Amytel AW340 Operation Manual

Operation Manual
Walkie Talkie
AW340
TALKING AND LISTENING
Read this manual carefully before use.
Your radio has 20 channels. All radios in your group must be set to
the same channel and CTCSS code in order to communicate.
• For maximum clarity, hold
radios 5 to 7 centimeters
from mouth.
• Press and hold and
speak into the microphone
to transmit.
• To receive messages, release
1. Call Tone Key
• Short press to send a single call
tone
• Long press to send the call tone
maximum 10 times, and returns
to standby mode automatically.
2. PTT Key
• Push to transmit, release to listen
• Pressing has 60 second limit
• In menu mode, push to confirm
selection
3. MENU Key
• Long press to turn radio on or off
• Short press to enter menu mode
-- Press one time to enter MENU mode, press
to select RF channel.
-- Press two times to enter CTCSS Code Setting mode, press
or to set the CTCSS code.
.
or
1
