- Page 1 Aqua I Series Softener Operation Manual Note: 1. Read all instructions carefully before operation. 2. Avoid pinched o-rings during installation by applying (provided with install kit) NSF certified lubricant to all seals. Rev 6,December 6, 2010...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Water Softener Gallon Setting Chart ..................2 System Specifications......................3 Introduction ..........................4 Programming .......................... 5 General Valve Installation ....................... 7 Start-up Instructions ....................... 7 System Configuration ......................8 Maintenance ........................... 9 Power Head Valve Exploded View ..................11 Power Head Parts List ...................... -
Page 3: Water Softener Gallon Setting Chart
Water Softener Gallon Setting Chart Water Softener Gallon Setting Chart Instructions: First select the chart for your model of water softener, then simply line up the number of people living in the home with the hardness of the water and select the appropriate gallon setting for your model. at 6lbs salt/CF .75 CF Total Hardness in Grains per US Gallon... -
Page 4: Introduction
USGPM USGPM Water (Factory Setting) Factory Setting) 19,875 16,500 10,500 8 x 44 0.75 18.1 x 34.7 AQUA I-75 AQUA I-100 26,500 22,000 14,000 10.0 9 x 48 1.00 18.1 x 34.7 39,750 33,000 21,000 12.0 10 x 54 1.50... -
Page 5: Programming
Programming 1. Press ‘ ’ to enter programming. If the system has been inactive, you may have to hold and press ‘ ’ until you hear a beep to unlock the display screen. Press ‘ ’ or ‘ ’ to select which setting to modify. 2. -
Page 6: Manual Regeneration
Program Options Depending on the current option settings, some parameters cannot be viewed or set. Program Mode DESCRIPTION PARAMETER OPTIONS This option controls whether cubic meters or US gallons is used for the volume display and the format REGIONAL METRIC of the day, year, and month. -
Page 7: General Valve Installation
General Valve Installation Water Pressure Minimum 25 PSI Electrical Supply Uninterrupted 115V AC Existing Plumbing Free of any deposits or build-ups inside pipes. Softener Location Locate close to drain and connect according to plumbing codes Bypass Valves Always provide for bypass valve if unit is not equipped with one. -
Page 8: Start-Up Instructions
Start-up Instructions 1. Plug the valve into an approved power source. 2. When power is supplied to the control, the screen will display TIME OF DAY AND DEFAULT GALLON SETTING. If the valve is not in service it will read “CANATURE” while the valve returns to the service position. 3. -
Page 9: Maintenance
Automatic Bypass The regeneration cycle lasts approximately 75 minutes, after which soft water service will be restored. During regeneration, hard water is automatically bypassed for use in the household. Hot water should be used as little as possible during this time to prevent hard water from filling the water heater. This is why automatic regeneration is set for sometime during the night and manual regenerations should be performed when little or no water will be used in the household. - Page 10 Figure 10 Injector Assembly Cleaning the Injector Assembly Sediment, salt and silt will restrict or clog the injector. A clean water supply and pure salt will prevent this from happening. The injector assembly is located on the right side of the control valve. This assembly is easy to clean. Shut off the water supply to your softener and reduce the pressure by opening a cold soft water faucet.
-
Page 11: Power Head Valve Exploded View
Power Head Exploded View See parts listing on next page (12) -
Page 12: Power Head Parts List
Power Head Parts List Item No. Part No. Part Description Quantity 5056136 Screw-ST3.5×13(Hexagon with Washer) 5056014 Bnt65 Back Cover 5010045 Piston Stem Holder 13000426 Screw-ST2.9×13(Large Wafer) 5056139 Washer-3x13 5056005 Main Gear 5056083 Screw-M4x14 5056166 Screw-ST4.2×12(Large Wafer) 5056141 Washer-4x12 13111004 Washer-4x9 5056016 Refill Regulator 5056015... -
Page 13: Control Valve Exploded View
Control Valve Exploded View See parts listing on next page (14) -
Page 14: Control Valve Parts List
Control Valve Parts List I t em N o. P art N o. P art D i scri pt i on Q uant i t y A 01 05056087 S crew -M 5× 12(H exagon) A 02 05056088 S crew -M 5× 16(H exagon w i t h W asher) A 03 05056047 E nd P l ug R et ai ner... -
Page 15: Trouble Shooting
Trouble Shooting Issue Possible Cause Possible Solution A. Unit fails to initiate a 1. No power supply. Check electrical service, fuse, etc. regeneration cycle. 2. Defective circuit board. Replace faulty parts. 3. Power failure. Reset time of day. B. Water is hard. 1. -
Page 16: Guarantee
AquaCliniq guarantees that your new water conditioner is built of quality material and workmanship. When properly installed and maintained, it will give years of trouble free service. Five Year Complete Parts Guarantee: AquaCliniq will replace any part which fails within 60 months from date of manufacture, as indicated by the serial number, provided the failure is due to a defect in material or workmanship.
