Summary of Contents for Axion AXN-9705
- Page 1 User’s Guide...
-
Page 2: Fcc Compliance Statement
FCC ComplianCe Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Controls And Connections
ContRolS anD ConneCtionS top View power leD Power On/Off Button play/pause/mode Button menU Button Up/Copy/Delete Button Down/Rotate Button prev./Return Button next Button P OW E R P L A Y /P A U S E M EN U D OW N P R EV . - Page 4 ContRolS anD ConneCtionS Cal/time SoURCe Switch between the Press to switch between clock, calendar and memory card reader,USB, or photo display mode internal memory as source Zoom Repeat Press to zoom into an image Up/CopY/Del menU neXt/RiGHt leFt/RetURn plaY/paUSe/moDe Down/Rotate *For detailed feature and function of each key, please refer to the detailed feature pages.
- Page 5 SetUp Press MENU button to enter main menu. Use the directional keys to highlight the “SETTINgS” icon then press “Play/Pause/Mode” button to select. a. General Setup page • BRIgHTNESS: Adjust brightness from -10 to 10 • SlIDE SHOW TIME: Select 05, 10, 30 sec; 01 minute, or 01 hour display time for each photo •...
-
Page 6: Photo Slide Show
pHoto SliDe SHow The Digital Photo Frame will automatically start a photo slide show every time it is powered on. The source of the picture will be as following: memory Card Reader -> USB devices ->internal memory (note: to manually change file location, press the “Source” button on the remote control to select the desired location) During the slide show, you may press the “Play/Pause/Mode”... -
Page 7: Music Playback
mUSiC plaYBaCk Press the “MENU” button to access menu screen of the frame. Use the direction button to select the “AUDIO” icon then press “Play/Pause/Mode” to confirm. The frame will display a list of audio file found on the selected source media (press “SOURCE”... -
Page 8: Video Playback
ViDeo plaYBaCk Press the “MENU” button to access menu screen of the frame. Use the direction button to select the “VIDEO” icon then press “Play/Pause/Mode” to confirm. The frame will display a list of video file found on the selected source media (press “SOURCE”... -
Page 9: Clock/Calendar Display
CloCk/CalenDaR DiSplaY Press the “MENU” button to access menu screen of the frame. Use the direction button to select the “ClOCK” icon then press “Play/Pause/Mode” to confirm. The frame will display current time and alarm time. Press the “MENU” button to access menu screen of the frame. Use the direction button to select the “CAlENDAR”... - Page 10 alaRm CloCk opeRation Press “MENU” button to enter main menu. Use the directional keys to highlight the “SETTINgS” icon then press “Play/Pause/Mode” button to select. Press “NEXT/RIgHT” button to enter “ClOCK SETUP PAgE”. Press “DOWN/ROTATE” button 6 times then press “Play/Pause/Mode” button to set alarm time. Use LEFT or RIGHT button to choose the Hour or Minute, then use UP or DOWN button to change the digit.
- Page 11 CopY/Delete piCtURe Copying photos to your frame To copy photos from a memory card to your frame, locate the photo, press the “Play/ Pause/Mode” button once to pause, and press UP/COPY/ DElETE. It will ask if you would like to copy the photo. Select YES, and press PlAY/MODE. The frame will then copy up to 15 photos to the frame’s internal memory.
- Page 12 FaQ & Specifications Q: Why after I pressed POWER on/off button, the screen is still dark? A: Check to see if the power lED is illuminated that indicates the power supply is properly connected and providing power. Q: Why the frame won’t recognize my memory card? A: Please check the type of memory card you are using.
-
Page 13: Key Features
Key Features Feature External Memory Internal Memory (Cards and or Flash Drives) √ Photo slide show with music Photo slide show √ √ without music Photo auto-rotation with √ frame orientation √ Delete photos from memory √ Playback music/audio files √... - Page 14 AXN products are warranted for one (1) year for parts and ninety (90) days for labor, starting from the original date of purchase/invoice. What brand(s) can be covered under the warranty: Any “ACTION” and “AXION” branded products sold by America Action, Inc. Whom the warranty protects: This warranty is valid only for the original purchaser.
- Page 15 How to get service: 1. For additional information on obtaining an extended warranty service, contact your AXN dealer or AXN’s Customer Service Department by e-mailing to customerservice@axionzone.com To obtain warranty service, you will be required to do one of the following: fill out an online RMA Request Form, print the form, fill it out and fax it to 1-909-869-5545, or call AXN’s Customer Service number at 1-909-869-6600.
- Page 16 INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BYAPPLICABLE LAW,ANYIMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS DURATION TO THE DURATION OF THIS WARRANTY. Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
