Pro ceed CVP2 Owner's Manual

Component video processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
CVP2
Component Video
Processor

Advertisement

Table of Contents
loading

Summary of Contents for Pro ceed CVP2

  • Page 1 Owner’s Manual CVP2 Component Video Processor...
  • Page 2 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Please read all instructions and precautions carefully and completely before operating your Proceed component. 1. ALWAYS disconnect your entire system from the AC mains before connecting or disconnecting any cables, or when cleaning any component. 2. This product is equipped with a three-conductor AC mains power cord which includes an earth ground connection.

  • Page 4: Table Of Contents

    ................. 10 software updatable ..................11 Front Panel ....................12 Rear Panel ....................13 Configuration 1: AVP2 & CVP2 ..............17 Configuration 2: AVP2/CVP2/PVP ............20 Configuration 3: AVP2/PVP/CVP2 ............23 Troubleshooting ..................27 Care and Maintenance ................28 U.S.

  • Page 5: Maximizing The Value Of Your Purchase

     performance upgrade notices We occasionally offer software updates to our products, providing new fea- tures and control options. In the case of the CVP2, these updates are easily done without even opening up the unit, via flash-memory. If they include fea- tures you would like to have, you can get them—if you know about them.

  • Page 6: Unpacking And Placement

    It is normal and perfectly safe for your CVP2 to run slightly warm. Be sure to ventilation allow 2 to 3 inches of clearance above it to allow heat dissipation through air circulation.

  • Page 7: Serial Number

    The serial number for your CVP2 is found on the rear panel of the unit. Please serial number note and record this number for your future reference. Having found the serial number, now would be a good time to fill out the reg- register your purchase! istration card.

  • Page 8: Operating Voltage& Frequency

    There are no user-serviceable parts within the unit. Please refer any problems to an authorized Proceed service center. The CVP2 can easily be powered by a normal 15-ampere AC mains line, as it draws only a few watts of power. If other devices are also powered from the same AC line, their additional power consumption should be taken into ac- count.

  • Page 9: A Word About Installation

    If you need or prefer to rack mount your CVP2, the necessary hardware is supplied with the unit. To use the rack mount kit, simply follow the instruc- tions on page 34.

  • Page 10: Special Design Features

    Special Design Features Congratulations on your purchase of the Proceed Component Video Processor (CVP2). We have gone to great lengths to ensure that the CVP2 remains “future-proof” even in these times of change. As a result, you will be able to enjoy the outstanding performance of the CVP2 for many years.

  • Page 11: Software Updatable

    “legacy” sources so that watching them does not become a huge disappointment after watching HDTV signals. Once again, the CVP2 works for you to both make the most of these legacy sources by trancoding them to interlaced component video with exceptional quality, while also handling the switching of up to four HD sources via its component inputs.

  • Page 12: Front Panel

    POWER INDICATOR This LED illuminates to indicate that power is being supplied to the CVP2. If this indicator is not lit, power is not being supplied to the unit. Check to make sure that the external power supply is connected properly, and...

  • Page 13: Rear Panel

    input 1 input 2 input 3 input 4 output input 5 input 6 RS-232 control 5V DV Pb/B Pr/R Csync Pb/B Pr/R Csync Pb/B Pr/R Pb/B Pr/R composite s video Pb/B Pr/R Csync to controller to AVP2 1A reg. WA R N I N G ! Use only with Use only with MADRIGAL...
  • Page 14 YP (composite available on C sync) If you choose to route the progressive output of a Proceed PVP through your CVP2, it must be connected to Component Input 3. See Configura- tion 3 for more details. COMPONENT INPUT 4 Component Input 4 is what most people would consider a “standard”...
  • Page 15 , and P respectively, read left to right. If the CVP2 has been configured instead to convert SDTV inputs to SDTV video, the connectors (as seen from the rear) provide G, B, and R respectively, read left to right. Sync signals are available on all three channels, as well as on the fourth connector (which may be used for composite sync in SCART connections).
  • Page 16 AC mains power to a smaller DC voltage prior to introduc- ing the power to the CVP2 itself. This power is then re-regulated within the CVP2 to provide extremely pure and clean power to all the CVP2’s critical circuitry.

  • Page 17: Configuration 1: Avp2 & Cvp2

    SDTV video formats, either for direct connection to a television or in preparation for further video processing. HDTV signals are passed through to the output of the CVP2. In this way, one can have a single connection to the display device, and enjoy one-touch selection of any A/V source on the AVP2 (without having to also select different video inputs on the television).
  • Page 18 DEFINE YOUR NEW A/V INPUTS IN THE AVP2 MENU SYSTEM Having told your AVP2 that there is now a CVP2 in the system, define your new source components as “buttons” on the AVP2 in the usual fash- ion, taking advantage of the new component input options that will be available in your menu system.
  • Page 19 CYCLE THROUGH STANDBY Cycling the AVP2 from standby back to operate will ensure that the RS- 232 connection between the AVP2 and the CVP2 is active. This will allow the two components to work together, as a single system.

  • Page 20: Configuration 2: Avp2/Cvp2/Pvp

    R S - 2 3 2 c o m m u n i c a t i o n s Configuration 2: AVP2/CVP2/PVP This configuration adds SDTV component video switching to the AVP2, transcodes all SDTV non-component video signals to interlaced SDTV compo- nent video, and routes the resulting signals to the Proceed PVP for conversion to progressive video.
  • Page 21 480/60i (NTSC) or 525/50i (PAL). DEFINE YOUR NEW A/V INPUTS IN THE AVP2 MENU SYSTEM Having told your AVP2 that there is now a CVP2 in the system, define your new source components as “buttons” on the AVP2 in the usual fash- ion, taking advantage of the new component input options that will be available in your menu system.
  • Page 22 CYCLE THROUGH STANDBY Cycling the AVP2 from standby back to operate will ensure that the RS- 232 connection between the AVP2 and the CVP2 is active. This will allow the two components to work together, as a single system.

  • Page 23: Configuration 3: Avp2/Pvp/Cvp2

    R S - 2 3 2 c o m m u n i c a t i o n s Configuration 3: AVP2/PVP/CVP2 This configuration converts all the legacy interlaced sources input to the AVP2 to progressive signals (either 480/60p or 525/50p, respectively), while adding HD-capable component switching capability that integrates seamlessly with routine operation of the AVP2.
  • Page 24 DEFINE YOUR NEW A/V INPUTS IN THE AVP2 MENU SYSTEM Having told your AVP2 that there is now a CVP2 in the system, define your new source components as “buttons” on the AVP2 in the usual fash- ion, taking advantage of the new component input options that will be available in your menu system.
  • Page 25 INPUT 3 Using high quality 75Ω cables, connect the progressive component out- put of the PVP to Component Input 3 of the CVP2. This will make all of the legacy sources connected to the AVP2 available to the CVP2, but in progressive form.
  • Page 26 CYCLE THROUGH STANDBY Cycling the AVP2 and the PMDT from standby back to operate will en- sure that the RS-232 connection between the AVP2 and the CVP2 is ac- tive, as well as the PHAST connection between the AVP2 and the PMDT/ PVP.

  • Page 27: Troubleshooting

    Troubleshooting Your Proceed CVP2 has been designed to deliver many years of satisfaction. Its flexibility requires a bit of attention when first configuring the system, but results in tremendous ease of operation in daily use. It has been our experience that most difficulties encountered with the CVP2 are due to improper initial setup.

  • Page 28: Care And Maintenance

    Care and Maintenance To remove dust from the cabinet of the CVP2, use a feather duster. To remove dirt and fingerprints, we recommend isopropyl alcohol and a soft cloth. Caution! Always apply the isopropyl alcohol to the soft cloth and then wipe the CVP2 with the dampened cloth.

  • Page 29: U.s. And Canadian Warranty

    U.S. and Canadian Warranty ® 90-day limited warranty This Proceed product is warranted to be free from defects in material and workmanship under normal use for a period of ninety (90) days from the date of purchase. To extend the warranty of this Proceed product, return the warranty registration card along with a copy of the original receipt of purchase to Mad- rigal, Inc., P.

  • Page 30: Obtaining Service

    Obtaining Service We take great pride in our dealers. Experience, dedication, and integrity make these professionals ideally suited to assist with our customers’ service needs. If your Proceed component must be serviced, please contact your dealer. Your dealer will then decide whether the problem can be remedied locally, or whether to contact Madrigal for further service information or parts, or to ob- tain a Return Authorization.

  • Page 31: Specifications

    Specifications Pass-through gain +0.0 dB, - 0.2 dB Pass-through frequency response +0.25 dB, - 3.0 dB to 70 MHz less than 0.2% Pass-through differential gain less than 0.2° Pass-through differential phase ±0.2 dB Decode/encode path gain Decode/encode path frequency response Composite &...
  • Page 32 less than 5 W Power consumption See “Dimensions” Overall dimensions: 12 lbs. (5.5 kg) Shipping weight: For more information, see your Proceed dealer, or contact: Madrigal, Inc., P.O. Box 781, 2081 South Main Street, Middletown, Connecticut 06457 USA Telephone (860) 346-0896 FAX (860) 346-1540 If purchased in the United States or Canada, the warranty on this Proceed product is owner-transferable.

  • Page 33: Dimensions

    Dimensions...

  • Page 34: Cvp2 Rack Installation

    4 pieces screw for rack bracket to CVP2 (#4 phillips scres) Assemble in the following sequence: 1. Attach one rack bracket to each side of the CVP2 using two #4 Phillips screws per side. 2. Position the CVP2 on the rack.
  • Page 36 Madrigal, Inc. 2081 South Main Street, P.O. Box 781 Middletown, Connecticut 06457 USA Telephone: (860) 346-0896 Fax: (860) 346-1540 http://www.madrigal.com is a registered trademark of Madrigal, Inc. a Harman International company 630671-1 © 7/2002 Madrigal, Inc. All rights reserved. Printed in U.S.A.
