Meade Wireless Telescope Server
Setup Guide
Thank you for purchasing the USB device server Meade Wireless Telescope Server (this product).
This setup guide, "Meade Wireless Telescope Server Setup Guide", provides information on how to configure and use this product in a network environment.
Before setup, please read carefully the "Safety instructions" in the online manual included in the CD-ROM to properly configure this product.
English
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WTS 1.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Meade WTS 1.0

  • Page 1 Thank you for purchasing the USB device server Meade Wireless Telescope Server (this product). This setup guide, “Meade Wireless Telescope Server Setup Guide“, provides information on how to configure and use this product in a network environment. Before setup, please read carefully the “Safety instructions“ in the online manual included in the CD-ROM to properly configure this product.

  • Page 2: Technical Data

    • WPA-PSK(TKIP/AES) Ethernet. • WPA2-PSK(AES) This is the first step MEADE Europe is taking in terms of • Share USB Devices over an Ethernet Network development of our own products for convenient observation • Max. number of USB connections is 15 (including optional in the amateur astronomical sector.
  • Page 3 This MEADE WTS 1.0 is the ideal solution for sharing your Supported Software: astronomical devices in your wireless network. It supports the • Meade Autostar Suite including Envisage remote wireless access of the following devices: • The Sky • Stellarium MEADE DSI 1 •...

  • Page 4: Name Of Parts

    Stand Power Supply Meade Virtual Link User‘s Guide CD-ROM (Meade Server Setup CD) · When the product is placed in the horizontal (side) position, please use the rubber feet provided to prevent the unit from sliding. Place one on each corner.
  • Page 5 Safety instructions are provided in the readme file on the Meade Server Setup CD. Be sure to read them before using this product. - Safety instructions regarding the radio Frequency emissions Please note the following instructions: - Do not use this product near medical devices such as a heart pacemaker. The RF energy generated by this product may interfere with the operation of these devices and may threaten one‘s life.
  • Page 6 WTS in AdHoc mode. To communicate with this product in AdHoc mode, the wireless setting on the PC must be the network cable same as the WTS. Meade Wireless • Configuration via Windows “Connect now“ Telescope Server This product supports “Windows Connect Now“, which is one of the functions installed in Windows XP SP2.
  • Page 7 Step 1: Connect this product to the network · If this product has been used in another network, reset it to factory Connect the power supply to this product, and then insert default prior to setup (See page 14). the AC Plug into the electric outlet. The following items are necessary for the setup.
  • Page 8 Please insert the Device Server Setup CD into your Windows PC. Please select Meade Server Setup from the menu. · Select the network connection type. Click Wired for a wired network. This Setup Guide explains how to configure with a wired...
  • Page 9 · When in a Windows XP environment (SP2 or higher), the following Read the agreement and click Yes to accept. message will be displayed. Select Yes. · The User Account Control screen is displayed when configuration is performed on Windows Vista. Select Continue. Select this product and click next.
  • Page 10 Detailed Config and configure each setting. For Detailed Config, please refer to the online manual. If you are going to use Meade Wireless Telescope Server with a network cable instead of wirelessly, upon comple- ting the configuration, check Skip wireless configuration and click next.
  • Page 11 Yes and click Finish at thefollowing screen. The MEADE WTS 1.0 will be placed on or next to the telescope. Via an active (power supplied) USB Hub (optio- nal) all telescope specific and camera specific USB Ports can be connected to the WTS.
  • Page 12 USB- Appliances attached. When buying a powered USB Hub it should have the following LOGO: LX200 (flat cable Art.: 0745810; #507 serial cable for LX200) Connect your USB-Hub with the free USB port of your MEADE WTS 1.0.
  • Page 13 Connect the USB devices to be shared over the network Connect Meade WTS 1.0 with the powerline. along with this product via an USB cable. The initial configuration of this product is complete.

  • Page 14: Customer Support

    Push and hold the Reset switch while re-inserting the AC plug into the electric outlet. Continue pressing the switch. The Status LED(Orange) will light when the factory default Meade Instruments Europe configuration settings have been restored. Release the GmbH & Co. KG Reset switch.
  • Page 15 Warranty The period of warranty is 2 years, beginning on the day of purchase. Please keep the cash receipt as evidence of purchase. Devices which become defective during the warranty period can be returned to the dealer where the device was bought. The repaired device or a new one will then be returned to you.
  • Page 16 Meade Instruments Europe GmbH & Co. KG Gutenbergstr. 2 · DE-46414 Rhede www.meade.de...
