 60 seconds. Attach the mounting plate to the wall using To enter further handsets, please repeat the screws and rawl plugs provided. above process with each handset (up to a total of six). Re-attach the speech panel to the OTHER FEaTuREs mounting plate: Turn on/off backlight on speech panel Securely attach the speech panel back to the Hold down the ‘call’ button on the speech mounting plate with the security screw, using the panel until the button/nameplate flashes. special driver piece. Replace the name plate and nameplate Press the ‘call’ button for a further five cover. seconds until the speech panel beeps. The ERa locca Connecta is now installed. The speech panel backlight will turn on/off.
-
Page 5: Technical Information
deleting handsets from speech panel ImPORTanT Turn off power to speech panel. The user should not attempt to service the unit or Hold down call button. open the main casing. Turn on power to speech panel. TECHnICal InFORmaTIOn Release call button. Handset: All handsets will now be deleted. • Operating range up to 200 metres line of Paging other phones sight in open area Press talk on the handset. • Ambient temperature range: 0° to 40° All other handsets will ring (different tone). • Environment humidity: 80% RH • Adaptor Supply: 6Vdc 200mA PROGRammInG HandsETs TO wORK • First charging time for rechargeable wITH an ERa lOCCa aCCEss OR mulTI batteries: 12 hours To programme handsets into the • Use Locca adaptor with band Ktec and... - Page 6 ERA Products Ltd, Straight Road, Short Heath, Willenhall, West Midlands WV12 5RA Tel: 01922 490000 www.era-security.com E-mail: info@era-security.com...
Need help?
Do you have a question about the Locca Connecta and is the answer not in the manual?
Questions and answers
Cannot hear the person outside but they can hear me?
Possible reasons for not hearing the person outside with ERA Products Connecta could include:
1. The power to the speech panel is off.
2. The handset is not properly programmed or logged into the system.
3. The handset is out of range (over 200 metres or with obstructions).
4. The rechargeable batteries in the handset are not charged or installed correctly.
5. The speech panel or handset speaker/microphone is malfunctioning.
6. The system is not properly wired or installed.
This answer is automatically generated
