Setting the Standard in Mobile Power
Instruction Manual for Model
BD - 400SV
BELT DRIVEN 3600 RPM GENERATOR
Manufacturing of: Vehicle Mounted Generators • Hydraulic Generators
P.O. Box 582 • Chester, NY 10918 • 845-469-9151 • Fax: 845-469-7871 • Web Site/E-mail: www.fabcopower.com
Advertisement
Related Manuals for Fabco Power BD - 400SV
Summary of Contents for Fabco Power BD - 400SV
- Page 1 Setting the Standard in Mobile Power Instruction Manual for Model BD - 400SV BELT DRIVEN 3600 RPM GENERATOR Manufacturing of: Vehicle Mounted Generators • Hydraulic Generators P.O. Box 582 • Chester, NY 10918 • 845-469-9151 • Fax: 845-469-7871 • Web Site/E-mail: www.fabcopower.com...
- Page 2 Fabco Power Instruction Manual GENERAL INFORMATION MODEL: BD-400SV GENERATOR .... BRUSHLESS GENERATOR .... 3600 (60 Hz) GENERATOR VOLTAGE .... 120 or 120/240 MOTOR STARTING .... 300% SURGE VOLTAGE REGULATOR .... INHERENT OUTPUT .... 3750 WATTS CONTINUOUS 4000 WATTS PEAK AT 100°F OIL TEMPERATURE...
- Page 3 Fabco Power Instruction Manual Initial Installation and Start-Up Be sure you set the speed of the generator at approximately 62.5 HZ or 3750 RPM with NO electrical load on the generator. By using this setting you will have approximately 60HZ (cycles) or 3600 RPM when you are running at full rated load.
-
Page 4: Technical Information
Fabco Power Instruction Manual TECHNICAL INFORMATION These self-excited and self-regulating generators, although overall dimensions have been reduced to a minimum, are designed for high-level electrical performance and the maximum in operating reliability. PRELIMINARY CHECKS: Before touching the machines, perform a thorough and in depth visual inspection, checking that components are correctly connected up and that no cables or terminals are broken or loose. - Page 5 Fabco Power Instruction Manual • Page 5 •...
- Page 6 Fabco Power Instruction Manual • Page 6 •...
-
Page 7: Troubleshooting
Fabco Power Instruction Manual TROUBLE SHOOTING PROBLEMS CAUSES REMEDIES ALTERNATOR EXCITATION Low Speed 1. Check RPM and set at nominal FAILURE value. Faulty capacitor 2. Check and replace. Faulty winding 3. Check that winding resistance is as shown in the tables.
