- Page 1 Infrared Mini high speed dome Operation and Installation Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1. Precaution----------------------------------------------------------------------------------------------------1 2. Performance-----------------------------------------------------------------------------------------2 2.1 PTZ t echnology parameter ------------ -------- -------------- ------------------------------------------ 2.2 Camera parameter----------- ----------------------------------------- - ----------------------------- 2.3 Performance & Feature ----------- -------------------------------------- ----- -------------------------------- Function and instruction ------------------------------------------------------------------------------------4 Auto-run motion ----------- ---------------------- ---------- ---------- ---- -------------------------------4 Camera control... - Page 3 5.8.2 White balance mode ---------- ---------------- ----- -----------------------------------------25 Function setting ------------------------------------------------------------------------------------------26 Preset ------------- --------------- ------- ------- ----------------------------------------------------- Scan -------------- --------------------------------- ------- ---------------------------------------------- Pattern ---------------- --------------------------- --------- --------------------------------------------- 6.4 Tour------------ --------------------- ------- -------------- ------------------------------------------29 Zone ---------------- ---------------------------- ----------------------------------------------------30 6.6 Time running---------------- ---------------------------- ------------------------------------------31 Privacy zone masking...
-
Page 4: Precaution
Precaution 1. Precaution Ø Electrical safety Conform to country and local electrical safety standard when using or installing the product. Ø Transportation The PTZ should be protected against extremes of pressure, vibration and humidity during storage installation and transportation. The infrared PTZ camera is transported by integrated packing. Ø... -
Page 5: Performance
Performance 2. 1 Technology parameter Electrical： Setting: （ ） DC12V 2400/4800/9600/19200bps Power supply Baud rate RS485 （ ） PTZ+IR light 18W Sixteen protocols, including Pelco, Protocol Consumption （ ） PTZ+IR light+Heater 24W Kalatel, Phlips, Diamond, etc. Address setting Decoder Built-in 0-254 Operation: Environmental:... -
Page 6: Performance & Feature
Performance PTZ Performance and Feature The intelligent Pan/tilt was complete new design, compact structure, built-in constant temperature device and rapidly heat dissipation from chip; Infrared LED; Camera rotate flexibly with low noise, wide capture range and certain auto-functions can provide perfect quality of image for customer. Ø... -
Page 7: Function And Instruction
Performance Ø Internal temperature test Set time display ● When the temperature exceeds the limit, the screen will display alarm information. ● When the temperature is under the limit, the PTZ will delay to startup, and when the heat device ●... -
Page 8: Monitor Function
Function Instruction 3. 2 Camera control Ø Magnification control “ ” The user can control Wide/Tele to adjust zoom far and near of the image by keyboard controller to obtain panoramic image or close view that you need. The PTZ support digital zoom and optical zoom. Ø... - Page 9 Function Instruction Ø Scan The operator can prompt set right limit and left limit in advance by keyboard and menu, so as to make the camera repeatedly scanned between right and left limit at setting speed. Ø Pattern Pattern is built-in function in camera; the PTZ can record tracks that are no less than 180s, when running pattern, the PTZ moves repeatedly according to the recorded tracks.
-
Page 10: System Setting
System Setting 4. System setting 4. 1 Basic operation 4. 1. 1 Current-carrying to PTZ and Self-testing The PTZ conducts self-testing after current-carrying , and it rotates slowly until displaying pan origin that is default setting, then moving to tilt origin, the lens is adjusted from far zoom to near zoom, then from near zoom to far zoom, when self-testing is finished, there is relevant system information displaying on the screen, as follow: Soft edition... -
Page 11: Edit Dome Label
System Setting 4. 2 Edit dome label MAIN MENU ’ When using a lot of PTZs systems, in order to identify each PTZ, SYSTEM SETTING ： the systems support title setting. The setting ways as follow CAMERA SETTING FUNCTION SETTING 、... -
Page 12: Display Initial Information
System setting 4. 3 Display initial information MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 、 【 】... -
Page 13: Display Setup
System Setting 4. 4 Display setup MAIN MENU 、 1 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING 9 preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 、 【 】 【 】... -
Page 14: System Motion Control
System setting 4. 5 Systematic motion control SYSTEM SETTING Systematic motion controlling may control a series of canonical mov- EDIT DOME LABEL ement of the PTZ, and play an important role in controlling the PTZ. INITIAL INFO DISPLAY SETUP MOTION 、... -
Page 15: Park Action
System Setting 4. 5. 3 Park action MOTION This setting allows the PTZ to run an appointed action after it enters AUTO FLIP vacancy for a few time (1-240minutes). If default sets as 0, it means not to PROPORTION PAN run this action automatically. -
Page 16: Advance Setting
System setting 4. 5. 6 Advance setting 【 】 【 】 1.Operate joystick and move to ADVANCE SETTING press OPEN MOTION to enter into "advance setting"; AUTO FLIP 【 】 EIS ENABLED Electronic Image Stabilizer function; PROPORTION PAN 【 】 PRESET FREEZE Function of Preset Freeze means during PARK TIME... -
Page 17: Clear And Restart
System Setting 4. 6 Clear and restart MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 、 【 】... -
Page 18: Password Set
System setting 4. 7 Password set MAIN MENU 1. The system enters into the main menu by calling 95 preset or by calling 9 SYSTEM SETTING preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 【 2. Operate the joystick up and down, move the cursor to SYSTEM WINDOW BLANKING 】... -
Page 19: Time Set
System Setting 4. 8 Time set MAIN MENU 1. The system enters into the main menu by calling 95 preset or by calling 9 SYSTEM SETTING preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 【 WINDOW BLANKING 2. Operate the joystick up and down, move the cursor to SYSTEM 】... -
Page 20: Setup Dome Parmeter
System setting 4. 9 Setup Dome parameter MAIN MENU 1.The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 【 】 2.Click the up and down button to move the cursor to SYSTEM SETTING , EXIT and click the right button to enter into the next menu. -
Page 21: Camera Setting
Camera setting 5. Camera setting MAIN MENU 5. 1 Zoom speed SYSTEM SETTING CAMERA SETTING 、 The system enters into the main menu by calling 95 preset or by calling 9 FUNCTION SETTING preset twice within 3 seconds. WINDOW BLANKING EXIT 、... -
Page 22: Digital Zoom Control
Camera setting 5. 2 Digital zoom control MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 、 【 】... -
Page 23: Back Light Compensation
Camera Setting 5. 3 Back light compensation MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling 9 SYSTEM SETTING preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 、 【 】 Operate joystick, move the cursor to CAMERA SETTING to enter WINDOW BLANKING... -
Page 24: Slow Shutter
Camera setting 5. 4 Slow shutter control MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 、 【 】... -
Page 25: Line Sync Control
Camera Setting 5. 5 Line sync control MAIN MENU 、 SYSTEM SETTING The system enters into the main menu by calling 95 preset or by calling CAMERA SETTING 9 preset twice within 3 seconds. FUNCTION SETTING WINDOW BLANKING 、 【 】... -
Page 26: Ir Cut Filter
Camera setting 5. 7 IR cut filter MAIN MENU 、 1 The system enters into the main menu by calling 95 preset or by SYSTEM SETTING calling 9 preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 、 【 】 2 Operate joystick, move the cursor to CAMERA SETTING WINDOW BLANKING... -
Page 27: Advance Setting
Camera Setting 5. 8 Advance setting MAIN MENU 、 The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING 9 preset twice within 3 seconds. CAMERA SETTING FUNCTION SETTING 、 【 】 Operate joystick, move the cursor to CAMERA SETTING to enter WINDOW BLANKING... -
Page 28: White Balance Mode
Camera setting 5. 8. 2 White balance mode MAIN MENU 【 】 、 【 】 、 System supports AUTO indoor mode INDOOR outdoor SYSTEM SETTING 【 】 、 【 】 、 【 】 、 mode OUTDOOR auto track mode single mode CAMERA SETTING 【... -
Page 29: Function Setting
Function setting 6. Function setting 6. 1 Preset MAIN MENU . The system enters into the main menu by calling 95 preset or by calling SYSTEM SETTING “ ” 9 preset twice within 3 seconds. Click each command to enter preset menu CAMERA SETTING according to the order of the left picture. -
Page 30: Scan
Function setting 6. 2 Scan MAIN MENU Scan is that preset two points , then the camera repeatedly scan betw- SYSTEM SETTING een the two points at a stable speed, the same magnification and pan. A do- CAMERA SETTING me has four scan tour. FUNCTION SETTING 、... -
Page 31: Pattern
Function setting 6. 3 Pattern MAIN MENU Pattern is built-in function in camera; the PTZ can record tracks while less SYSTEM SETTING than 180s. (A series of pan/tilt controlling and lens controlling command). CAMERA SETTING A PTZ may set up to 4 pattern tours. FUNCTION SETTING 、... -
Page 32: Tour
Function setting 6. 4 Tour MAIN MENU Tour is the built-in function in the PTZ, it will arrange the presets SYSTEM SETTING CAMERA SETTING into the queue of auto-tour, and can set how long it will park at preset. FUNCTION SETTING Operate auto-tour is a process of incessantly transfer each preset. -
Page 33: Zone
Function setting 6. 5 Zone MAIN MENU A PTZ may be set up to 8 zones; the regional scene can't be overlapped. SYSTEM SETTING 【 】 User can set label for each zone. When setting ZONE LABEL as ON, CAMERA SETTING the PTZ will display zone label as it runs some zone. -
Page 34: Time Running
Function setting 6 . 6 Time running MAIN MENU User can set the time of preset, scan, tour and pattern. SYSTEM SETTING CAMERA SETTING 1.Call 95 preset or call 9 preset twice within 3 seconds to enter into the main FUNCTION SETTING menu. -
Page 35: Privacy Zone Masking
Privacy zone masking 7. Privacy zone masking MAIN MENU Privacy function can show someone piece of regional shielding while SYSTEM SETTING protecting. For example, protect the window of bedroom or ATM of bank. A CAMERA SETTING PTZ can set up to 24 privacy windows.(Masking setting function is relat- FUNCTION SETTING ive with the model of camera module. -
Page 36: Appendix
Appendix MAIN MENU 8. Appendix SYSTEM SETTING CAMERA SETTING FUNCTION SETTING 8. 1 Menu Index WINDOW BLANKING EXIT SYSTEM SETTING CAMERA SETTING FUNCTION SETTING WINDOW BLANKING EDIT DOME LABEL ZOOM SPEED HIGH PRESETS WINDOW NUMBER INITIAL INFO DIGITAL ZOOM SCAN DISPLAY SETUP EDIT WINDOW BLC MODE... -
Page 37: Rs485 Bus Basic Knowledge
Appendix 9. Rs485 Bus Basic Knowledge Ø Ø Ω Characteristics of Rs485 Bus The connection of 120 termination resistor: As specified by Rs485 standard, Rs485 Bus is Ω Connection mode for 120 resistance of equipment of half-duplexed data transmission cables with terminal. - Page 38 Appendix Ø Problems in practical connections In such circumstances the factory recommends the usage of RS485 distributor. The distributor can In some circumstances user adopts a star change the star configuration connection to the mode configuration in practical connection. The termination resistors must be connected to the of connection stipulated in the RS485 standards.
-
Page 39: Installation
Warnings 10. Installation 10. 1 Caution Please refer to user manual before installation. Power: DC12 , for actual needs, please refer to label of product. Precise optical and electronic parts inside of product. Avoiding severe press, hard vibration etc non-correct operation methods, which may cause damage to product when transportation and installation. -
Page 40: Lightning Proof And Surge Proof
Warnings Ø Stuff Preparation 10. 3 Lightning Proof and Surge Proof Please select the type of cables based on transmitting distance: This product uses TVS lightning Proof technology, ● Minimum video coaxial cable requirements: can prevent from the damage of the equipment caused by Ω... -
Page 41: Installation Instruction
Installation Introduction 11. Installation instruction ● Structure Introduction The Dome utilizes overall packing, and mainly consists of four parts, connection board cover, Main body cover, Main body , and IR LED lamp cover. Wall bracket Pendant bracket Bracket connection plate Connection plate cover Main body cover Main body... -
Page 42: Wall Mount Installation
Installation Introduction Integrated the DOME and the wall bracket together with 11.1 Wall mount installation 3pcs M4*12 screws contained in the accessory bag, and 11. 1. 1 wall bracket installation make sure the cable is completely embedded in the outlet slot. -
Page 43: Pendant Mount Installation
Installation Introduction 11.2 Pendant mount installation Integrated the DOME and the pendant bracket together with 11. 2. 1 Pendant bracket installation 3pcs M4*12 screws contained in the accessory bag, and make sure the cable is completely embedded in the outlet slot. Use 1. -
Page 44: Installation Instruction
Installation Introduction 11.3 installation instruction 11. 4 Electrification inspection Use 3pcs screws to integrate the dome and the bracket Connect video cable and control cable to the other equipments; connection plate together by turning them 10 degree Electrify DC12V power. clockwise, as shown in the below figure: The PTZ carries on self-checking and executes replacement procedure after power-on. -
Page 45: Maintance Service Terms
Maintenance 12.Maintenance service terms 1. Range of warranty The product will be maintained free for one year. ● The product will be obtained the free maintenance service if the same malfunction appears again within three ● months. Malfunction of products caused by force majeure (such as war, earthquake, lightning strike and so on ), abuse, ●... - Page 46 Infrared Mini high speed dome Operation and installation user manual Version V1.00...
