Summary of Contents for TS-market MAG-1
- Page 1 MAG-1 Digital Recorder OPERATION MANUAL Version: April, 2012 © TS-Market...
-
Page 2: Table Of Contents
Contents Introduction Description and specifications Overlook Recorder’s appearance Technical characteristics Design and operation Operation Voice Activation System Settings Battery charging Storage Transportation Warranty In box... -
Page 3: Introduction
• Before operation read this manual carefully. Description and specifications Overlook MAG-1 digital recorder is designed for high quality audio recording. Recorded files can be downloaded to a PC for further use. The recorder is noted for its small dimensions and weight, long continuous operation, wide dynamic range and high sensitivity of its built-in microphone. -
Page 4: Recorder's Appearance
To extend recording time the recorder employs Voice Activation System (VAS). It also has time and date function. The supplied software allows downloading recorded files (.wav) to a PC and changing the recorder settings through USB port. Recorder’s appearance Microphone Line input Green and red LEDs... -
Page 5: Technical Characteristics
Technical Characteristics Memory capacity, Gb 1; 2 Sampling frequency, kHz 12/24 Bit capacity, bit Recording time, hours (1 Gb built-in memory): - sampling frequency – 12 kHz - sampling frequency – 24 kHz Recording time, hours (2 Gb built-in memory): - sampling frequency –... -
Page 6: Design And Operation
Design and operation Operation Switch the recorder on by moving the switch to position. Switch the recorder on The LED will light up for a few seconds. Color of the LED light will show battery charge level: • green – level of charge is more than 50%, •... - Page 7 Selection of the source of recording If to press TEST button the LED shows the recor- der’s mode of operation: • The LED glows continuously for a few seconds – the recorder is in stand-by mode, the color of the light shows battery’s charge level.
-
Page 8: Voice Activation System
press and hold TEST button till the LED starts blinking (red). Then immediately press REC but- ton – erasing will start and the LED will light continu- ously during operation. When recorded files will be erased, the recorder will switch to stand-by mode. Attention! If during recording the recorder’s memory will be filled up or its battery will be completely dis-... -
Page 9: Battery Charging
• Set quality of recording • Synchronize time and date with a PC See the detailed instructions of software installation in MAG-1 Software manual. Battery charging Turn the recorder on. Connect the recorder to PC’s USB port with a supplied cable. The LED starts blinking. -
Page 10: Storage
Attention! • The recorder must be switched on for charging. • When the battery is fully discharged the recorder does not react to pressing of its buttons, but the battery will be charged when connected to a PC. • If there is long intervals in operation of the recorder the device must be switched off (storage mode). -
Page 11: Warranty
Repairs or replacement of the device in the post- warranty period is to be made according to the additional agreement. In box MAG-1 recorder USB cable Audio cable Software CD User Manual to Contents... - Page 12 Address: TS-Market Ltd. Building 10/1 Sosnovaya Alleya, Zelenograd, Moscow, The Russian Federation, 124489 Tel: +7 (495) 638-88-00 +7 (499) 940-95-75 Cell: +7 (903) 530-10-01 +7 (909) 638-88-00 Fax: +7 (499) 735-04-91 E-mail: support@ts-market.com www.ts-market.com...
