INSTRUCTION MANUAL
BTY-2-FM
Professional FM Broadband Antenna
Stock No. 4878
Description
The BTY-2-FM is a professional quality FM omnidirectional broadband (88 MHz - 108 MHz) antenna, for use in
CATV and MATV installations. The antenna is a twin dipole design with 75 Ohm output and can be mounted
vertically or horizontally to a mast or tower (up to 2 1/2" diameter).
Square, heavy duty aluminum boom design for positive lock with mast and element mounting clamp. Elements
are thick wall aluminum with sealed ends for maximum vibration damping. Patented off-center driven elements
provide excellent 75 Ohm match without use of fragile capacitors as required in gamma match antennas. All
components and hardware required for complete assembly and mounting are supplied. Unit carton is UPS
shippable.
All mounting hardware is stainless steel.
Features
•
Universal bracket for easy mounting (horizontal or vertical).
•
Comes with all components required for a complete installation.
•
Heavy duty construction.
•
Hard drawn heavy wall aluminum boom.
•
All stainless steel hardware.
•
Thick aluminum wall elements with sealed ends provide maximum vibration damping.
•
Mast mounting bracket has serrated teeth for better grip on mast (up to 2 1/2" O.D.)
•
Patented off-center driven elements provide excellent 75 OHM match without use of fragile capacitors as
required in gamma match antennas.
•
Easy to assemble and mount with minimum amount of tools.
•
Square boom design assures positive lock with mast mounting bracket and element mounting clamp.
©2007 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
(800) 523-6049 • (732) 679-4000 • FAX: (732) 679-4353
One Jake Brown Road
Old Bridge, NJ 08857-1000 USA
www.blondertongue.com
651144300D
Advertisement
Table of Contents
Summary of Contents for Blonder tongue BTY-2-FM
- Page 1 Easy to assemble and mount with minimum amount of tools. • Square boom design assures positive lock with mast mounting bracket and element mounting clamp. 651144300D ©2007 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
-
Page 2: Installation Instructions
BTY-2-FM Instruction Manual Specifications (Typical) Mechanical Electrical Size Gain Boom Length: 18" Over Isotropic: 2.2 dB Bandwidth: 88-108 MHz No. of Elements: 2 (Driven) Length of Longest Element: 59" VSWR (Return Loss): 12 dB (1.62-1) Accessories Supplied (In Plastic Bag) - Page 3 BTY-2-FM Instruction Manual Boom Endcaps Element Clamp Element Endcaps Element Connector Bracket Lower Element Reinforcement Bracket Mounting Clamp Wrap Cable As Shown Upper Element...
-
Page 4: Limited Warranty
Limited Warranty Blonder Tongue Laboratories, Inc. (BT) will at its sole option, either repair or replace (with a new or factory reconditioned product, as BT may determine) any product manufactured by BT which proves to be defective in materials or workmanship or fails to meet the specifications which are in effect on the date of shipment or such other specifications as may have been expressly agreed upon in writing (i) for a period of one (1)
