Summary of Contents for acopla ARX 1000
- Page 1 ARX®1000 Hardware Installation Guide Part Number: 810-0006-00, Revision T Acopia Networks, Inc. 41 Wellman Street Lowell, MA 01851 (978) 513-2900 tel (978) 513-2990 fax...
-
Page 2: Revision History
ARX®1000 Hardware Installation Guide Copyright© 2004-2008, Acopia Networks, Inc. All Rights Reserved, Printed in U.S.A. Revision History June 2004 - Rev A July 2004 - Rev B September 2004 - Rev C October 2004 - Rev D - new Hardware release October 20, 2004 - Rev E - added safety notices December, 2004 - Rev F - updated License notice, added admonishment March 2005 - Rev G... -
Page 3: Table Of Contents
Contents Chapter 1 Introduction Audience for this Manual..................1-1 Document Conventions .....................1-1 Related Documents ....................1-2 Safety and Regulatory Notices..................1-3 Class A ITE Label....................1-3 Laser Product Notice..................1-4 Qualified Personnel Warning ................1-5 Environmental....................1-5 High Temperature Warning.................1-5 Restricted Area Warning................1-5 Warning for Rack-Mounting and Servicing..........1-6 Power .........................1-7 Power Cord Usage ..................1-7 Electric Shock Warning ................1-7... - Page 4 Supported Protocols....................2-4 Network ......................2-5 File Services ...................... 2-5 Security and Authentication ................2-5 Management ...................... 2-6 Chapter 3 Switch Hardware Interfaces........................3-2 Application Control Module (ACM) ................ 3-2 Control and Management Functions ..............3-2 Adaptive Services ..................... 3-3 Network Services....................
- Page 5 Chapter 5 Unpacking and Installing the Switch Safety Instructions.....................5-2 Tools and Equipment....................5-2 Verifying Shipment ....................5-2 Unpacking the Switch ....................5-3 Installing the Rack-Mount Rails ................5-3 Rack-Mounting the Switch..................5-5 Attaching the Power Cord ..................5-5 Powering Up the Switch....................5-6 Cabling ........................5-6 Chapter 6 Connecting the Switch to the Network Management Interfaces .....................6-1 Connecting the Console Port..................6-2...
- Page 6 LED Status Indicators....................7-4 Status LEDs ....................... 7-5 Ethernet-Port Link Status LEDs ................ 7-6 Hard-Drive (HD) LED ..................7-7 Removing a Hard Disk Silencing the RAID Alarm ..................A-2 Replacing the Disk Drive..................A-3 Incorporating the Disk into the RAID .............. A-3 Monitoring the Rebuild ..................
-
Page 7: List Of Figures
List of Figures Figure 2-1. ARX®1000 Adaptive Resource Switch............ 2-2 Figure 3-1. ARX®1000 Front Panel View ..............3-1 Figure 3-2. ARX®1000 Interfaces................3-2 Figure 4-1. RJ-45 Male Connector ................4-6 Figure 4-2. RJ-45 to Serial DB9 Adapter ..............4-6 Figure 5-1. Installing the Rack-Mount Rails ............... - Page 8 3-viii ARX®1000 Hardware Installation Guide...
- Page 9 List of Tables Table 4-1. ARX®1000 System Specifications ............4-3 Table 4-2. Required Power and Data Cables............... 4-4 Table 4-3. Cable Connectors ..................4-5 Table 4-4. ACM Console Port Signaling/Cabling Using a Cross-over Cable..... 4-7 Table 7-1. Operational States and LED Patterns ............7-6 ARX®1000 Hardware Installation Guide 4-viii...
- Page 10 4-ix ARX®1000 Hardware Installation Guide...
-
Page 11: Introduction
Chapter 1 Introduction This manual describes the Acopia™ Adaptive Resource Switch 1000 (ARX®1000) and its hardware components. It also describes how to install the switch and connect it to the network. Audience for this Manual This manual is intended for field engineers and network administrators responsible for setting up and connecting the switch to a network at an enterprise data center facility. -
Page 12: Related Documents
Introduction Related Documents Cautions show how to avoid possible service outage or data loss. CAUTION Warnings are instructions for avoiding damage to the equipment. WARNING Danger notices help you to avoid personal injury. DANGER Related Documents In addition to this guide, the following Acopia documentation is also available: •... -
Page 13: Safety And Regulatory Notices
Introduction Safety and Regulatory Notices Safety and Regulatory Notices The maximum ambient room temperature that the unit can operate in is 55° C. CAUTION Do not block power supply vents or otherwise restrict airflow when installing unit in CAUTION rack. Mechanical loading of rack should be considered so that the rack remains stable and WARNING unlikely to tip over. -
Page 14: Laser Product Notice
Introduction Safety and Regulatory Notices Laser Product Notice Class 1 laser product. WARNING Produit laser de classe I. ATTENTION Class 1 lasers are defined as products which do not permit human access to laser radiation in excess of the accessible limits of Class 1 for applicable wavelengths and durations. -
Page 15: Qualified Personnel Warning
Introduction Safety and Regulatory Notices Qualified Personnel Warning Only trained and qualified personnel should be allowed to install, replace, or service WARNING this equipment. Il est vivement recommandé de confier l'installation, le remplacement et la maintenance ATTENTION de ces équipements à des personnels qualifiés et expérimentés. Environmental High Temperature Warning To prevent the switch from overheating, do not operate it in an area that exceeds the... -
Page 16: Warning For Rack-Mounting And Servicing
Introduction Safety and Regulatory Notices Cet appareil est à installer dans des zones d'accès réservé. Ces dernières sont des zones ATTENTION auxquelles seul le personnel de service peut accéder en utilisant un outil spécial, un mécanisme de verrouillage et une clé, ou tout autre moyen de sécurité. L'accès aux zones de sécurité... -
Page 17: Power
Introduction Safety and Regulatory Notices Power Power Cord Usage Do not use the attached power supply cable for other devices or usage. WARNI The attached power supply cable was designed to be connected and to be used for Acopia devices, and the safety for this purpose has been confirmed. Please do not use it for other devices or usages. -
Page 18: Circuit Breaker (15A)
Introduction Safety and Regulatory Notices Les ports étiquetés LINK, 1/1 through 1/6, CONSOLE, MGMT, MIRROR, et DEBUG ATTENTION sont des circuits de sécurité basse tension (safety extra-low voltage ou SELV). Les circuits SELV ne doivent être interconnectés qu'avec d'autres circuits SELV. Circuit Breaker (15A) This product relies on the building's installation for short-circuit (overcurrent) WARNING... -
Page 19: International Power-Cord Requirements
Introduction Contacting Customer Service Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par ATTENTION une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. International Power-Cord Requirements International Cords should have the following characteristics- •... - Page 20 Introduction Contacting Customer Service 1-10 ARX®1000 Hardware Installation Guide...
-
Page 21: Product Overview
Chapter 2 Product Overview This chapter provides a general overview of the Acopia ARX®1000. Topics include the following: • “The ARX®1000” on page 2-1 • “Hardware Features” on page 2-2 • “Redundant Pairs” on page 2-3 • “Resilient Overlay Network (RON)” on page 2-4 •... -
Page 22: Hardware Features
Product Overview Hardware Features • inline management of storage capacity, to adapt the back-end storage to client demands, • ability to add or remove back-end storage without any effect on clients, and • the ability to seamlessly migrate files from one back-end storage device to another. -
Page 23: Redundant Pairs
Product Overview Redundant Pairs • External interfaces including: – serial console port – out of band 10/100Mbps Ethernet management port – two Gigabit Ethernet Small Form Factor Pluggable (SFP) ports (with SX fiber optics) – four 100/1000BASE-T Ethernet ports • Front panel LEDs to indicate system status, port link status, and NVRAM battery status (shown in Figure 7-3 on page... -
Page 24: Resilient Overlay Network (Ron)
Product Overview Resilient Overlay Network (RON) Resilient Overlay Network (RON) You can connect multiple ARXes together in a Resilient Overlay Network (RON). A RON is composed of a series of IP tunnels between the switches. You can use the CLI to configure a RON tunnel, as described in the CLI manuals. -
Page 25: Network
Product Overview Supported Protocols Network • spanning tree: 802.1D and Rapid Spanning Tree (802.1S) In 802.1D mode, the switch executes the 802.1S protocol in 802.1D compatibility NOTE mode. This allows inter operability with legacy 802.1D-only devices. • VLAN (802.1Q) • passive link aggregation (802.3ad), without LACP •... -
Page 26: Management
Product Overview Supported Protocols Management • Simple Network Management Protocol (SNMP) • Telnet • SSH (Secure SHell) • Hypertext Transfer Protocol (HTTP) • Hypertext Transfer Protocol over SSH (HTTPS) • For transferring maintenance and release files: • File Transfer Protocol (FTP), •... -
Page 27: Switch Hardware
Chapter 3 Switch Hardware The Acopia ARX®1000 switch is a 2-rack unit designed for a standard 19-inch rack installation. Figure 3-1. ARX®1000 Front Panel View The switch contains the following components: • Interfaces for client/server traffic and system management. • Application Control Module (ACM), which supports all system control, adaptive services, and network functions for the switch. -
Page 28: Interfaces
Switch Hardware Interfaces Interfaces The switch provides eight external interfaces, including a serial Console interface, Ethernet management interface, two fiber-optic Gigabit Ethernet ports, and four copper 100/1000 Ethernet ports. Figure 3-2. ARX®1000 Interfaces ports 1/1 and 1/2 ports 1/3 - 1/6: serial network- Gigabit Ethernet... -
Page 29: Adaptive Services
Switch Hardware Application Control Module (ACM) • Port mirroring and debugging • MAC address assignment for Ethernet ports • Real-time clock synchronization for user interfaces • Switch health status and statistics monitoring and management through LEDs and software • Temperature and power monitoring Adaptive Services The ACM module provides the core distributed filer functions for the switch, including:... -
Page 30: Power Supply
Switch Hardware Power Supply • Common Internet File System (CIFS) Fast Path Power Supply The AC/DC power supply provides the following features and functions: • Provides 450 Watts @ +2.5 V, +3.3 V, and +12.0 V for switch operations. (Note that the power supply draws up to 608W from the AC power cord due to its operating efficiency.) •... -
Page 31: System Specifications And Requirements
Chapter 4 System Specifications and Requirements This chapter contains regulatory information and specifications for the ARX®1000: • “Regulatory Compliance” on page 4-1 • “FCC Compliance” on page 4-2 • “System Specifications” on page 4-3 • “System Power Requirements” on page 4-3 •... -
Page 32: Fcc Compliance
System Specifications and Requirements FCC Compliance Category Compliance • FCC Part 15 Class A Emissions • CISPR22 Class A (EN55022) CE Marking • EN 55024 • VCCI Class 1 FCC Compliance This is a Class A product. In a domestic environment this product may cause radio CAUTION interference, in which case the user may be required to take adequate measures. -
Page 33: System Specifications
System Specifications and Requirements System Specifications System Specifications Table 4-1 describes the ARX®1000 system specifications. Table 4-1. ARX®1000 System Specifications Component Specification Chassis Dimensions Height: 3.375 in. (includes front bezel) Width: 19.00 in. (including the fixed mounting ears) Depth: 23.75 in. Weight 35 lb (15.88 kg) Power Load... -
Page 34: Power Cord And Cable Requirements
System Specifications and Requirements Power Cord and Cable Requirements Power Cord and Cable Requirements Table 4-2 lists the required cables and power cords for the switch. All cables except the AC power cord and console cable are customer-supplied. Table 4-2. Required Power and Data Cables Qty. -
Page 35: Cable Connectors And Pinouts
System Specifications and Requirements Cable Connectors and Pinouts Gigabit Ethernet ports support automatic MDI/MDIX cross-over. This feature automatically corrects the polarity of the attached CAT5 cable, regardless if it is a cross-over or straight-through type. However, for this feature to work, the port speed must be set to auto (auto-negotiate) through the CLI. -
Page 36: For The Serial-Console Port
System Specifications and Requirements Cable Connectors and Pinouts For the Serial-Console Port The serial-Console port requires a rollover cable (RJ-45 to RJ-45) that is included with the ARX-installation kit. This cable is sufficient for connecting to a Terminal Server. For a direct connection to the serial port on a management station (such as a laptop), an RJ-45 to DB9 adapter is also included in the kit. -
Page 37: Sfp Optical Connector
System Specifications and Requirements Cable Connectors and Pinouts Table 4-4. ACM Console Port Signaling/Cabling Using a Cross-over Cable SCM/ACM Cross-over Cable Terminal Adapter Console Console Port Device DTE Signal RJ-45 USOC RJ-45 RJ-45 T568 DB9F Pinout Color Pinout Pinout Color Pinout Signal yellow... - Page 38 System Specifications and Requirements Cable Connectors and Pinouts ARX®1000 Hardware Installation Guide...
- Page 39 Chapter 5 Unpacking and Installing the Switch This chapter describes the following topics and tasks: • “Safety Instructions” on page 5-2 • “Tools and Equipment” on page 5-2 • “Verifying Shipment” on page 5-2 • “Unpacking the Switch” on page 5-3 •...
-
Page 40: Unpacking And Installing The Switch
Unpacking and Installing the Switch Safety Instructions Safety Instructions Observe the following safety guidelines to avoid personal injury or damage to equipment when installing or operating the switch: Never assume that power is disconnected from a circuit; always check. DANGER Before installing the switch, locate the power ON/OFF toggle on the back of the switch and make sure it is set to OFF. -
Page 41: Unpacking The Switch
Unpacking and Installing the Switch Unpacking the Switch • 1 8-ft. (2.4384-M) crossover cable (for the Console) with RJ-45-to-DB9 adapter • 2 mounting rails, 1 left and 1 right • 2 sets of screws for mounting the rails to the rack: 12 #8 screws and 12 #10 screws •... -
Page 42: Figure 5-1. Installing The Rack-Mount Rails
Unpacking and Installing the Switch Installing the Rack-Mount Rails Align each rail edge flush against the rack, aligning the screw holes. If necessary, adjust the depth of the rails by loosening or tightening the locking screws with a Phillips-head screwdriver. locking nuts Secure the rails in place on both ends of the rack with the rack-mount screws (4 per rail) shipped in the accessory kit:... -
Page 43: Rack-Mounting The Switch
Unpacking and Installing the Switch Rack-Mounting the Switch Rack-Mounting the Switch Holding the switch firmly, align the switch (front panel view) with the rack rails. Carefully slide the switch into place on the rails. Figure 5-2. Aligning Switch with Rack Rails screw hole Firmly grip the switch edges and slide the switch into place... -
Page 44: Powering Up The Switch
Unpacking and Installing the Switch Powering Up the Switch Figure 5-3. ON/OFF Power Switch (Rear View) “Power Cord and Cable Requirements” on page 4-4 for power cord and cable specifications. Powering Up the Switch Before applying power, ensure that the AC outlet to the switch is properly grounded. WARNING To power up the switch, turn the ON/OFF toggle switch(es) to the ON position. -
Page 45: Connecting The Switch To The Network
Chapter 6 Connecting the Switch to the Network This chapter describes how to connect the ARX to a console terminal and boot the switch for the first time. Management Interfaces As stated earlier, the switch provides the following management ports: •... -
Page 46: Connecting The Console Port
Connecting the Switch to the Network Connecting the Console Port During the initial-boot process described in this chapter, you can only access the serial (Console) port. You configure the OOB management port (“MGMT”) as part of the procedures in this chapter. Connecting the Console Port Set the following console-terminal parameters to match those on the Console port: •... -
Page 47: Sample: Booting A Non-Replacement Switch
Connecting the Switch to the Network Booting the Switch Sample: Booting a Non-Replacement Switch This sample shows the simplest initial-boot scenario, for a new (non-replacement) switch that is either standalone or the first member of a redundant pair. The sample answers are not necessarily appropriate to the following scenarios: •... - Page 48 Connecting the Switch to the Network Booting the Switch Massachusetts, U.S.A.. 2. Enter 'yes' to accept these terms and conditions in the format 'yes' or 'no'. # yes The switch's management port requires an IP address and mask. 3. Enter the management port IP address in the format nnn.nnn.nnn.nnn or 'none'.
- Page 49 Connecting the Switch to the Network Booting the Switch in the format base64-encoded key or keyword 'generate'.(default=generate) # <Enter> The system displays a configuration summary, for example: Configuration Summary Management IP Address 10.1.23.11 Management IP Mask 255.255.255.0 Management Gateway 10.1.23.1 Power Configuration Private IP Subnet 169.254.76.0...
-
Page 50: Preparing For Switch Replacement
Connecting the Switch to the Network Booting the Switch The boot-up prompts continue until you reach the “Username” prompt. Confirm that an administrator can log in by using the Crypto-Officer username and password that you entered in the initial-boot script. For example: User Access Authentication Username: admin Password: mypassword... -
Page 51: Entering The Private Subnet
Connecting the Switch to the Network Booting the Switch private subnet for communication with other ARXes in the same RON and/or the switch’s redundant peer. All private subnets in the RON and/or pair are carried by the same VLAN. This private VLAN, and the separate metalog VLAN, must be reserved for ARX traffic only. -
Page 52: Finding The Uuid Of The Failed Switch
Connecting the Switch to the Network Booting the Switch in the format integer [1-4095].(default=1002) # <Enter> The private subnet metalog VLAN is used for storing file-change logs on battery-backed NVRAM, possibly on a redundant peer. Be sure this value does not conflict with existing VLAN IDs. 10. -
Page 53: Applying The Uuid
Connecting the Switch to the Network Booting the Switch bstnA6k# show ron Switch Name HA Peer Switch Uptime Status UUID Management Addr ------------------------------------------------------------------------------ bstnA6k (None) 0 days, 02:02:47 ONLINE d9bdece8-9866-11d8-91e3-f48e42637d58 10.1.1.7 provA5c (None) 0 days, 02:01:04 ONLINE db922942-876f-11d8-9110-8dtu78fc8329 10.1.38.19 prtlndA1k prtlndA1kB 0 days, 00:30:53 OFFLINE... -
Page 54: Preparing To Install A Redundant Peer
Connecting the Switch to the Network Booting the Switch Preparing to Install a Redundant Peer The initial-boot script requires some additional information if you are installing the second switch in a redundant pair. Both members of a redundant pair share a common master key. -
Page 55: Applying The Master Key
Connecting the Switch to the Network Booting the Switch 2oftVCwAAAAgAAAApwazSRFd2ww/H1pi7R7JMDZ9SoIg4WGA/XsZP+HcXjsIAAA ADDRbMCxE/bc= prtlndA1kB# ... Applying the Master Key As shown earlier, there is a prompt for the master key in the initial-boot script. You can answer this prompt with the encrypted master key; the script then prompts for the wrapping password. - Page 56 Connecting the Switch to the Network Booting the Switch Acknowledge acceptance of the following terms and conditions by entering 'yes' at the next question. 1. Press <Enter> to continue. # <Enter> 2. Enter 'yes' to accept these terms and conditions in the format 'yes' or 'no'.
- Page 57 Connecting the Switch to the Network Booting the Switch The private subnet metalog VLAN is used for storing file-change logs on battery-backed NVRAM, possibly on a redundant peer. Be sure this value does not conflict with existing VLAN IDs. 10. Enter the chassis's private subnet metalog VLAN in the format integer [1-4095].(default=1003) # <Enter>...
- Page 58 Connecting the Switch to the Network Booting the Switch Confirm the wrapping password # an0ther$ecretpw Configuration Summary Management IP Address 10.1.23.12 Management IP Mask 255.255.255.0 Management Gateway 10.1.23.1 Power Configuration Private IP Subnet 169.254.94.0 Private IP Mask 255.255.255.0 Private VLAN 1002 Private Metalog VLAN 1003...
- Page 59 Connecting the Switch to the Network Booting the Switch User Access Authentication Username: admin Password: mypassword SWITCH> The switch is now ready for configuration through the GUI or CLI. To join it with its redundant peer, you can use the standard practice of copying and applying the failed switch’s running config: SWITCH>...
-
Page 60: Connecting The Ethernet Management Port
Connecting the Switch to the Network Connecting the Ethernet Management Port prtlndA1k(cfg)# ... prtlndA1k(cfg)# exit prtlndA1k# If you copied the private subnet and mask from the defunct switch, this completes the switch replacement. Otherwise, the new switch learns its private subnet from its peer, re-configures itself, and reboots. -
Page 61: Operational Status And Troubleshooting
Chapter 7 Operational Status and Troubleshooting This chapter describes the ARX®1000 hardware power-on self-test (POST) diagnostics and module and port status indicators (LEDs) and their associated conditions. POST Diagnostics When the switch reboots and the system powers up, POST (power-on self-test) diagnostics run to verify basic hardware integrity. -
Page 62: Figure 7-2. Show Chassis Sample
Operational Status and Troubleshooting POST Diagnostics prtlndA1k uptime is 0 weeks, 0 days, 1 hours, 43 minutes. Slot Admin ModuleType ModuleState FW Upgrade ---- ------- ------------ ---------------- ---------- Enabled Online Disabled Resource State Forwarding -------- ------------------------------- ---------- Switch Disabled Figure 7-2. Show Chassis Sample prtlndA1k# show chassis Identification: Hostname... - Page 63 Operational Status and Troubleshooting POST Diagnostics ------ --------------------- ----------------- ----------------- Optimal Automatic 10 % Disk Details: Disk Size State Transfer Rate Model -------- ----------- ----------------- ------------- ----------------- Bay 1 74.53G Online 1.5Gb/sec ST380013AS Bay 2 76.33G Online 1.5Gb/sec 6Y080M0 RAID Controller Details: Rebuild Rate Max Transfer Rate Firmware...
-
Page 64: Led Status Indicators
Operational Status and Troubleshooting LED Status Indicators firetruck 2.05.000.09942 2.05.000.09942 2.05.000.09942 hunchback 2.05.000.09942 2.05.000.09942 2.05.000.09942 Port Media Details: Slot/Port Type vendor Status --------- --------------- --------------- ----------------------- 1000BASE-SX FINISAR CORP. Good 1000BASE-SX FINISAR CORP. Good Disk Usage: Name Total MB Used MB Free MB Used% --------------------------------... -
Page 65: Status Leds
Operational Status and Troubleshooting LED Status Indicators • hard-drive LED and NVR-battery-backup LEDs (also shown in Figure 7-3) • Ethernet management port and user port LEDs (see Figure 7-4 on page 7-5) Figure 7-3. ARX®1000 System LEDs system Alert (red if hardware fails) module Status (green = ’all OK’,... -
Page 66: Ethernet-Port Link Status Leds
Operational Status and Troubleshooting LED Status Indicators STATUS — Illuminates Green or Yellow based on the system’s current operational state During various module operations, LEDs display Green, Yellow, or Red with intermittent blinking patterns, depending on the state. When blinking, LEDs blink ON for a half second and OFF for a half second. -
Page 67: Hard-Drive (Hd) Led
Operational Status and Troubleshooting LED Status Indicators Hard-Drive (HD) LED The hard drive (HD) LED is not supported. ARX®1000 Hardware Installation Guide... - Page 68 Operational Status and Troubleshooting LED Status Indicators ARX®1000 Hardware Installation Guide...
-
Page 69: Removing A Hard Disk
Appendix A Removing a Hard Disk This chapter describes how to remove and replace a disk drive in the ARX®1000 chassis. This is a hot-swap procedure, requiring no power-down of the switch and no loss of service. Static electricity can damage switch components. Be sure to wear antistatic wrist straps WARNING before handling disk drives. -
Page 70: Silencing The Raid Alarm
Removing a Hard Disk Silencing the RAID Alarm To remove a disk drive, use a Phillips-head screwdriver to loosen both captive screws. Slide out the disk drive and sled from its slot in the chassis. The chassis continues to run, in degraded state, with only one disk missing from the RAID. -
Page 71: Replacing The Disk Drive
Removing a Hard Disk Replacing the Disk Drive Escape character is '^]'. Username: admin Password: acopia prtlndA1k> enable prtlndA1k# raid silence prtlndA1k# ... Replacing the Disk Drive To replace the disk drive, slide it into the empty slot and tighten its two captive screws. - Page 72 Removing a Hard Disk Replacing the Disk Drive prtlndA1k# show chassis diskuse Logical Disk Details: Disk Status Verification Mode Verification Rate ------ --------------------- ----------------- ----------------- Optimal Manual 50 % Disk Details: Disk Size State Transfer Rate Model -------- ----------- ----------------- ------------- ----------------- Bay 1...
- Page 73 Copyrights Copyright (c) 1990, 1993, 1994, 1995 The Regents of the University of California. All rights reserved. Copyright 2000 by the Massachusetts Institute of Technology. All Rights Reserved. Export of this software from the United States of America may require a specific license from the United States Government.
- Page 74 Copyright-2 ARX®1000 Hardware Installation Guide...
- Page 75 Index connector adaptive services , 3-2, features network services Diagnostics at switch bootup Disk drives 1000 platform removing and replacing Audience for this manual Fan unit Bezel FCC compliance , 6-2, 6-10 Booting the switch File service protocols supported Front bezel FRUs and static electricity disk drive...
- Page 76 features Powering up the switch Protocols supported LEDs conditions and blinking patterns front panel (fig.) port/link LEDs system status and alert Rack-mounting the switch Redundancy between two ARX1000’s Regulatory compliance Removing and replacing a disk drive Management port Resilient Overlay Network (RON) 6-16 connecting RON tunnels...
- Page 77 Tools for installation Unpacking the switch ARX®1000 Hardware Installation Guide...
- Page 78 ARX®1000 Hardware Installation Guide...
