GasAlertMicro Charger II
Instruction Sheet
Introduction
The GasAlertMicro Charger II ("the charger") charges the GA MicroBatt
rechargeable battery pack. It is expandable to charge up to six units at one
time and can be easily mounted onto a secure surface.
Standard GasAlertMicro Charger II kit includes:
•
GasAlertMicro Charger II unit
•
Universal power adapter
•
Power cord
•
Wall mounting kit
•
Back plate for adding additional units
•
Instruction sheet
Table 1. Order Numbers
Model No. Description
Standard charger kit
GAMIC-C05 *
Standard charger kit with battery pack
GAMIC-C05-K
*
Add suffix (-UK) for United Kingdom mains plug, (-EU) for European mains
*
plug, (-CH) for Switzerland mains plug, (-AU) for Australian mains plug.
D5755/3
iERP: 124281
©
BW Technologies 2006, all rights reserved. Printed in Canada.
All product names are trademarks of their respective companies.
a Safety Information - Read First
⇒
For indoor use only.
⇒
Warning: Substitution of components may impair Intrinsic Safety of the
detector under charge.
⇒
Do not charge the battery pack with any other unapproved charger. Do
not use the charger, change the batteries, or charge the batteries in a
hazardous location. Failure to observe these precautions will impair the
Intrinsic Safety of the detector and can lead to fire and/or explosion.
⇒
Do not expose the charger to electrical shock or severe continuous
mechanical shock.
⇒
Ensure the battery pack is locked in place before operating the
detector.
⇒
If the charger is damaged or parts are missing, contact
BW Technologies by Honeywell immediately.
⇒
To eliminate the risk of electrical shock, unplug the charger whenever
cleaning or other maintenance is required.
⇒
Avoid touching the detector bay contact pins.
⇒
Use only BW approved batteries. Do not use alkaline or other non-
rechargeable batteries with this charger.
⇒
The detector must be deactivated .before charging.
⇒
Do not calibrate the detector during or immediately after charging is
complete.
Table 2. International Symbols
Symbol Meaning
n Approved to both U.S. and Canadian Standards by the CSA
International
a
Caution – risk of danger
dc current

Parts of the GasAlertMicro Charger II

1 Charger module lid
2 Release tabs
3 Detector bay
4 Power port
5 Charger status LED
6 Battery connectors (contact pins)
