Owner's Manual
Indoor Lighting Fixture
Installation Instructions
Please write model number here for future reference: / Veuillez noter le numéro de mod-
èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para
futura referencia:
W-101
062204

Advertisement

loading
Need help?

Need help?

Do you have a question about the Indoor Lighting Fixture and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse Indoor Lighting Fixture

Summary of Contents for Westinghouse Indoor Lighting Fixture

  • Page 1 Owner’s Manual Indoor Lighting Fixture Installation Instructions W-101 062204 Please write model number here for future reference: / Veuillez noter le numéro de mod- èle aux fins de référence ultérieure: / Por favor, incluya el número del modelo aquí para...

  • Page 2: Warranty Information

    If this fixture fails for any reason covered by this warranty, simply return the fixture with a copy of the original sales receipt, freight prepaid and Westinghouse Lighting, at its option, shall repair or replace the fixture or refund the purchase price.
  • Page 3 FIGURE 1. GROUND *OUTLET WIRE BOX (B) WIRE CONNECTORS (O) SIDE HOLE (Q) MOUNTING *OUTLET BOX BAR (A) SCREWS (C) LOCK WASHER (F) HEX NUT (D) GREEN NIPPLE 1 (G1) GROUNDING SCREW SCREW (P) COLLAR (M) CANOPY (N) SCREW COLLAR RING (L) CHAIN (K) FIXTURE LOOP (I)
  • Page 4 MOUNTING AND WIRING INSTRUCTIONS NOTE: Underwriters Laboratories (UL) does not require all fixtures to have ground wires. These fixtures meet all UL specifications. 1. Turn off power at circuit box to avoid possible electric shock. 2. Secure mounting bar (A) to outlet box (B) with outlet box screws (C) (not included) (see fig. 1). 3.
  • Page 5 (voir fig. 1). GARANTIE LIMITÉE DE CINQ ANS Cet appareil d'éclairage Westinghouse est assorti d’une garantie de 5 ans contre les défauts de matériaux et de fabrication, qui entre en vigueur à partir de la date d'achat. La présente garantie se substitue à...
  • Page 6 FIGURE 1. FIL DE MISE *BOITE DE SORTIE A LA TERRE DE COURANT (B) CONNECTEURS DE FIL (O) TROU LATERAL (Q) *VIS DE LA BOITE DE BARRE DE SORTIE DE COURANT (C) FIXATION (A) RONDELLE DE BLOCAGE (F) L’ECROU VIS DE MISE HEXAGONAL (D) A LA TERRE MANCHON...
  • Page 7 INSTRUCTIONS DE MONTAGE ET DE RACCORDEMENT NOTA : Underwriters Laboratories (UL) n’exige pas que tous les appareils d’éclairage comportent des fils de mise à la terre. Ces appareils satisfont cependant à toutes les spécifications UL. 1. Mettez l’interrupteur de la boîte de fusibles à « OFF » afin d’éviter le risque d’électrocution. 2.
  • Page 8 Si este artefacto sufre un desperfecto causado por cualquiera de las razones cubiertas por esta garantía, simplemente envíe el artefacto con una copia del comprobante original de compra, fran- queo prepago, y Westinghouse Lighting, a su criterio, reparará o reemplazará el artefacto o le rein- tegrará el precio de compra.
  • Page 9 FIGURA 1. CABLE DE *CAJA DE TIERRA EMBUTIR (B) CONECTORES DE ROSCA (O) ORIFICIO LATERAL (Q) *TORNILLOS CAJA BARRA DE DE EMBUTIR (C) MONTAJE (A) ARANDELA DE PRESION (F) TUERCA TORNILLO HEXAGONAL (D) VERDE DE TIERRA (P) NIPLE 1 (G1) COLLAR ROSCADO (M) DOSEL (N)
  • Page 10 INSTRUCCIONES DE MONTAJE Y CABLEADO NOTA: Underwriters Laboratories (U.L.) no requiere que todos los artefactos tengan cables de tierra. Estos artefactos cumplen con todas las especificaciones U.L. 1. Desconecte el suministro eléctrico en la caja de fusibles para evitar la posibilidad de descarga eléctrica.
  • Page 11 FIGURE 2. WARNING CONNECT TO BLACK CONNECT TO WHITE GROUP A: GROUP B: HOUSE WIRE HOUSE WIRE Turn off electricity to the BLACK WHITE mounting site before beginning installation. WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER Mounting instructions must be followed exactly BROWN, GOLD OR BLACK BROWN, GOLD OR BLACK WITH TRACER...
