Summary of Contents for Jensen BT360
Page 1
JENSEN BT360 ’ ’ Installation and User Manual...
Page 3
Bluetooth Car Kit User Manual Preface This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. Version 2.0, March 2009 Trademarks Other product names mentioned herein are used for identification purposes only...
Perface... i Identifying components...1 Installing the junction box...2 Installing the Components...5 Installing the microphone & speaker... 5 Installing the remote control ...6 Product overview and features ...7 Using the remote control...9 Pairing phones... 10 Operation with multiple paired phones ... 12 Resetting the Car Kit...
Bluetooth Car Kit User Manual This section demonstrates how to set up and install the Bluetooth Wireless Car Kit into a vehicle. Identifying components Unpack the Car Kit package and ensure the following items are included. Remote Control Part # 31102000 Speaker Part # 31092430 Some items may vary slightly from the picture shown.
Installing the junction box This Car Kit is designed to work with a 12 - 24-volt vehicle power supply. Refer to the following to install the junction box in a vehicle. 1. Locate a suitable place inside the car to mount the junction box.
Bluetooth Car Kit User Manual Connecting the power supply The following illustration demonstrates how to connect the Car Kit’s power cables to the vehicle’s electrical system. Power cables Important! The Blue cable must be connected to the +12/24-volt switched ignition to enable the Car Kit to go into standby mode. Do not connect the Blue cable to the +12/24-volt constant connection.
Connecting Components The following illustration shows where to connect the devices. Do not connect the components until you have followed the next steps and have finalized your installation. CONNECT THE POWER HARNESS LAST. Speaker Microphone Control Module Speaker Microphone Junction box Control Module The control module should be located within reach and view of the driver.
Bluetooth Car Kit User Manual Installing the Components Before installing the components, take note of the following: • Make sure that the cables can reach from the each component to the Junction Box. If the cable is too short, relocate the component. Do not lengthen the cable. •...
Installing the remote control Find a suitable place for remote control that will provide the best visibility. Remove dust and grease from the surface and firmly press BT360 control in place with the sticker pads provided.
When properly installed, the Car Kit enables you to talk freely to the other party on your mobile phone. The BT360 uses the latest Bluetooth Technology available and allows today’s phones with A2DP music transfer the ability to play through your cars stereo without any connection to it.
Page 12
WWW.JENSEN.COM. The BT360 is designed to be on when ever your car is turned on. The feature allows “AUTO PAIRING” which means when you leave the vehicle and return, as soon as you start the vehicle the BT360 will look for your phone, re-pair, and the Hands free system will be ready to go! You will not need to re-pair your phone each time.
Bluetooth Car Kit User Manual Using the remote control The BT360 is operated using a wired remote control: Control Module Functions Volume Press during operation to increase or lower the volume. Up/Down Answer/ Dial Press to answer a call. For call waiting, press to answer a Last Call second call during a call.
Press to play next or previous song. Song Pairing phones To use a phone with your BT360, you must first pair the phone and receiver 1. DO NOT attempt to pair a phone while driving. Park your car and with the ignition on proceed.
Page 15
4. Select the BT360 from the list of Bluetooth devices on your phone. 5. Enter the passcode: 1234. when prompet on your phone. 6. The Display on the BT360 will show the phone model or name and a connected sign when the pairing is established. Nokia N95...
BT360 performs another search and establishes a connection with the most recently connected phone, in this example phone B. Resetting the Car Kit If for any reason you need to reset the BT360 back to the factory settings and delete all paired phones, follow these instructions. Master Reset...
Bluetooth Car Kit User Manual The car kit only connects to one phone at a time. However, it can be paired with up to 4 phones. Using Master Reset function will delete all pairings. To reset press and hold the Volume up and down keys at the same time.
Find a radio station on your car stereo that does not already have anything playing on it. This will be the station you will set the BT360 to transmit the A2DP Music on so you can hear it on your stereo.
3 set stations you have selected, M1, M2, M3. NOTE: The music will be muted automatically when a calls comes in. Calls are heard only through the BT360 Speaker, not the car speakers. Last Number Re-Dial Press and hold the Send key “...
Using the Multimedia buttons to Play, Pause, Stop and jump to Next or Previous song. Note: For some mobile phones, users will need to turn on the MP3 before BT360 can play the Media function. Notes on using voice recognition Voice recognition is a feature of your phone which enables you to dial a number by simply saying a pre-recorded “voice tag”.
Updating the Bluetooth Software The BT360 has the ability to be upgraded to give you many years of use and to be compatible with newer versions of phones. There is a complete manual that explains the upgrade process available at WWW.JENSEN.COM.
Page 22
BT Update USB MODE After upgrading, please turn the unit off and on again by turning your cars ignition on and off.
Bluetooth Car Kit User Manual My mobile phone can’t make a connection. When my mobile phone is ringing and I adjust the volume, the call is disconnected. My phone doesn’t recognize my voice tags for voice recognition. (Note: Not available on all phones.
