Jasco AV93299 Instruction Manual

Video converter (rf modulator)
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

AV93299
Video Converter
(RF Modulator)
INSTRUCTION MANUAL
Please read before using this equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV93299 and is the answer not in the manual?

Questions and answers

Summary of Contents for Jasco AV93299

  • Page 1 AV93299 Video Converter (RF Modulator) INSTRUCTION MANUAL Please read before using this equipment.

  • Page 2: Note To Catv System Installer

    NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the build- ing, as close to the point of cable entry as practical.

  • Page 3: Required Parts

    REQUIRED PARTS The following items (not supplied) are required to connect your RF Modulator to a video input source and your TV. • one audio/video shielded cable with three phono connectors at each end, if the video source’s audio output is stereo; or one audio/video shielded cable with two phono connectors at each end if the video source’s audio output is monaural •...

  • Page 4: Operation

    If your TV is already connected to another VHF input source (such as cable, an antenna, or a VCR, for example), disconnect the VHF input source’s 75-ohm cable from the TV’s 75-ohme VHF/UHF terminal, and reconnect it to the RF Modulator’s ANT IN terminal. Then connect a 75-ohm coaxial cable between the TO TV terminal on the RF Modulator and the 75-ohm VHF/UHF terminal on your TV.

  • Page 5: Specifications

    2. Set the RF Modulator’s CHANNEL 3/4 switch to the same channel you set the TV (3 or 4). 3. Turn on the connected video source and set OHMS 75/1K on the RF Modulator to the position that gives the best picture. The video signal indicator on the RF Modulator lights when the modulator is receiving a signal for an A/V source.

  • Page 6: Fcc Warning

    Esta limitada darse justicia, y talvez tiene otro justicias que cambia del estado a estado. Si la unidad resulta defectuosa durante el periodo de garantía, devolverla prepagada a: Jasco Products Co., Inc., 311 N.W. 122nd. Street, Oklahoma City, OK. 73114...
  • Page 7 Distributed for Thomson Consumer Electronics, Inc. by Jasco Products, Co., Inc., 311 N.W. 122nd Street, Oklahoma City, Oklahoma 73114 www.ge-electronics.com...
