w w w.JensenRVDirect.com
TooLs & suppLies
• Drill or Battery Driver with a #2 Philips bit
1
• Putty Knife
2
• 3/32" Allen wrench
3
• Electrical Tape
4
• Exterior Roof Sealant (Non-hardening type)
5
Remove sealant & screws from base,
3
remove antenna and clean surface
ANHD20RTL12 INSTALLATION guIde
Crank existing antenna to full elevation.
1
Remove
3/32" set screw
2
spring, directional handle, & 4 screws.
Apply sealant to all holes & attach exterior plate
4
using the included hardware
from crank. Remove crank,
Advertisement
Related Manuals for Jensen ANHD20RTL12
Summary of Contents for Jensen ANHD20RTL12
- Page 1 ANHD20RTL12 INSTALLATION guIde w w w.JensenRVDirect.com TooLs & suppLies • Drill or Battery Driver with a #2 Philips bit • Putty Knife • 3/32” Allen wrench • Electrical Tape • Exterior Roof Sealant (Non-hardening type) Remove sealant & screws from base, remove antenna and clean surface Crank existing antenna to full elevation. Remove 3/32” set screw from crank.
- Page 2 Apply sealant to holes and attach base using the included hardware. Apply sealant to 3 screws, fill coax hole, connect coax to antenna and wrap connection with insulating electrical tape. Coax connection should be located inside vertical stalk of antenna for service. Attach antenna to base and seal all seams and screws on plate and antenna base.
