Microlab MD312 User Manual page 2

80-MD312-97-0001-01
English
1
2012-04-09
2
(changed to power adapter)
Technical Information
AMPLIFIER
Total Power: 4 Watt RMS
Power distribution: 1.25 Watt x 2 + 1.5 Watt
Harmonic distortion: < 5% 1 W 1 kHz
Frequency response: 40 Hz - 18 kHz
Signal/Noise ratio: > 65 dB
Separation: > 45 dB
Speakers
Tweeter type: 2" x 2
Tweeter rated power: 2 Watt 4 Ohm
Woofer type: 3"
Woofer rated power: 5 Watt 2 Ohm
Interfaces
Output: NIL
Input: 3.5mm stereo jack, mini-USB charging port
Wireless: Bluetooth 2.1 + EDR, and A2DP
FrequentlyAsked Questions (FAQ)
FrequentlyAsked Questions
Check if the system is powered on or battery is
replaced with fresh BL-5C type
LED do not light up
Please perform an initial charge of 4 hours prior
to initial use.
Check if the audio source is properly paired and
connected. Secondly check if the 3.5mm stereo plug
is correctly inserted for AUX mode.
No Sound
Ensure volume is correctly set
Please check the audio source distance, try to place
Intermittent sound
it nearer to the speaker system.
Simply connect the system to the supplied Charging
How to charge the system?
adapter. After charged the LED will turned off.
Any Bluetooth enabled music devices and playback
What are the products
devices such as PC, Media players with 3.5mm
supported?
stereo plug.
Check if the volume is at lower level and the Mp3
Sound is distorted
format is recorded at above 196 bitrate
It is magnetically shielded so can be placed
Where to place this speaker
near LCD TV Monitor without any distortion
If the problem still exists, please contact the distributor or ask for professional service
- The end -
© 2012 Microlab Electronics Co., Ltd All rights reserved.
Answers
