Summary of Contents for Jens of Sweden MP-X
- Page 1 MANUAL MP-X V E R S I O N 1 . 2...
- Page 2 English...
-
Page 3: Table Of Contents
Table of Contents ... 24 BUTTONS AND CONNECTIONS Buttons Key... 26 LED Blink Key... 27 ... 28 BASIC OPERATIONS Connect the Player to a Computer... 28 File Management Using a Removable Disk ... 29 Format... 30 Disconnecting the Player From a Computer ... 31 Firmware Upgrade ... -
Page 4: Buttons And Connections
MODE PLAY / PAUSE VOLUME (+) REWIND FORWARD VOLUME (-) SHUFFLE EQUALIZER... - Page 5 EARPHONES JACK RESET USB PORT...
-
Page 6: Buttons Key
BUTTON KEY Button Name Short Press Play / Pause Play / Pause Change EQ Shuffle On (Play Random) Volume + Increase the volume Volume - Decrease the volume Skip to previous track Skip to next track Long Press On / Off Change to normal EQ Off (Play In Order) Increase the volume continuously... -
Page 7: Led Blink Key
LED BLINK KEY MP3 Mode RED & BLUE LED blink alternately Transmitting Data BLUE LED blinks continuously Low Battery Step 1 : Red LED blinks regardless if LED is ON or OFF Step 2 : Red LED ON, the device does not function. Step 3 : Power Off * Recharging required for Step 1 and after. -
Page 8: Basic Operations
CONNECT THE PLAYER TO A COMPUTER 1) Turn on the player. Connect the USB port on the player to the USB port on the computer using the provided cable. 2) After the message ”Found New Hardware” the neccessary USB drive is installed. *The installation screen may not be visible. -
Page 9: File Management Using A Removable Disk
FILE MANAGEMENT USING A REMOVABLE DISK 1) After connecting the player to your PC, run Windows Explorer. 2) After selecting a file or a folder to save, drag & drop the selected file or folder to the desired folder in the removable disk drive. -
Page 10: Format
FORMATERING If there is a problem recognizing USB, or the product malfunctions, try to reser it (this is done by pressing the Reset-button on the back of the player). If the problem is not solved, you may format it to stabilize the player. -
Page 11: Disconnecting The Player From A Computer
DISCONNECTING THE PRODUCT FROM THE COMPUTER 1. Double-click the “Safely Remove Hardware” icon in the system tray at the lower right corner of the PC screen. 2. Select a USB device and click the <Stop> button. When the message “Safely Remove Hardware?” is displayed, click the <OK> button and then unplug the USB cable from the product. -
Page 12: Firmware Upgrade
FIRMWARE UPGRADE Firmware upgrade is needed to keep the product up-to-date. 1. Download the latest YUF file from our web page. 2. Connect the product to your PC. 3. Copy the downloaded YUF file to the root directory of the product. 4. -
Page 13: Product Specifications
PRODUCT SPECIFICATIONS Classification Option File File File File File MS DRM Interface USB version Interface Supported OS File System Audio post Equalizer Processing Specification MPEG1, 2, 2.5 Layer3(8~320Kbps, VBR) Version 9 (32~192Kbps) Audio ASF - OK Ogg Vorbis (Q1–Q10) PD-DRM 9.0 USB 2.0 (High Speed : 25 Mbps, transmission speed : 480Mbps), mass storage Windows 98 SE / ME / 2000 / XP and MAC 9.2... -
Page 14: Product Features
forts. Output power S/N ratio Frequency Range Distortion Battery PRODUCT FEATURES FEATHERLIGHT DESIGNED FOR OUTDOOR SPORTS HISPEEED SUPPORT MP SHUFFLE RESUME VARIOUS EQ TONE PRESETS SUCH AS NORMAL USER FRIENDLY INTERFACE BUILT IN LITHIUM POLYMER BATTERY PPGRADEABLE FIRMWARE 2.0 - Music play Music play Music play... -
Page 15: Using The Player
USING THE PLAYER 1. MP3 PLAY / PAUSE Press the Play / Pause button briefly to toggle between Play and Pause. 2. MOVE TO THE NEXT / PREVIOUS FILE Press the REW / FF button to move to the next / Previous track. 3. -
Page 16: Navigation Mode - Folder
5B. NAVIGATION MODE - FOLDER when this mode is active you will navigate in one folder at a time until you switch folder. (See instructions below). This mode only works when Shuffle is turned off. If to Shuffle is turned on the Navigation Mode will automatically switch to “All”. -
Page 17: Miscellaneous
the player is connected to the computer the battery will automatically start charging. The battery will be charged as long as it’s connected to the computer. You can also charge the battery using a USB Charger which is available for purchase as an accessory at www.jensofsweden.com. While the battery is beeing charged the red LED is ON. -
Page 18: Earphone-Related Cautions
EARPHONE-RELATED CAUTIONS TRAFFIC SAFTEY Do not use the earphones while riding a bike or driving a car or a motorcycle. It may cause a hazard by imparing your ability to hear what’s going on around you, and is a violation of the law in certain areas. Even walking or using a pedestrian crossing while wearing the earphones and using the product at high volume can be dangerous. -
Page 19: Troubleshooting
TROUBLESHOOTING Q. The product does not power on. A. The battery might be completely discharged. Connect the product to a USB port of your PC to see if the power comes on. Q. The power goes off automatically. A. When paused, the unit will turn off automatically in 1 minute. Or if the battery is low, the device will power off automatically. -
Page 20: Limited Consumer Guarantee
LIMITED CONSUMER GUARANTEE This limited guarantee applies to purchasers of products from JOS AB. If any party who resells this prod- uct after it has left the ownership of JOS AB issues any guarantee other than this one then the guarantee that was issued most recently will apply. - Page 21 4) This guarantee does not cover deterioration of the product that may be regarded as being due to normal wear. Nor does the guarantee cover the following situations: a) any faults that are due to exposure of the product to moisture, liquids, extreme temperatures or variations in temperature, chemical products, excessive external force, software modification or force majeure and which are not directly caused by material defects, design defects or faulty workman- ship,...
- Page 22 www.jensofsweden.com...
