INSTRUCTION MANUAL

BLP-890/ BLP-840 CUSTOM NAVIGATION SYSTEM

Table of Contents

Need help?

Do you have a question about the BLP-890 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bluepower BLP-890

Page 1 INSTRUCTION MANUAL BLP-890/ BLP-840 CUSTOM NAVIGATION SYSTEM...
Page 3: Table Of Contents
___________________________ Content: Precaution ............................2-3 Features...............................4 Location and function of controls.......................5-7 Card remote control..........................8 Getting started............................9 Tuner operation......................,....10-11 Playback controls(CD/USB/SD).....................12-13 Playing disc............................14-15 USB/SD operation..........................16 iPod operation..........................17-18 Bluetooth operation........................19-20 Other mode............................21 Navigation............................22-24 DVB-T..............................25-26 Settings............................27-32 Installation............................Troubleshooting............................35 Specifications............................36...
Page 4: Precaution
___________________________ Safety Precautions Thank you for purchasing this product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this manual in a safe place for future reference. 1.
Page 5: Precaution
_____________________________ Safety Precautions Please power off this unit at once and send it back to the after-sales service center or the dealer /distributor you purchased from if one of the following symptoms is found: MUTE (a). No audio output; (b). No image output; (c).
Page 6: Features
Features _________________________________ DVD-R/RW compatibility It is possible to playback DVD-R/RW discs recorded with the video format and Video Recording format. Video CDs featuring PBC compatibility It is possible to playback Video CDs featuring PBC (playback control). WMA and MP3 compatibility It is possible to playback WMA and MP3 files.
Page 7: Location And Function Of Controls
_________________________ Location and function of controls BLP 890 Zone A Zone B Zone C PIC 1 1. Disc slot 2. SD card slo GPS card slot 4. Eject button SRC button -- Short press to change sources; Long press to return to main source list/homepage 6.
Page 8 Location and function of controls _________________________ Zone A Zone B Zone C PIC 2 1. Disc slot 2. SD card slo GPS card slot 4. Eject button SRC button -- Short press to change sources; Long press to return to main source list/homepage 6.
Page 9: Location And Function Of Controls
Location and function of controls ______________________...
Page 10: Card Remote Control
Card remote control __________________________ Card remote commander The remote control can operate within a distance of 3~5 meters. 30˚ 30˚ Caution: 1. Service life of the battery is around 6 months under normal conditions. If the remote control can not be operated normally, the battery should be replaced with new one in time. 2.
Page 11: Getting Started
Getting Started __________________________ Resetting the unit Before operating the unit for the first time, or after replacing the car battery or changing the connections, you must reset the unit-- Press the reset button (with a pointed object, such as a ball-point pen.) Note Pressing the reset button will erase the clock setting and some stored contents.
Page 12: Tuner Operation
Tuner Operation _______________________ Touch “RADIO” Touch “SOURCE LIST”, then “RADIO”. The radio reception display appears: PIC 7 PIC 6 -- Go back main source list -- Enter setting interface -- When RDS on, touch to open PTY list(see PIC 7 –...
Page 13: Tuner Operation
Tuner Operation (Advanced) _______________________ Storing automatically 1. To change the band, touch “Band”, then select the desired band 2. Touch “Preset List,” then “Search”, the unit stores stations in order of frequency in the preset list (button 1 to button 5). Storing manually 1.
Page 14 Playing discs _________________________ Insert a disc Insert a disc into the slot, and the unit will change to disc mode automatically. Note Please confirm whether there is a disc in the unit before you insert another one. The unit will exit current playing source and enter DVD mode when one disc is inserted.
Page 15: Playback Controls(Cd/Usb/Sd)
Playback controls(CD/USB/SD) ___________________________ Touch the display if the playback controls are not shown. PIC 13 PIC 14 – Go back to main source list -- Enter settings main menu interface -- Close/ go back to previous interface -- It shows track name; -- It shows artist name;...
Page 16: Playback Controls
Playback controls _______________________ Touch the LCD screen, the playback controls menu interface appears: PIC 11 PIC 12 -- Return to main source(homepage) -- Exit menu interface and return to disc playback mode -- Enter settings interface where user can make settings -- Enter information interface where user can check disc information -- Enter digital keyboard interface for selecting sections by directly input the numbers -- Play or to pause the current selectedd program...
Page 17: Usb/Sd Operation
USB/SD Operations ________________________ Note • Connect the USB device after starting the engine. Depending on the USB device, malfunction or damage may occur if it is connected before starting the engine. • A large-sized file may take time to star playing back. Playing a SD card Remove the cap from the SD card slot, and insert the card to the SD card reader slot, playback starts automatically.
Page 18: Ipod Operation
iPod Operations _________________________ Playing an iPod Reduce the volume on this unit. Remove the cap from the Ipod connector, and connect the iPod to the connector. Playback starts automatically. If an iPod is already connected, to start playback, touch “SOURCE LIST,” then “iPod” Controls and indications during playback: PIC 15 PIC 16...
Page 19 iPod Operations ____________________________ Operating an iPod directly You can directly operate an iPod connected to this unit. During playback, touch “Video”, the play mode changes to resuming mode. To close the play menu, touch “Music” Note • To output video to this unit, you need to activate the video output of iPod. •...
Page 20: Bluetooth Operation
Bluetooth Operation _________________________ Pairing • Pairing is required only the first time you connect to a Bluetooth device(cellular phone, etc.). • To pair this unit to a Bluetooth device, you need to enter password to the Bluetooth device. The password is 0000. Passkey may be called “passcode,” “PIN code,” “PIN number,” “password,” etc. depending on the Bluetooth device.
Page 21: Bluetooth Operation
Bluetooth Operation ________________________ 2. Touch “Dial Pad”, the number input display appears(see PIC 18 PIC 18 Touch the number keys to enter the phone number, then touch to make a call. To delete an entered number, touch The call is made and the calling display appears until the other party answers. During talking through the car Bluetooth, touch to switch calling between your mobile phone and the car raido.
Page 22: Other Mode
Other Modes __________________________ AV mode External peripheral devices with RCA audio andd video outputs can be connected with the unit. For more details, please refer to < Electrical Connections Overall Diagram >. Front Camera / Rear Camera External camera devices with video output can be connected with the unit. For more details, please refer to <...
Page 23: Navigation Operation
Navigation Operation __________________________ 6. After completing the touch screen calibration, the system will memorize the calibration result which would not lose even power off. It is unnecessary to calibrate every time power on. 7. Every product have already been calibrated before delivery. Navigation setup 1.
Page 24: Navigation
Navigation Operation __________________ Screen Setup Touch “Touch Screen” on the Setup interface( ). The Screen setup interface appears:. PIC 21 PIC 25 PIC 26 Touch “Brightness color” on , the brightness color interface( see ) appears: PIC 25 PIC 26 Touch to adjust brightness or contrast.
Page 25 Navigation Operation ______________________ Time and date Touch “Time” on the Setup interface(see ). TheTime Setup interface appears: PIC 21 PIC 29 Touch the keys to setup Month, Day, Year, Hour and Minute. Touch to select time zone System Setup Touch “System” on the Setup interface(see ).
Page 26: Dvb-T
DVB-T ______________________ DVB-T Antenna Installation Guide: You can mount the DVB-T antenna inside of the car or outside of the car: • Fix the DVB-T antenna to a suitable position on the dashboard behind the windscreen, and make sure no obstacles on the signal receiving direction. •...
Page 27 DVB-T _____________________ PIC 34 PIC 33 -- Exit menu interface -- Confirm the selected frequency -- Slide upward/downward to display frequencies PIC 36 PIC 35 -- Enter to set preferred TV OSD language -- Enter to set Ratio(16:9) and Format (Auto/Letterbox/Pan &Scan) -- Enter to set TV backgrond colors -- Enter to select the country where you are -- Enter to check TV system status...
Page 28: Settings
Settings __________________________ Touch “SETTINGS” on the top menu, the main settings interface appears: -- Go back to Main Source interface -- Enter steering wheel setup interface -- Close current interface/go back to last interface PIC 37 -- Enter time setup interface (see PIC 38 -- Enter radio setup interface(see PIC 39...
Page 29 Settings __________________________ Radio Touch “Radio” on the main settings interface ( ), the radio setup interface appears:. PIC 37 -- Go back to Main Source interface -- Close current interface/go back to last interface -- Go back to last interface without saving new settings -- Save new settings and go back to last interface...
Page 30 Settings ___________________ Language Touch ”Language” on the main settings interface ( ), the language setup interface appears: PIC 37 -- Go back to Main Source interface -- Close current interface/go back to last interface -- Go back to last interface without saving new settings -- Save new settings and go back to last interface...
Page 31 Settings _________________________ Sound - EQ Touch “EQ” on the main sound settings interface ( ), the EQ setup interface appears: PIC 42 -- Go back to Main Source interface -- Close current interface/go back to last interface -- Go back to last interface without saving new settings -- Save new settings and go back to last interface...
Page 32 Settings _____________________________ Touch “Level Speaker” on main settings interface( ), the level speaker setup PIC 37 interface appears: PIC 46 PIC 45 -- Go back to the Main Source interface -- Close current interface/go back to last interface -- Reset the settings -- Go back to last interface without saving new settings -- Save new settings and go back to last interface Touch...
Page 33: Steering Wheel Controls
Steering wheel controls _____________________________ Touch ”STEER” on the top in main settings interface( ), the steer setup interface appears: PIC 3 PIC 48 After connecting the steering wheel control wires to the car, operate as followings: Press a button on steering wheel, you will see a voltage value shows on the interface, select the corresponding button from the interface (for example, you press on the steering wheel, the voltage value will show here...
Page 34: Troubleshooting
Troubleshooting _____________________ The following checklist can help you solve the problems which you may encounter when using the unit. Before consulting it, check the connections and follow the instructions in the user manual. Problem Possible cause Solution General Car ignition is not on. Turn your car key in the ignition.
Page 35: Specifications
Specifications _______________________ General Digital TFT LCD Power supply 12V DC (10.8V-16V) Display resolution 800(W) x 480(H) Best voltage 14.3V, Active area (mm) 137.52(H) x 77.22(V) negative ground Maximum power output 60Wx4 channels Screen size (inch) 6.2/7.0 (Diagonal) Continuous power output 80Wx4 channels (4 Brightness ≥350 nits...

This manual is also suitable for:

Blp-840
