ICP Central Air CCA724GKA100 Technical Support Manual

TECHNICAL SUPPORT MANUAL
Two Stage Split System Air Conditioner
DANGER, WARNING, CAUTION, and
NOTE
The signal words
CAUTION, and NOTE are used to identify levels of
hazard seriousness. The signal word DANGER is
only used on product labels to signify an immediate
hazard. The signal words WARNING, CAUTION,
and NOTE will be used on product labels and
throughout this manual and other manuals that may
apply to the product.
DANGER -- Immediate hazards which will result in
severe personal injury or death.
WARNING -- Hazards or unsafe practices which
could result in severe personal injury or death.
CAUTION -- Hazards or unsafe practices which
may result in minor personal injury or product or
property damage.
NOTE -- Used to highlight suggestions which will
result in enhanced installation, reliability, or opera-
tion.
TABLE OF CONTENTS
Model Number Identification
R--410A Quick Reference Guide
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flash Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tech Labels (Expanded Data)
Cooling Multiplying Factors
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CCA7,HCA7,TCA7 Parts List
Exploded Drawings . . . . . . . . . . . . . . . . . . . . . . . . .
MODELS
CCA724GKA100 HCA724GKA100 TCA724GKA100
CCA736GKA100 HCA736GKA100 TCA736GKA100
CCA748GKA100 HCA748GKA100 TCA748GKA100
CCA760GKA100 HCA760GKA100 TCA760GKA100
(C,H,T)CA7
Safety Labeling and Signal Words
DANGER, WARNING,
. . . . . . . . . . . . . . . . . . . 2--3
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . 7--9
. . . . . . . . . . . . . . . . . . 10--32
33
34
. . . . . . . . . . . . . . . . 35--37
38--40
Signal Words in Manuals
The signal word WARNING is used throughout this
manual in the following manner:
WARNING
!
The signal word CAUTION is used throughout this
manual in the following manner:
CAUTION
!
Signal Words on Product Labeling
Signal words are used in combination with colors
and/or pictures on product labels.
WARNING
!
DEATH, PERSONAL INJURY, AND/OR PROPERTY
4
DAMAGE HAZARD
5
Failure to carefully read and follow this warning
6
could result in equipment malfunction, property
6 damage, personal injury and/or death.
Installation or repairs made by unqualified per-
sons could result in equipment malfunction, prop-
erty damage, personal injury and/or death.
The information contained in this manual is inten-
ded for use by a qualified service technician famili-
ar with safety procedures and equipped with the
proper tools and test instruments.
Installation must conform with local building
codes and with the National Electrical Code
NFPA70 current edition or Canadian Electrical
Code Part 1 CSA C.22.1.
WARNING
421 04 1701 00
March 2012
