Summary of Contents for Pioneer Air Systems PHL Series
- Page 1 HEATLESS REGENERATIVE DRYERS PHL SERIES Pioneer Air Systems Inc 210, Flatfork Road, Wartburg, TN - 37887 Tel. : (423) 346-6693 Fax : (423) 346-3865, (423) 346-7522 Email : sales@pioneerair.com Internet Address: http://www.pioneerair.com...
-
Page 2: Receiving And Inspection
Options and custom equipment may not be included in this manual. Pioneer Air Systems, Inc. was founded in the spring of 1980 amidst a deep recession in American industry. As pioneers in the compressed air industry, Pioneer engineers and designers boldly faced manufacturing challenges, which their competitors ignored. -
Page 3: Standard Features
INSTALLATION Location Locate your Pioneer PHL series dryer on a level floor free from vibrations and in clean surroundings. Although the dryer is a freestanding package, it may be secured by bolting the dryer base to the floor. Allow approximately three feet on each side of the dryer for ease of connecting and maintaining the dryer. - Page 4 Filtration All regenerative desiccant dryers are designed to remove water in the vapor phase. The possibility of liquid carry over to the desiccant dryer must be avoided. A coalescing pre-filter will eliminate the carry over of droplets and aerosol-sized mists of both liquid water and compressor lubricant. The use of a Pioneer coalescing filter (CS Series) will enhance the dew point depression capability of the dryer.
- Page 5 DIP Switches There are two DIP switches on the PHL electronic board located inside the electrical enclosure. One is a 4-pin switch; the other is a 6-pin switch. When the switch is on the same side of the pin and the number, it is ON. Explanation of 4-pin switch: 50 Hertz 60 Hertz...
-
Page 6: Operation
OPERATION The Pioneer PHL Series dryer is specifically designed to remove moisture in vapor form. The dryer's Electronic Sequence Module is fully automatic, alternately cycling gas flow through the dryer's twin desiccant towers. -
Page 7: Maintenance
-100 F PDP operating sequence (optional)- In systems rated for -100 F PDP the time cycle is reduced to five minutes. Actual drying time per tower will be two and a half minutes. The actual purge time will be one minute and fifty-five seconds. - Page 8 Desiccant replacement and installation Use only Pioneer Activated Alumina -100 F in your PHL Series. Remove contaminated desiccant from each vessel through the desiccant "drain port" located near the bottom of each vessel. Pour new desiccant into the indicated "fill port" located near the top of each vessel. Allow adequate space above the desiccant bed to permit bed motion and expansion during drying.
- Page 9 MAINTENANCE SCHEDULE/CHECKLIST Maintenance Contracts- Pioneer and its network of distributors offer yearly maintenance contracts for worry- free operation. Contact Pioneer Air Systems at 423-346-6693 for details. Frequency* Action Method Inspect pre-filter and after filter for dirt, oil, 2-3 days after start-up...
-
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem Cause Remedy 1. Excessive inlet flow 1. Reduce flow to rated capacity 2. Excessive inlet temperature 2. Inspect, repair, or replace upstream aftercooler 3. Excessive water 3. Check upstream separator, pre-filter, and their drain traps; repair or replace 4.
