9884 MONROE DR. DALLAS, TX 75220
RADIO INTERCOM SYSTEM
OPERATING INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions prior to use. Retain these instructions for
future reference. Heed all warning labels. Do not attempt to service this
product yourself. Refer to qualified personnel.
LIMITED WARRANTY
Audio Tech warrants to our authorized Distributor-Dealer that products
of our manufacture are free from defects in materials and workmanship
for one (1) year from date of installation to the home owner-user. For a
period of one (1) year the Distributor-Dealer that sold a defective prod-
uct will accept it for service and or replacement at the option of Audio
Tech at no charge to the home owner-user, providing the product has
not been misused, in commercial service, and was correctly installed
based on written instructions furnished by us with the product.
EXTENDED WARRANTY
After the one (1) year, for another two (2) years Audio Tech soley war-
rants to the User that it will repair or replace at their option any prepaid
defective product received at their offices in Dallas, Texas.
On receipt of a defective Master Radio-Intercom Unit and an advance
payment of $35.00 to cover the cost of handling, packaging, and return
transportation Audio Tech will REPAIR or REPLACE at their option the
defective unit with a factory re-manufactured unit and return-ship the
original or replacement unit within three (3) working days.
On receipt of a defective Speaker and an advance payment of $20.00
Audio Tech will REPLACE any defective speaker with a brand new
speaker of the same kind, and ship it within three (3) working days.
There are no other express or implied warranties. Audio Tech is not
liable for consequential or incidental damages related to the use or per-
formance of any defective product. The laws of some states are differ-
ent and your rights can be different depending on where you live.
Advertisement
Table of Contents
Summary of Contents for Audio Tech 462
- Page 1 EXTENDED WARRANTY After the one (1) year, for another two (2) years Audio Tech soley war- rants to the User that it will repair or replace at their option any prepaid defective product received at their offices in Dallas, Texas.
- Page 2 RADIO INTERCOM SYSTEM MODEL 462, 462X and 462Z The new Model 462 combination AM-FM Radio, and Intercom System with built- in Door Chimes is a sophisticated state of the art home entertainment and com- munications system that is easy to operate by everyone in the family. The 462X has built-in station tuning, and the 462Z also has a home automation relay that can be used to release a door lock.
- Page 3 This guarantees privacy at each Room Speaker. STATION TUNING-RADIO ON-OFF For the 462 system, Room and Patio speakers with the optional “ST” (Station Tuning) feature will have a Push to Tune label on the Volume Control. To turn the radio on, press the volume control knob and hold for approximately two (2) seconds.
- Page 4 -------------------------- 3 -------------------------- ROOM SELECTOR SWITCHES 1- 12 PLUS MASTER UNIT Each switch controls a Room Speaker. Each switch has three (3) positions, INT-ONLY, MON, and RAD-INT. 1. When the INT-ONLY (Intercom Only) position is selected and the numbered room speaker is on the speaker will receive all intercom communications and the door chimes.
- Page 5 -------------------------- 4 -------------------------- DOOR TALK When the Door Talk button is pressed and held in at the Master Unit or any Room Speaker you can converse with a person at a door station. When you release the Door Talk button the person at the door can speaker hands free for 15 seconds.
- Page 6 -------------------------- 5 -------------------------- COMPACT DISC (CD) PROGRAM Press to activate the CD Player as the source of program. The LED red light indicator above the button will light when the CD Player is on. Please refer to “BUILT-IN CD PLAYER” section on page 7 for more information. AUXILIARY (AUX) INPUT Press to activate the Aux input as the source of program.
- Page 7 -------------------------- 6 -------------------------- MEMORY and TIME SETTINGS (MEM/TIME SET) To store a radio station (AM or FM) in memory buttons 1-6 you first select the desired AM or FM Station, and the frequency will show on the display. A good technique is to enter your favorite AM or FM station on button one, your next favorite station on button number two, etc.
- Page 8 -------------------------- 7 -------------------------- RADIO AUTOMATIC ON-OFF (AUTO) When the Auto button is pressed and immediately released the red LED above the button will light and the automatic function will become active and remain indefinitely active 24 hours a day until the Auto button is pressed to cancel the automatic on and off function.
- Page 9 -------------------------- 8 -------------------------- OPTIONAL EQUIPMENT and ACCESSORIES PATIO SPEAKERS An outside PATIO Speaker is a popular and frequently added additional speaker to the radio intercom system. The Patio Speaker operates the same as the in- door Room Speaker. Since the Patio Speaker can be distracting to neighbors after dark the speaker should be used with consideration, and when not in use the volume control on the speaker should be turned to the fully “OFF”...
- Page 10 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN THIS SYMBOL INDICATES THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE WITH THIS PRODUCT THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CAUSING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS PRODUCT 9884 MONROE DR.
