MSR180
Owner's
Manual
VOL +
MENU
CH
CH
SEL
TUNE
TUNE
+
VOL
WATERPROOF
2
3
1
RPT
CATEGORY
featuring
MODE
AS/PS
EQ
BAND
DISP
LOUD
ENTER
S-MOD
4
5
6
SHF
SCN
Thank You!
Thank you for choosing the MSR180. We hope you will find the instructions in this owner's
manual clear and easy to follow. If you take a few minutes to look through it, you'll learn how to
use all the features of your new receiver for maximum enjoyment.
System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Radio Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Sirius Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
System Features
Features of the MSR180 mobile audio system include:
•
PLL Synthesizer Stereo Radio
•
Waterproof Fixed Front Panel
•
Sirius-Ready Satellite Radio Function
•
Auxiliary Input Function
•
Marine Construction (uV resistant finishes, coated circuit boards,
daylight visible display, etc.)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ASA Electronics MSR180
Summary of Contents for ASA Electronics MSR180
- Page 1 Thank You! Thank you for choosing the MSR180. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new receiver for maximum enjoyment.
-
Page 2: Table Of Contents
Guide d'Utilisateur Merci! Merci d'avoir choisi la MSR180. Nous espérons que vous allez trouver les instructions dans ce guide de propriétaire claires et faciles à suivre. Prenez quelques minutes à le consulter, vous apprendrez à utiliser toutes les fonctions de radio pour en tirer une jouissance maximum. -
Page 3: Cableado
Wiring The wiring diagram depicts all the wiring connections required for proper operation of the unit. From 9-Pin Harness Speaker Pair White/Black White Black Blue Speaker Pair Gray/Black Gray From 4-Pin Harness Speaker Pair Violet/Black Violet Speaker Pair Green/Black Green Cableado El diagrama de cableado describe todas las conexiones necesarias para el funcionamiento de la unidad. -
Page 4: Basic Operation
Basic Operation 1. Power Press the power button (1) to turn the unit on. The unit will turn on to the mode that was in use when it was last powered down. Press the power button again to turn the unit off. 2. - Page 5 Basic Operation (continued) 6. Menu Operation Press SEL/MENU (6) for more than three seconds to access the menu feature. Once this feature is activated, press SEL/MENU momentarily to step though the available menu options, then press VOL + or VOL - to change the setting for that option, if desired. When no adjustments have been made for five seconds, the unit will resume normal operation.
- Page 6 Basic Operation (continued) 7. Loudness Press LOUD (7) momentarily to reinforce the bass output. “LOUD” will appear in the display. Press LOUD again to deactivate this feature. 8. Display Press DISP (8) multiple times to change the displayed information in Sirius mode. The displayed information includes Artist, Song Title, Channel Name, and Category Name.
-
Page 7: Radio Operation
Radio Operation 11. Select a Band Press BAND/ENTER (11) to change between three FM bands and two AM bands. 12. Tuning Seek Tuning Press CH TUNE - (12a) or CH TUNE + (12b) momentarily, and the unit will automatically tune to the next strong station. - Page 8 Radio Operation (continued) 14. Automatically Store / Preset Scan Automatically Store To automatically select six strong stations and store them in the current band, select a band (if needed) and press AS/PS (14) for more than three seconds. The six strongest stations are stored as presets, replacing any preset stations already stored in that band.
-
Page 9: Sirius Satellite Radio Operation
MSR180 Sirius Satellite Radio Operation 16. User Preset Channel Selection While in Sirius mode, navigate the three options in the user-preset channel group by momentarily pressing BAND/ENTER (16). User preset channels include SR1, SR2 and SR3. 17. User Preset Channel Search Press AS/PS (17) to search for each user preset channel from SR1 to SR2 to SR3 and stop at each available channel for five seconds. - Page 10 Sirius Satellite Radio Operation (continued) Category Tune To search the available music categories, press SHIFT/SCAN to access category mode then press CATEGORY (20b) or CATEGORY (20c) to scroll through the available category options. When the desired category is found, search for a specific channel by momentarily pressing CH TUNE - or CH TUNE +.
-
Page 11: Troubleshooting
Troubleshooting Problem Cause No power. Vehicle ignition switch is not The fuse is blown. No sound. Volume turned down too low. Wiring not connected properly. Check wiring connections. Operation keys do not Microcomputer is not operating work. properly due to noise. Radio does not work Antenna cable not connected. -
Page 12: Dépannage
Dépannage Problème Cause Pas de puissance L'allumage du véhicule n'est pas en marche Le fusible a sauté Pas de son Le volume est trop bas Le câblage n'est pas correctement fait Vérifiez le câblage Les clés d'opération Le micro-ordinateur ne fonctionne pas ne fonctionnent pas bien à...
