Summary of Contents for Konexx Konference Konnector
Page 1
Local: 863-614-1900 Toll Free: 866-770-4930 Fax: 888-782-3072 E-mail: telephoneman@telephonemanofamerica.com Skype Us TelephonemanOfAmerica.com shop.telephonemanofamerica.com TELEPHONE MAN OF AMERICA Earning Your Business Every Step of the Way! Specializing in Telecom Equipment of all Brands, Carrier Services, Technician Services, Maintenance Agreements and Purchasing Excess Telecom Equipment! I will always do my best to match or beat any competitors bid!
Figure 1: Typical Installation 1. Unplug the coiled handset cord from the telephone instrument. 2. Plug the short cord on the KONEXX into the handset jack on the telephone base (from which you just removed the coiled cord). 3. Plug the coiled cord from the handset into the KONEXX jack labeled "HANDSET".
D. Remember that the KONEXX Konference Konnector must have the AC adapter connected in order to operate. E. The KONEXX Konference Konnector will not operate with telephones which have the dialer in the handset, such as Princess or Trimline phones. The electronics with which the Konference Konnector interacts are not accessible in these telephones.
Page 4
OUTPUT LEVEL SETTING CHART MANUFACTURER MODEL SWITCH MANUFACTURER MODEL SWITCH MANUFACTURER MODEL SWITCH SETTING SETTING SETTING None Alcatel Harris Lanier Nitsuko Onyx Specified Hitachi Digital Northcom Premier Avaya Definity (NC-1648) Model 200 Lucent Destiny Nortel Advantage HCX-5000 Dimension 2 or 3 Focus Intecom IBX System...
Page 5
(performed by Konexx) to optimize the audio level from the Datastar conference phone to the remote parties. The indicated telephone has “Non-Standard” handset wiring, which requires an adapter cable. Contact Konexx if you have one of these Meritore telephones. Onyx...
