Assembly

Ensure that the rear side of the Upper
Tube is facing the same direction as the
rear side of the Main Body.
Rear Side of the Front Side of the
Upper Tube Upper Tube
Insert narrow end of Upper Tube (with
button) into Lower Tube, matching
screw holes. Fasten tubes together
with the included small screw.
(See Fig. 1 on pg. 9.)
Insert assembled tube in the back of the
Main Body. Ensure the back of the Upper
Tube (with screw holes and flat section)
faces away from Main Body. Fasten tube
with the included large screw.
(See Fig. 2 on pg. 9.)
8
