Installing the Batteries

Note: Batteries are small objects. Replacement of batteries must be done by adults.

Console

• Make sure the unit is turned OFF.
• Locate the battery cover on the bottom of the main unit.
• Using a Phillips screwdriver, loosen the screws on the battery
compartment to remove the battery cover.
• Insert 4 C (called LR14 in some countries) alkaline batteries, following
the polarity (+/-) diagram in the battery compartment.
• Replace the battery cover and tighten the screws.

Keyboard

• Locate the battery cover on the bottom of the keyboard.
• Using a Phillips screwdriver, loosen the screws on the battery
compartment to remove the battery cover.
• Insert 4 AA (called LR6 in some countries) alkaline batteries, following
the polarity (+/-) diagram in the battery compartment.
• Replace the battery cover and tighten the screws.
A

Getting Started

Console (A)
Make sure both your TV and your CLICKSTART console are turned off.
Connect the console to the TV by plugging the colored/coloured cables
on the unit into the matching video (yellow) and audio (white) input jacks
on your TV set. Turn on your TV and your CLICKSTART console. Make
sure there is a clear line-of-sight between the console and the keyboard.
Note: Older TVs without video/audio inputs may require an additional adapter, not
available from LeapFrog.
For TVs with a single audio input:
Connect the yellow connector to the yellow video input jack on the TV.
Connect the white connector to the audio input jack on the TV.
For TVs with no audio/video input
(usually outside of North America)
Connect the included SCART connector or Euro-connector to the SCART
input on the TV. Plug the colored/coloured cables on the unit into the
matching video (yellow) and audio (white) input jacks on the SCART
connector. Set the TV to video mode.
Mouse and Mousepad (B, C)
The mousepad can easily be converted for right- or left-handed
play. To change the position of the mousepad, simply turn the knob
counterclockwise to loosen. Then, lift the mousepad, move it to the other
side and turn the knob clockwise to tighten.
You can store the mouse underneath the keyboard. Simply wrap the cord
around the posts and click the mouse into place.
Note: In order to conserve batteries, the CLICKSTART system will go to sleep after
a period of inactivity. To wake it up again, hit any key on the keyboard or click the
mouse. If that does not work, "reboot" the console by turning it off and then on
again. Moving the mouse will not reawaken the system.
B
2
A
™
:
C
