TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0
TLT-2K
TLT-2K
GPS/GSM
GPS/GSM
TLT-2K GPS/GSM
TLT-2K
GPS/GSM Car
Instruction
Instruction
Instruction
Instruction Manual
Manual
Manual V3.0
Manual
Shenzhen V-sun Electronics Co. Ltd.
April 1, 2012
1/36
Car
Car
Tracker
Tracker
Car Tracker
Tracker
V3.0
V3.0
V3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLT-2K and is the answer not in the manual?

Questions and answers

Summary of Contents for Shenzhen v-sun Electronics TLT-2K

  • Page 1 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 TLT-2K TLT-2K GPS/GSM GPS/GSM Tracker Tracker TLT-2K TLT-2K GPS/GSM GPS/GSM Car Car Tracker Tracker Instruction Instruction Instruction Instruction Manual Manual Manual Manual V3.0 V3.0 V3.0 V3.0 Shenzhen V-sun Electronics Co. Ltd. April 1, 2012...

  • Page 2: Table Of Contents

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Contents Contents Contents Contents Chapter Chapter Chapter Chapter one one Preface Preface Preface Preface......................................................................................................................3 3 3 3 I. Overview................................4 II. Notice................................4 Chapter Chapter Chapter Chapter Two Two Device Device...
  • Page 3 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 4. Set IP address and port........................... 28 5. Set timing data upload............................29 6. Instruction to upload current position immediately..................30 7. Phone upload..............................30 8. Emergency upload............................30 9. Low voltage upload............................31 10. Historical data upload function........................31 11.

  • Page 4: Chapter One One

    Overview Overview TLT-2K is a perfect combination of GSM and GPS technologies. The advanced technologies of the product in GSM and GPS fields are verified by its accurate dimension and simple appearance. It represents a typical design integrating the communication product and GPS positioning.

  • Page 5: Two Device

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Chapter Device Description Chapter Chapter Chapter Two Two Device Device Device Description Description Description I. I. I. I. Brief Brief Brief Brief Introduction Introduction Introduction Introduction TLT-2KGPS/GSM is a car positioning and tracking device based on GPS technology and GSM/GPRS technology.
  • Page 6 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Code Code Code Code Code Code C/A Code Code Channel Channel 50-channel, 50-channel, omnibearing omnibearing tracking tracking Channel Channel 50-channel, 50-channel, omnibearing omnibearing tracking tracking Position Position accuracy accuracy <2.5m,CEP <2.5m,CEP Position Position accuracy accuracy <2.5m,CEP...
  • Page 7 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Figure 1 3. 3. 3. 3. LED LED status status status status description description description description 3.1 Green LED ---- GPS status indicator Status Description GPS unavailable Quick flash GPS available 3.2 Blue LED ---- GSM status indicator...
  • Page 8 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Figure 2 Pins from Left to Right PIN1 (red): 12V power wire of vehicle to connect positive electrode of vehicle battery; PIN2 (black): ground wire to connect negative electrode of vehicle battery; PIN3 (green): ACC wire to supply power for car ACC;...

  • Page 9: Chapter Chapter Three Three

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 2. Power wire 3. Battery 4. Instruction manual (CD) Chapter Three Initial Model Description Chapter Chapter Chapter Three Three Three Initial Initial Initial Use Use and and Model Model Model Description Description Description After reading brief introduction to the product, you must know how to install the product.
  • Page 10 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Instruction format: 700+user password (4 digits) For example: 7000000 Description: When TLT-2Kreceives the instruction, it will automatically switch to SMS mode. After success, it will return confirmation message “SET MODE OK, CURRENT MODE: SMS P2P”.
  • Page 11 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Chapter Chapter Four Four Application Application Operation Operation Operation in in in in SMS Mode Mode Chapter Chapter Four Four Application Application and and Operation SMS Mode Mode Most instructions operable under both...
  • Page 12 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Time: 16:39:45 BS: 25ee0dff Fix: A ID: 353686009002030 STATE: SMS Note: Note: Note: Note: 1. In case of cold start and GPS is not positioned, invalid message will be returned: GPS UNAVAILABLE, PLEASE TRY AGAIN LATER.
  • Page 13 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Figure Figure Figure 4 4 4 4 Figure You can also input position data into local map software on PDA or navigation device to view the position (as shown in the following graph) Figure 5 3.

  • Page 14: Description

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 For example: 6670000 Instruction format 2: 667+user password+MAP For example: 6670000MAP Instruction format: 667+user password+MAP,WWW,HHH,ZZ For example: 6670000MAP,640,480，15 Description: 1. When the device receives instruction 1, it will immediately read GPS information and return Chinese address information to the sending number.
  • Page 15 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 recommended to be 1-20). 3. Default size of screenshot is 240*320. 5. 5. 5. 5. Instruction Instruction Instruction Instruction to to to to return return return return map map link link link link for...
  • Page 16 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Description: After receiving the instruction, the device will immediately return confirmation information after success: SET BASESTATION OK. Note: 1. X is base station number with value range of [0, 6]. 2. If X is 0, position information contains no base station information.

  • Page 17: Power Off Alarm

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Instruction for incoming call restriction off: 171+user password For example: 1710000 Description: After success to receive instruction for incoming call restriction on (170), TLT-2Kwill return confirmation message: SET UNLIMITED MODE OFF OK. At this time, the device can only receive incoming call from 3 prestored numbers.
  • Page 18 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Note: 1. Default power failure warning is off. 2. If calling status is off, message will be sent to prestored user instead of calling him. Fuel Fuel shutoff shutoff function function 14. Fuel...
  • Page 19 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Round geo-fence takes the set coordinates as center of circle and uses the set semi-diameter to determine fence scope. Square geo-fence uses 4 known latitude and longitude points to determine a square fence.
  • Page 20 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Eddd.ddddd is longitude information with degree as unit, among which ddd.ddddd stands for degree (5 digits after decimal point is maintained and zero cannot be omitted). Ndd.ddddd is latitude information with degree as unit, among which dd.ddddd stands for degree (5 digits after decimal point is maintained and zero cannot be omitted.

  • Page 21: Geo-Fence Function

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Note: (1) After setting is completed, fence is turned on automatically. Now, default fence type is IO, i.e., warning for both outgoing and incoming fence. (2) If calling status is off, message will be sent to prestored user in SMS mode instead of calling him.

  • Page 22: Mileage Statistics Function

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 16. Overspeed Overspeed Overspeed Overspeed alarm alarm alarm alarm Instruction format: #122#user password#X## For example: #122#0000#250## After receiving the instruction, TLT-2Kwill return confirmation message: SET RATE LIMIT:250. Description: 1. X is speed benchmark value, which is an integral number. Its unit is KM/H with defined domain of [0, 999].
  • Page 23 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 30 minutes. The device will return: SET MILEAGE STATISTICS ON OK, REPORT INTERVAL：30 Note: Mileage report data format: +IMEI+Epoch+Mileage+CS++\r\n For example, if the device is IMEI 为 135790246813555, current time is GMT 2011-12-14 12:04:12, current...

  • Page 24: Tow Truck Alert Function

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 18. Tow Tow truck truck truck truck alert alert alert alert function function function function 1>Turn 1>Turn on on truck truck alert: alert: 181 + + + + user user user password password password + + + + TX 1>Turn...
  • Page 25 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 21. ACC detection and movement warning 1>Instruction 1>Instruction 1>Instruction to to to to set movement movement warning warning area: area: 008 + + + + user user user password password password + + + + Rzzz.z Rzzz.z...

  • Page 26: Super Electricity-Saving Mode

    Format: 121+passwork 4 digits For example: 1210000 Description: TLT-2K receives this instruction and then return confirmation message: OPEN VIB MODE. After entering the mode, the device judges whether it enters shutoff mode through vibration sensor. If it does not detect vibration within 5 minutes, the device will enter shutoff mode.
  • Page 27 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 work normally in the event that ACC is ON, and it will enter again into shutoff mode in the event that ACC is OOF. Shutoff Shutoff mode mode upload upload interval interval setting...

  • Page 28: Chapter Chapter Five Five

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 Chapter Five Application Operation GPRS Mode Chapter Chapter Chapter Five Five Five Application Application Application and and Operation Operation Operation GPRS GPRS GPRS Mode Mode Mode in in in in Send “710 + user password” to switch to GPRS mode. In the mode, TLT-2Kcan also pre-store three phone numbers (No.1, No.2 and No.3), a set of TCP/IP server IP address and port number, 4-digit GPRS password and an...
  • Page 29 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 5 5 5 5 ..Set timing timing data data upload upload Set timing timing data data upload upload Timing data upload has the following two modes: traveling car tracking mode and turn-off mode. In accordance with different settings of GPS sampling time and upload quantity, data are intensively uploaded to display real-time trace with more detail in the event of traveling car.
  • Page 30 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 until all complementary data are sent. After After making making three three basic basic settings settings settings as as as as stated stated stated above, above, running running trace trace trace of of of of your...
  • Page 31 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 If working voltage of TLT-2Kis lower than the set value, and the device will operate “instruction to immediately upload current position” and add “LP” auxiliary attribute into data status to show current status. The information will be sent for 3 times with an interval of 1 minute.
  • Page 32 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 as position information mentioned in “instruction to immediately upload current position” and information status is SOTRAGE. 1 1 1 1 1 1 1 1 ..Switch Switch Switch Switch to to to to upload...
  • Page 33 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 1 1 1 1 ..Status Status Status Status and and corresponding corresponding corresponding corresponding signs signs signs signs Status Corresponding signs 666 single request Phone positioning CALL Accept calling...
  • Page 34 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 #122#user password#X## Overspeed alarm setting 120+user password closing vibration control 121+user password opening vibration control 140+user password Closing distance statistics 141+user password+IX Start distance statistics and interval upload setting 142+user password+MX Initial value of distance statistics and zero...

  • Page 35: Change Gprs User Name

    TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 *prestored number*user password*sequence** Change pre-stored number #801#user password#new user name## Change GPRS user name #802#user password#new service password#old Change GPRS service password service password## #803#user password#APN## Set GPRS access point #803#user password#APN#APN user...
  • Page 36 TLT-2K GPS/GSM Car Tracker Instruction Manual V3.0 The following after services are provided in order to serve and satisfy the customers: Ⅰ. Warranty scope: 1. The product may be replaced free of charge within 30 days since purchase in the event that it is ineligible when normal operation (man-made sabotage excluded) and without dismantlement.
