Sound Ryder Free Wheelin User Manual

Audio system for helmets, vehicles, desktop
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Free Wheelin and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sound Ryder Free Wheelin

  • Page 1 USER GUIDE...
  • Page 2 FreeWheelin is the world’s most advanced stereo audio system worn on helmets by cyclists, skiers, skaters, construction workers, equestrians and more. It also functions as a high quality speakerphone for vehicle or desktop. Freedom to use your Bluetooth speakers on helmets, in the car, or in the office is really what Bluetooth freedom — or FreeWheelin —...

  • Page 3: Package Contents

    PACKAGE CONTENTS • FreeWheelin Bluetooth amp (1) • FreeWheelin left/right speaker communication pods (2) • 3.5mm audio cable for wired mode (48”) • USB charge cable — Type A USB to 3.5mm plug (36”) • Dual Lock pads — self-adhesive for helmet application (3) •...
  • Page 4 CHARGING FREEWHEELIN 1) Use included USB charge cable 2) Connect USB cable to any open USB port on computer 3) For faster charge connect to USB/AC wall adapter 4) Insert 3.5mm plug into 3.5mm port located at base of FreeWheelin amp (Figure A) 5) LED indicator illuminates red while charging (Figure A) 6) LED indicator shuts off when FreeWheelin is fully charged in about 1.5 hours LED indicator...
  • Page 5 INSTALLING FREEWHEELIN TO HELMET 1) Locate 3 pieces of Dual Lock to be applied to helmet exterior 2) Locate installation point for the FreeWheelin amp along rear of the helmet 3) Apply 1” square Dual Lock at this location and press firmly for 20-30 seconds. Do not apply Dual Lock to the Styrofoam portion Dual Lock of the helmet...
  • Page 6 PAIRING FREEWHEELIN WITH BLUETOOTH DEVICE Note: See Figure A for location of controls used in the following instructions. 1) Make sure FreeWheelin is powered off 2) Prepare your device for Bluetooth pairing mode (do not initiate yet) 3) Locate Multi Function Button (MFB) atop left FreeWheelin speaker pod 4) Press and hold FreeWheelin power button —...
  • Page 7 PAIRING NOTES FreeWheelin pairing mode lasts 2 minutes — make sure your Bluetooth device is ready to initiate. If pairing is unsuccessful, repeat steps 1-7. If you have paired many devices with FreeWheelin and experience pairing problems with new devices, you may have reached the maximum number of paired devices.
  • Page 8 USING AUDIO CABLE FOR WIRED CONNECTION 1) Insert 3.5mm audio cable into any audio device having a 3.5mm stereo output/headphone port 2) Insert opposite end of 3.5 audio cable into 3.5mm port located at base of FreeWheelin amp (the charging port is also the audio cable port) 3) FreeWheelin automatically powers ON and LED illuminates (no need to press power button) 4) Play music from audio device 5) Remove cable to automatically power OFF FreeWheelin and save battery power...
  • Page 9 FREEWHEELIN CONTROLS OVERVIEW MULTIFUCTION BUTTON (MFB) • POWER ON • POWER OFF • PLAY • PAUSE • ANSWER CALL • END CALL • REJECT CALL • MICROPHONE FORWARD BUTTON LED INDICATOR • VOLUME UP • NEXT TRACK • BATTERY LEVEL •...

  • Page 10: Playing Music

    PLAYING MUSIC PLAYING MUSIC PLAYING MUSIC PLAYING MUSIC PLAYING MUSIC FUNCTION OPERATION DEVICE STATUS INDICATION FUNCTION FUNCTION OPERATION OPERATION DEVICE STATUS DEVICE STATUS INDICATION INDICATION PLAY SHORT PRESS MFB BUTTON MUSIC PLAYING SHORT AUDIBLE TONE FUNCTION OPERATION DEVICE STATUS INDICATION PLAY PLAY SHORT PRESS MFB BUTTON...
  • Page 11 CHARGING CHARGING LED INDICATOR FREEWHEELIN’ STATUS CHARGING RED LED ON CHARGING LED INDICATOR FREEWHEELIN’ STATUS RED LED OFF DEVICE IS FULLY CHARGED RED LED ON CHARGING RED LED OFF DEVICE IS FULLY CHARGED CHARGING LED INDICATOR FREEWHEELIN’ STATUS PAIRING AND BLUETOOTH RED LED ON CHARGING PAIRING AND BLUETOOTH...
  • Page 12 1) Attach FreeWheelin’ amp and left/right speaker pods to visor clip accessory (Figure B) 2) Use on vehicle visor as shown for hands-free calls while driving (Figure B) 3) Use on desktop as shown for speaker phone and music listening (Figure C) USING VISOR CLIP ACCESSORY FOR VEHICLE OR DESKTOP 1) Attach FreeWheelin amp and left/right speaker pods to visor clip accessory (Figure B) FIGURE B...

  • Page 13: Specifications

    SPECIFICATIONS AUDIO Amp   T ype Class   D AUDIO Amp   T ype Impedance Class   D 4   O hm Output 2W   R MS Impedance 4   O hm Total   H armonic   D istortion 0.50% Output 2W  ...
  • Page 14 HFP   ( Hands   F ree   P rotocol) HSP   ( Head   S et   P rotocol) AVRCP   ( Remote   C ontrol) BLUETOOTH   P AIRING Number   o f   P aired   D evices Passcode 0000 INTEGRATED  ...

  • Page 15: Limited Warranty

    USING AND CHARGING TEMPERATURE Do not use freewheeling in the environment at too high or too low temperature, never expose the mobile phone under strong sunshine or too wet environment. The suitable temperature for the phone and accessories is 0˚C - 40˚C. When charging, please place the FreeWheelin in an environment that has a normal room temperature and good ventilation.
  • Page 16 RF EXPOSURE INFORMATION AND STATEMENT This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 17 NOTES...
  • Page 18 NOTES...
  • Page 19 NOTES...
  • Page 20 SoundRyder™ Audio BST Enterprises, Inc. 17801 South Susana Rd, Rancho Dominguez, CA, 90221 USA...
