- Page 1 ETA-ECS3 Power Sequencer & Conditioner ETA-ECS3 Power Sequencer & Conditioner 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 1 – ETAsys.com Specifications are subject to change without notice.
-
Page 2: Table Of Contents
ETA-ECS3 Power Sequencer & Conditioner TABLE OF CONTENTS Important Safety Instructions ......................... 3 Introduction ............................5 Key Features ............................6 Applications ............................6 Front Panel ............................. 7 Rear Panel .............................. 9 Installation ............................. 10 Troubleshooting ............................ 10 AC Power Cord Retainer System ......................11 Specifications ............................ -
Page 3: Important Safety Instructions
ETA-ECS3 Power Sequencer & Conditioner IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 WARNING – WHEN THE DEVICE IS IN USE • To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to ETA Systems. • Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the AC outlet and contact ETA Systems. Do not to attempt to continue operation with the product as this may cause fire or electric shock: • Smoke or strange smell coming from the unit. •...
-
Page 5: Introduction
Another factor would be from voltage drops in AC lines due to long transmissions. The ETA-ECS3 will not only inform you if one of these conditions occurs, but under extreme variances in the AC Mains, it will shut the power to the equipment off. -
Page 6: Key Features
APPLICATIONS The ETA-ECS3 was designed to be flexible with features that allow it to be used in a variety of applications. The sequenced outputs allow the turning of equipment on and off in a particular order, to eliminate an in rush of current and audible pops that often occur with non-sequenced power strips. -
Page 7: Front Panel
FRONT PANEL FEATURES Unswitched AC Outlet – The two 120VAC outlets are always live when the ETA-ECS3 power cord is plugged into an AC mains power source and voltage is present. If voltage is present at the outlets, it will be displayed on the AC Mains Meter. Note: The AC mains power switch or sequencer section does not affect the Unswitched AC Outlets. - Page 8 ETA-ECS3. High AC Line Mains – T he Abnormal Voltage LED will flash between 128VAC – 1 32VAC indicating possible damage may occur to equipment due to high AC Mains voltage. The ETA-ECS3 outlets will remain active but the LED will stay flashing even if the voltage returns to a normal operating range. To stop the LED from flashing the system activation switch must be cycled “Off”.
-
Page 9: Rear Panel
Digital and Analog components. The total maximum continuous draw for this sequential section is 10A and the total current draw for the ETA-ECS3 is 15A. Note: It does not harm high current audio components to be connected to the Sequential Section 1 digital filter outlets. -
Page 10: Installation
ETA-ECS3 Power Sequencer & Conditioner INSTALLATION Before installing we strongly suggest you read the entire manual to ensure you benefit from all the features of the ETA-ECS3. The ETA-ECS3 can be placed on a shelf or rack mounted in a standard 19" width rack. Placement within a rack is not critical but the rack should be within 6' of dedicated 15A AC outlet. Always make sure the 15A outlet is properly inspected by a certified electrician prior to connecting the ETA-ECS3. Below are a few installation tips. • After plugging the ETA-ECS3 into a 15A AC Mains outlet inspect the Wiring Fault LED for illumination. The LED should not be on. • Inspect the equipment that is to be plugged into the ETA-ECS3 to ensure it does not exceed 15A total amperage draw. • Divide the equipment into three categories. Pick the outlets that match the outlets equipment use. -
Page 11: Ac Power Cord Retainer System
Power Sequencer & Conditioner AC POWER CORD RETAINER SYSTEM Your ETA Systems product comes with an AC Mains Power Cord Retainer System. This system prevents the power cord from being removed without the use of a screwdriver. Follow these steps for installation. -
Page 12: Specifications
ETA-ECS3 Power Sequencer & Conditioner SPECIFICATIONS Type Power Sequencer, Power Conditioner & Suppressor Sequencer Sections 3, Fixed Time of 3 Seconds Between “On” Seq. 2 & 3, “Off” 2 & 1 Load Rating 15A Continuous Safety Listing ETL (UL 60065 Standard) Front Panel AC Outlets 2 Unswitched Lights 1 Pull out LED with Dimmer Switch Activation Switch Momentary Circuit Breaker 15A Resettable AC Mains Voltmeter... - Page 13 ETA-ECS3 Power Sequencer & Conditioner NOTES: 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 13 – ETAsys.com Specifications are subject to change without notice.
- Page 14 ETA-ECS3 Power Sequencer & Conditioner NOTES: 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 14 – ETAsys.com Specifications are subject to change without notice.
- Page 15 ETA-ECS3 Power Sequencer & Conditioner NOTES: 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 15 – ETAsys.com Specifications are subject to change without notice.
-
Page 16: Warranty
This warranty shall extend from the date of purchase for a period of one year. Additionally, fuses and lamps carry no warranty. ETA Systems will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
