Integrated Entertainment System

Auto-Trail Integrated Entertainment System:
Operating Guide (built in FM modulator)
Safety Notice
It is not only illegal, but also highly dangerous for the TV/DVD monitor to
be positioned where it can be viewed by the Driver when the vehicle is in
motion. Please ensure you operate within the law, and more importantly,
do not risk or harm the safety of yourself, your passengers and/or other
road users.
General Notes
Please familiarise yourself with the individual component operating
instructions (monitor, Freeview, DVD) before using this guide.
For viewing both DVD and Freeview ensure that the LCD monitor is turned
ON and not in standby mode (in standby mode the LED is illuminated) by
pressing the button at the bottom right hand corner.
Ensure that the vehicle is not in reverse gear as this will override all
entertainment settings.
Position 3 on the selector dial (C) is not used.
On/Off switch (D) is used to isolate the entire system to eliminate battery
drain when the entertainment system or reversing camera is not in use
(0 = OFF, 1 = ON).
Please Note: this should be in the ON (1) position whilst driving.

Remote Controls

There are three remote controls required to operate the entertainment
system, there are:
Small: Monitor only
Medium: Radio / DVD player
Large (silver): Freeview (must be pointed at box, not monitor)
T H E
' N E X T
G E N E R A T I O N '
DVD Operation
1. Rotate selector dial (C) to position 1 on the control tower.
2. Switch on DVD player using power button or remote control (see
individual operating instructions).
3. Insert disk and press play.
4. Adjust volume and other settings to suit your requirements.
Freeview Operation
Note: Freeview sound requires the Radio/DVD
player to be tuned into the Freeview box, this is
done in the following manner (Note: this is only
required on initial set up or after power failure);
1. Turn on the Radio/DVD player using the
power switch at the top left corner of the unit.
2. Press and hold the 'Select' button until
'DEMO' appears on the display, then release button.
3. Rotate large silver knob anti clockwise
until 'DEMO OFF' appears on the display.
4. Using the round 'Direction Pad' (to the left
of the large silver knob) press the left direction
until 'EXT IN' appears on the display.
5. Now rotate large silver knob clockwise until
'EXT IN' appears on the display.
6. Press 'SRC' button (found on bottom left of the unit)
to store
this information.
7. Pressing the 'SRC' button will alternate between the radio and
Freeview channel.
Television
Booster A
Booster
ON/OFF
switch
Freeview
SYSTEM
ON/OFF
ON/OFF
Switch B
Switch D
DVD/TV
Selector
Control Tower (located either In
PSU locker or wardrobe
dependent on model)
