Installation Procedures
B7 Rear View Camera
Installation Guide
This tutorial is provided as a courtesy by ECS Tuning.
Proper service and repair procedures are vital to the safe, reliable operation of all motor
vehicles as well as the personal safety of those performing the repairs. Standard safety
procedures and precautions (including use of safety goggles and proper tools and equipment)
should be followed at all times to eliminate the possibility of personal injury or improper
service which could damage the vehicle or compromise its safety.
Although this material has been prepared with the intent to provide reliable information, no
warranty (express or implied) is made as to its accuracy or completeness. Neither is any
liability assumed for loss or damage resulting from reliance on this material. SPECIFICALLY,
NO WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY
OTHER WARRANTY IS MADE OR TO BE IMPLIED WITH RESPECT TO THIS MATERIAL. In
no event will ECS Tuning, Incorporated or its affiliates be liable for any damages, direct or
indirect, consequential or compensatory, arising out of the use of this material.
