MODELS SV 13YA SV 13YB Hitachi Power Tools RANDOM ORBIT SANDER TECHNICAL DATA SV 13YA SV 13YB SERVICE MANUAL LIST Nos. SV 13YA: 0356 Jun. 2005 SV 13YB: 0355 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...
Page 2
REMARK: Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s) is(are) used in the place of company name(s) and model name(s) of our competitor(s). The symbol(s) utilized here is(are) as follows: Competitors Symbols Utilized Company Name Model Name DW423K DEWALT DW421 333VS PORTER CABLE...
The scale of the random sander market is large. With the introduction of two palm-grip random orbit sanders Model SV 13YA (variable speed type) and the Model SV 13YB (single speed type), we fill out our line of sanders and aim to increase sales.
(3) All new design. The large soft grip comfortably fits in the palm of a hand for ease of operation. The Models SV 13YA and SV 13YB have a large soft grip that comfortably fits in the palm of a hand (double molded housing with elastomer).
5. SPECIFICATIONS 5-1. Specifications Item SV 13YA SV 13YB Sanding paper size 125 mm (5") (outer diameter) Sanding pad size 125 mm (5") (outer diameter) 3.2 mm (1/8") Orbital diameter Power source AC single phase AC single phase 50 Hz or 60 Hz...
7. PRECAUTIONS IN SALES PROMOTION In the interest of promoting the safest and most efficient use of the Models SV 13YA and SV 13YB Random Orbit Sanders by all of our customers, it is very important that at the time of sale the salesperson carefully ensures that the buyer seriously recognizes the importance of the contents of the Handling Instructions, and fully understands the meaning of the precautions listed on the nameplate attached to each tool.
The [Bold] numbers in the descriptions below correspond to the numbers in the parts List and the exploded assembly diagram for the Model SV 13YA, and the <Bold> numbers to those in the Parts list and the exploded assembly diagram for the Model SV 13YB.
(2) Wiring the Stator [23] <22> When wiring the Stator [23] <22>, be sure to insert each terminal in correct direction as shown in Fig. 2. At this time, securely insert each terminal as far as it will go. Viewed from the commutator Internal Wire (Blue) [19] <18>...
8-6. No-load Current Value After no-load operation for 30 minutes, the no-load current value should be as follows: Voltage (V) 220 V 110 V 120 V 230 V 240 V SV 13YA Current (A) max. SV 13YB --- 9 ---...
