- Page 1 BNAV-9500DVBTV CAR STEREO/HANDHELD GPS DUAL-SYSTEM PLAYER MANUAL BNAV-9500DVBTV BNAV-9500DVBTV CAR DVD/MP4/MP3/CD/USB/SD/MMC PLAYER TV/BLUETOOTH/GPS...
- Page 2 WELCOME Thanks for your choice of our digital player. For proper use of the product, please read the Manual carefully before utilization and keep the Manual properly for later reference. “Dual-system Player” is a multi-function player composed of car DVD player and handheld GPS.
-
Page 3: Table Of Contents
TROUBLESHOOTING GUIDE FOR MINOR FAULTS Contents Problem Check whether the fuse of the power supply is burnout. In case it is No Power Supply Installation Notes… … … … … … … … … … … … … … … … … … … … … … … … … … … … …. 3 necessary, change the fuse of proper capacity. -
Page 4: Installation Notes
INSTALLATION NOTES INDEX AND PARAMETER The Player is negatively ground in the form of 12VDC design. General Power………………………………………………… 14.4V DC When installing the Player, please make sure that the car relates to DC 12V negative Load………………………………………………….. 4Ω grounding. Maximum Power Output…………………………… 500W×4 Volume Control……………………………………... -
Page 5: Disc-Playable Format
INSTALLATION NOTES PREVENTION ITEMS The discs or files in the following formats are readable by the Player: ※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※ Component Table (for the illustration of numbers in Table, please see the Installation) Output Format of the Sound Output Format Disc Size and Film Source Sound &... -
Page 6: Wire Connection Notes
WIRING DIAGRAM THE OPERATION OF REMOTE CONTROLLER Title menu Standard Connection - In the state of DVD, press 24 (Title) to display all play list of the CD, and then press 14 (0~10+) to directly play or press the menu selection 4 ( )to select the needed menu. -
Page 7: Function Description
When selecting the output mode, the system will show the line output and RV adjustment (as shown in the figure). When selecting the dynamic rage, it is allowed to select the FULL, 6/8, 4/8 and 2/8 (as shown in the BNAV-9500DVBTV figure). BNAV-9500DVBTV When selecting left + right, the system will show stereo, left channel, right channel and mixing channel (as shown in the figure). -
Page 8: Basic Function Description
BASIC FUNCTION DESCRIPTION THE OPERATION OF REMOTE CONTROLLER 1. Power On/Off/Mute Audio Setup: digital output, audio and exit setup. Short press (1) (Power) to turn on the Player and long press it to turn the Player off. When selecting the password output, the system will show SPDIF/turn-off, SPDIF/sound code and In the state of working, the Player will turn to “mute”... - Page 9 THE OPERATION OF REMOTE CONTROLLER BASIC FUNCTION DESCRIPTION Language Setup AMS Radio Function Press (5) (AMS) to search the radio sets, and a function will be exiting on the number (17) (1~6) every 5 Language setup, OSD language, audio language, subtitle language, menu language and exit setup. seconds.
- Page 10 BASIC FUNCTION DESCRIPTION THE OPERATION OF REMOTE CONTROLLER *Go on to press volume button, and *Go on to press volume button, and When selecting the option of password setup, you can set your own password (as shown in the figure). when TRE appears, turn the button when BAL appears, turn the button The password initialization is locked so that you can neither see the level value nor change the password.
- Page 11 THE OPERATION OF REMOTE CONTROLLER BASIC FUNCTION DESCRIPTION Setup Menu 10. Tuning/ Song Selecting Ordinary tuning: Press(10 ), the radio sets will be regulated backwards or forwards. - In the state of playing, press 23 (SETUP), and the screen will show the contents of the system menu, which are as shown below.
- Page 12 BASIC FUNCTION DESCRIPTION THE OPERATION OF REMOTE CONTROLLER 12. Eject Random Play Press Eject, discs will be ejected from the Player. - In the mode of shuffle play, press 13 (LOC/RDM) to select the mode of random play (that is to play out of turn) Note: In the mode of DVD, 13 (LOC/RDM) is not available.
-
Page 13: Functional Position Of Remote Control
THE OPERATION OF REMOTE CONTROLLER REMOTE CONTROL FUNCTION POSITION BAND/SYS - In the mode of reception, press 5 (BAND/SYS) to switch the band. - In the mode of video, press 5 (BAND/SYS) to change the system NTSC, PAL or AUTO. Volume +/- - Press 7 (VOL+ or VOL -) to adjust the volume. -
Page 14: Operation Of Remote Controller
THE OPERATION OF REMOTE CONTROLLER THE OPERATION OF REMOTE CONTROLLER Battery Replacement Switch －Press 1( ), to turn on/off the power. When the remote controller lacks of voltage and can not work normally, you should replace the battery; and when replacing the battery, you should choose batteries of the same type with the ones you used before.
