Page 1: User Manual
5 Megapixel, 360 View IR Mini-Dome LP500-360 User Manual 9.20.2012... -
Page 2: Table Of Contents
Camera Access ........................8 Setup Video Resolution ......................13 Configuration Files Export / Import ..................14 Appendix A: Technical Specifications ..................15 Appendix B: Delete the Existing DC Viewer ................17 Appendix C: Setup Internet Security ..................18 razberi technologies™... -
Page 3: Overview
5 Megapixel CMOS progressive scan sensor provides a high density of pixels to reduce the number of cameras required to cover a wide field of view. The LP500-360 is compatible with the user-friendly razberi™ ServerSwitch NVR for quick plug-and-play installation. -
Page 4: Package Contents
Package Contents Please verify that the package contains the following items listed below. LP500-360 Self-tapping screws Plastic Anchors Security Screw (×3) (×3) (×1) Power Terminal Security Torx Quick Guide Block (x1) All In One Cable (Optional) NOTE: The supplied self-tapping screws are mainly for softer substrate / material installation such as wood. -
Page 5: Connectors
Connectors Please remove the security screws and the cover to reach the connectors. The diagram below shows the LP500-360 connectors and reset button. Connector Definition Remarks Power DC 12V Reserved Power* Power connection Power-1 AC 24V Earth GND Power-2 RJ-45 10/100 Mbps Ethernet / PoE Alarm &... -
Page 6: Cable Definition (Optional)
Line Out Two-way audio transmission / Alarm & Audio I/O ALM_IN – Alarm connection ALM_IN + ALM_OUT – ALM_OUT + DC 12V (+) / AC 24V (+) Power Wires Power connection DC 12V (–) / Black AC 24V (–) razberi technologies™... -
Page 7: Camera Cabling
Use of Category 5 Ethernet cable is recommended for the network connection. Cable length shall not exceed 100 meters. Connect one end of the Ethernet cable to the RJ-45 connector of the LP500-360, and the other end of the cable to the network switch, PC or Razberi ServerSwitch. -
Page 8: System Requirements
System Requirements To access the LP500-360 via web browser, please ensure your PC has a good network connection and meets the minimum requirements as described below. Items System Requirement Minimum : ® 1. Intel Core™ i5-2430M @ 2.4 GHz 2. 4 GB RAM... -
Page 9: Camera Access
Camera Access For initial access to the LP500-360, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Device Search Software Setup Step 1: Double click on the program Device Search.exe. After its window appears, click on the <Device Search>... - Page 10 NOTE: It is strongly advised that administrator’s password be altered for the security concerns. Refer to Full HD Multiple Streams IP Camera Menu Tree for further details. razberi technologies™...
- Page 11 Users can change an LP500-360’s network properties, ex. from static IP to DHCP in the discovered device list: Step 1: In the discovered device list, click on the LP500-360 to change its network properties. On the selected camera, right click “Network Setup.”...
- Page 12 <Finish> to exit the installation process. Step 3: Click on <Finish> to close the DC Viewer installation page. Once the DC Viewer is successfully installed, the LP500-360’s Home page will be able to correctly display as shown below.
- Page 13 Wall Mount Installed Camera Note: Please refer to Full HD Multiple Streams LP500-360 Menu Tree for more button function detail. razberi technologies™...
-
Page 14: Setup Video Resolution
The default value of Video Resolution is: H.264 2592 x 1994 (10 fps) + H.264 720 x 480 (10 fps). For more Video Resolution combination detail, please refer Appendix: Video Resolution. Click on <Save> to confirm the setting. razberi technologies™... -
Page 15: Configuration Files Export / Import
File Download window will come out. Click on <Save> and specify a desired location for saving the configuration file. Upload To copy an existing configuration file to the LP500-360, please first click on <Browse> to select the configuration file, and then click on the <Upload> button for uploading. -
Page 16: Appendix A: Technical Specifications
Photo Relay Output 300V DC / AC Event Notification HTTP / FTP / SMTP Micro SD microSDHC 32GB support Supported Web Browser Internet Explorer (6.0+) / Chrome / Firefox / Safari User Account Password Levels User and Administrator razberi technologies™... - Page 17 Rugged Camera- IP66 Dimension Ø 149 x 45.8 mm (Ø 5.87 x 1.80 in.) Weight 350 g (0.77 lbs) Power Source DC 12V* / AC 24V* / PoE Power Consumption Max. 12W Regulatory CE / FCC / RoHS (*) Optional razberi technologies™...
-
Page 18: Appendix B: Delete The Existing Dc Viewer
Appendix B: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing the LP500-360. Deleting the DC Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. -
Page 19: Appendix C: Setup Internet Security
Step 4: Click on <OK> to accept the settings and close the Security Settings window. Step 5: Click on <OK> to close the Internet Options screen. Step 6: Close the browser window, and restart a new one later to access the LP500-360. razberi... - Page 20 technologies™...
