Summary of Contents for Dutchman Dutchman
- Page 1 Martinus Van Breems, Inc. 54A Beach Road, Norwalk, CT 06855 Tel. 203-838-0375 Fax 203-838-0377 OWNER’S MANUAL BOOM BRAKE...
-
Page 3: Table Of Contents
Boom Brake Owner’s Manual Introduction The Dutchman Boom Brake is simple, reliable device to regulate the boom speed. How well the Brake will work depends on proper installation. You also will have set the tension correctly for different wind speeds. Please follow these instructions carefully. -
Page 4: Specifications
Specifications These specifications are for conventional, moderate displacement monohulls, and are provided as a rough indication of which Boom Brake and installation kit should be used. Heavy displacement sailboats or sailboats which will be undertaking extensive offshore passages must use oversized equipment. Use the next size larger installation kit to start off. -
Page 5: Installing The Boom Brake
Installing the Boom Brake How well the Brake works is determined by the installation. Read these Deck Attachment Points instructions carefully. First, identify the best possible locations for the deck attachment point, then the boom attachment point. Do not install any hard- Chainplate ware until you are certain of BOTH the boom and deck attachment points. -
Page 6: Check Line Tension
Check Line Tension Set the boom height to the lowest normal sailing position and snug up the vang. Locate the boom on the centerline. Temporarily run a line through a block or a shackle temporarily secured to the boom attachment point. Tie or tape the block or shackle to the boom if needed. - Page 7 If the line can not pass through the toggle, install an eye splice with a thimble in the end of the line. Follow the directions below to complete the installation. To attach hardware like a block or a shackle directly to the chainplates, use lacing line, which is more reliable than a poorly aligned shackle.
-
Page 8: Mounting Tips, Boom Attachment
Pad Eye Installation When installing pad eye’s in Balsa cored fiberglass, you must use the following Balsa Core procedure. 1. Drill a hole the diameter of the through bolt you intend to use through only the upper layer of the deck. If you drill all the way through, tape over inside hole. 2. -
Page 9: Rigging The Brake Brake Line Fixed
Rigging the Brake Brake Line Fixed If you want to be able to run the adjust- ing line back to the cockpit from the base of the mast, you have 2 options. Either use a block and tackle to pull the bail aft to tension the brake, or use a single line run to a line stopper and a winch. -
Page 10: Operation
Operation Using the Boom Brake is simple enough. Just adjust the tension on the Brake line to regulate the speed of the boom. Practice to get a feel of how this works. In light winds, you may want to let off on the adjusting knob to reduce friction. In winds over about 10 knots, the knob must be tightened. -
Page 11: Legal Information And Warranty
Van Breems, Inc., P.O. Box 2875 Saugatuck Station, Westport, Connecticut, 06880, U.S.A., tel 203 838 0375. Fax 203 838 0377 Martinus Van Breems, Inc. reserves the right to change all prices, hardware, and specifications without notice at any time. U. S. and Foreign patents pending. - Page 12 This licensing card will help us to provide you with product updates. Thank you very much, and please tell your friends about our products. Thank you for you selection of a Dutchman product. Please complete and return this warranty card as soon as possible. Thank you.
