Summary of Contents for B-Tech Quintro +
- Page 1 BETTER BY DESIGN PRO AUDIO VIDEO CONTROL USERS MANUAL...
- Page 2 page intentionally left blank...
-
Page 3: Table Of Contents
SAFETY PRECAUTIONS CONTENTS 1. The ’Quintro+’ Pro Audio Video Control operates within 220-240V INTRODUCTION ....AC / 50Hz. 2. If you have to replace the fuse, you HOW TO CONNECT ..must use a fuse of 250V/ F400 mA / 5 x 20 mm and with the safety Recommended Connections .. -
Page 4: Introduction
THANK YOU, 10 Highest level of audio and video for buying the ’Quintro+’. quality maintained at all times. Now you really can enjoy high quality 11 Elegant design and finish to audio and visual entertainment ‘easily’ compliment other AV equipment. with the unique features of your ’Quintro+’... -
Page 5: Recommended Connections
AUX INPUT CONNECTING A SECOND VCR The Scart and Phono sockets on the front and back panels of Input A second VCR may be connected to “5 -AUX IN” are parallel, hence, “SCART 2”’. To record video from any any one of these three inputs can other input, select as follows: be used. -
Page 6: Smart Automatic Switching
AUX IN SELECT LOCK (under front cover panel) INPUTS OUTPUTS “QUINTRO+” will automatically switch USING THE “QUINTRO+” to the front panel AUX input and disable SMART AUTO-SWITCHING: the back panel AUX input. 1. Scart connections: If the connection between the TV and the “QUINTRO+”... -
Page 7: Status Led Display Lamps
3. LED Lamp Display: MANUAL SWITCHING All lamps will turn off and on in green, 1. SELECT - red or orange fully automatically to At each press of the “SELECT” show the current video inputs and button, you will cycle through all outputs clear at a glance: inputs in the following order: Round Lamp = Input... -
Page 8: Lock Function
MANUAL SWITCHING (continued) Depending on the setting of the TV2 button, the TV2 lamp 2. LOCK - will change from orange to Depress the LOCK button to lock either red or green. the selected input to “SCART 1” and the “TV2” Phono sockets for uninterrupted recording or watching. -
Page 9: How To Make Two Different Recordings At The Same Time
4. Depress the LOCK key once to turn HOW TO MAKE TWO on the LOCK function to prevent DIFFERENT RECORDINGS recording from interruption. All AT THE SAME TIME: lamps will change from green to orange. 1. Connect the two VCR’s respectively to SCART “1”... -
Page 10: How To Record Between Two Vcr's
HOW TO RECORD BETWEEN TWO QUESTIONS & ANSWERS VCR’s: 1. I cannot release the LOCK 1. Connect two VCR’s respectively to function? “SCART 1” and “SCART 2” sockets. Recording can be done bi- You have to select the locked input directionally between two VCR’s. - Page 11 page intentionally left blank...
- Page 12 B-Tech International Limited, Croydon, CR0 9UG, UK. www.b-tech-int.com...
