Summary of Contents for Ge-Tectronic Fast Mute Sonic XL
- Page 1 Fastmute © SONIC XL Sound Rreproduction to your Car Speaker Instruction Manual ©2009 by ge-tectronic Page: 1...
-
Page 2: Table Of Contents
This includes among other things, incorrect storage, installation, connection or operation. To make a warranty claim, please contact ge-tectronic support. Under no circumstances is damage caused by the installation or use of this device included in warranty, either from the equipment itself or the incorrect installation in the vehicle. -
Page 3: Product Features
At the end of the switch-off delay time, the equipment switches to quiescent mode, to prevent possible battery discharge. For vehicles without a radio, manual switch on/off via the ignition is possible. ©2009 by ge-tectronic Page: 3... -
Page 4: Assembly, Installation And Connection
Picture 2: Insert the supplied DIN-ISO-Adapter between the radio sockets and the vehicle wring harness. If your vehicle does not have ISO connectors, our accessory program can supply suitable auxiliary adapters for your vehicle. ©2009 by ge-tectronic Page: 4... - Page 5 To use this function, you can connect the mute signal with this cable to the radio. (Note: Observe the correct pin connection for the mute signal of the radio. The layout of radio connections can be different from the standard). ©2009 by ge-tectronic Page: 5...
- Page 6 3.5mm connectors can be found in our catalog. Warning: When the integrated Multiprofile-Bluetooth® function is used, only Audio-IN 1 can be used for audio sources. As soon as audio connection 2 is used, then the audio signal from the ©2009 by ge-tectronic Page: 6...
-
Page 7: Operation And Use
For this application, use the loudspeaker connections PIN 17/15 (Right front), PIN 13/11 (Left front), PIN 9/7 (Right rear) and PIN 5/3 (Left rear). 6. Operation and Use a. Function testing after installation Sonic XL After installing the FastMute as described, you can begin to test the functionality. ©2009 by ge-tectronic Page: 7... -
Page 8: Wiring Diagram, Pin Connections, Block Diagram
When the switch-off delay time has expired, then the equipment goes into quiescent mode to avoid draining the battery. Sonic XL Check that the FastMute power indicator switches off after about 40 minutes as programmed. Wiring Diagram, Pin Connections, Block Diagram Picture 6: Connections and Operating Parts Connections ©2009 by ge-tectronic Page: 8... -
Page 9: Technical Data
21: Screened Supply Output 12V/DC for Navi-Charger Socket 22: Ignition/Start (not necessary with Auto Power-Function) 23: Input Supply Power Earth/GND from vehicle supply 24: Input Supply Power 12V/DC from vehicle supply Block Diagram Picture 7: Connection Schematic and Parts 8. Technical Data ©2009 by ge-tectronic Page: 9... -
Page 10: Fault Finding
-Threshold trigger value too low - Increase threshold trigger value happens without an input audio (Turn the potentiometer a little to the signal right) -Noisy audio signal -Check battery of audio source Output delivered only at the front ©2009 by ge-tectronic Page: 10... -
Page 11: Declaration Of Conformity
10. Declaration of Conformity Sonic XL The company ge-tectronic, declares in its sole responsibility that the Product: FastMute which this declaration refers, conforms to the following standards or standardising documents: EMV:... - Page 12 Bluetooth and the Bluetooth logos are trademarks owned by Bluetooth SIG, Inc., U.S.A. and licensed to ge-tectronic Automotive Communication Systems in Germany. Registered trademarks and product names of third party suppliers are recognised as such and are copyright of the respective companies.
