Summary of Contents for VoIPon AG-188
- Page 1 AG-188 User Manual AG-188N User Manual 1 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 2: Table Of Contents
Account Manage ................28 2.9.1 Syslog Config: ...................28 2.9.2 2.9.3 Time Set:...................29 Logout&Reboot .................29 2.9.4 IVR setting ......................30 Telnet Console ....................31 Introduce ........................31 Global Command......................32 Tree Structure .....................33 2 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 3 How to use speed dial function? ..............38 How to configure digital map? .................38 How to use Call Forward, Call Transfer and 3-way Conference calls? .....38 VLAN implement .....................39 3 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 4: Ag-188N Features
VoIP call come in/out , The default status when pick up the call is VoIP call out Interface Power: Output Power:12VDC,500mA. Port: RJ11 port. Connect to handset or the Lifeline accessory. WAN: RJ45 port. LAN: RJ45 port. 4 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 5: Electricity Characteristic
G.711 u/a; G729 audio Codec SIP RFC3261, RFC 2543 IAX2 TCP/IP: Internet transfer and control protocol RTP: Real-time Transport Protocol RTCP: Real-time Control Protocol VAD/CNG save bandwidth 5 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 6: Compliant Standards
Storage temperature: -30° to 65° C (-22° to 149° F) ● Humidity: 10 to 90% no dew Package Size 128 x 85 x 30 mm Packing List AG-188N gateway Power adaptor (12v, 500mA) Manual CD 6 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 7: Installation
AG-188N setting page. Default username and password is: Administrator: Username: admin password: admin User: Username: guest Username: guest 7 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 8 AG-188 User Manual 8 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 9: Current State
AG-188N has registered the public sip server and IAX2 server. Phone Number shows the public sip server、 the private sip server and the IAX2 server phone numbers. 9 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 10: Network
Notice: If user accesses the gateway through WAN port. He should use the new IP address to access the gateway when the WAN port address was changed. 10 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 11: Lan Config
Register port of public SIP server Register Username: Username of your SIP account (Always the same as the phone number) Register Password: Password of your SIP account. 11 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 12 Server Auto Swap:Please refer to Auto Detect server for detail. Enable Via rport: config the supporting for RFC 3581 SIP(Default Protocol): Setting for the default protocol of SIP 12 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 13: Iax2 Config
IAX(Default Protocol): Set IAX 2 as the default protocol , if not the system will choose SIP as default Enable G.729: Using G.729 speech coding mandatory consultations 13 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 14: Advance
Gateway: Default gateway of lease table DNS: default DNS server of lease table. Notice: This setting won’t take effect unless you save the config and reboot the device 14 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 15: Nat
LAN device port for port mapping. Outside Port: WAN port for port mapping. Click Add to add new port mapping item and Delete to delete current port mapping item. 15 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 16: Net Service
If you need to change telnet port or HTTP port, please use the port greater than 1024, because ports under 1024 is system remain ports. HTTP service if HTTP is set to 0. 16 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 17: Qos Settings
VLAN tag, Tag differentiated for Date and Voice VLAN is distinction VLAN tag, Date untagged for Date VLAN is distinction VLAN tag Please refer to VLAN implement for detail 17 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 18: Advance Sip Settings
User can register two sip servers: public sip server and private sip server. these two sip servers are independent from each other and running in the same time. sip configuration. For how to configure private sip server. Please refer to 18 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 19: Digital Map
8 digits numbers begin with 9 will be sent immediately. Number 911 will be sent will be immediately 99xT4 3 digits numbers begin with 99 with be sent after four seconds. 19 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 20: Call Service Settings
No Answer Time: no answer call forward time setting. Black List: incoming call in these phone numbers will be refused. Limit List: outgoing calls with these phone numbers will be refused 20 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 21: Mmi Filter
MMI filter is used to make access limit to AG-188N Gateway. When MMI filter is enable. Only IP address within the start IP and end IP can access AG-188N gateway. 21 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 22: Audio Settings
VPN IP： After VPN registered successfully, VPN server will give an IP aggress to the terminal . If there is a IP address shown on terminal (except for 0.0.0.0) ,it means your VPN has registered UDP Tunnel 22 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 23 UDPTunnel: use the UDP to visit VPN L2TP: use the L2TP to visit VPN Enable VPN: Enable the VPN server, you must choose UDP or L2TP type in advance 23 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 24: Dial-Peer Settings
AG-188 User Manual 2.6 Dial-Peer Settings Please refer to “how to use dial rule?” for detail. 24 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 25: Config Manage
Notice: clear config in admin mode, all settings restores to factory default; clear config in guest modem, all settings except sip, advance sip restore to factory default. 25 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 26: Update
Put the configure file in the root directory of update serve when finish editing. Current Version: the system will display the current version number 。 26 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 27 Gateway original version is: <<VOIP CONFIG FILE>>Version:1.0000 <GLOBLE CONFIG MODULE> ConfFile Version：6 User may edit the configure file version to: <<VOIP CONFIG FILE>>Version:1.0007 <GLOBLE CONFIG MODULE> ConfFile Version：7 27 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 28: System Manage
MGR Log Level: set the MGR log level SIP Log Level: set the SIP log level IAX2 Log Level: set the IAX2 log level Please click “apply” after setting 28 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 29: Time Set
Logout&Reboot Reboot Gateway, some setting needs to reboot to make it works. Please always save config before reboot, otherwise the setting will return to previous setting. 29 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 30: Ivr Setting
/*change to router mode*/ "#*50192.168.1.117" set WAN port IP address "#*51192.168.1.1" set default gateway IP "#*52202.112.10.37" set dns server "#*53255.255.255.0” set netmask, use 255.255.255.0 if no be set 30 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 31: Telnet Console
There are two types in command parameters: optional and required. “required” parameter use “-” as prefix and “optional” use “_” as prefix. User may type “-” or “_” then press TAB button for complementarily. 31 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 32: Global Command
Command Function Example exit Return to parent-node #exit logout Exit #logout ping Ping command, use to check network, #ping www.google.com write Save setting to flash #write 32 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 33: Tree Structure
Example:#<show>#ip rtp Show TCP packets Stat. Example:#<show>#ip tcp Show UDP packets Stat. Example:#<show>#ip udp memory path: <show># show gateway memory Example:#<show>#memory path: <show># show NAT information Example:#<show>#nat 33 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 34: Network Diagnosis
#show ip arp telnet Telnet to another device #telnet 192.168.1.2 7 Restore to factory default #setdefault clear gateway settings expect network part #setdefault all clear all settings. 34 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 35: Post Mode(Safe Mode)
PC into the network 192.168.1.xx ) Then user can according the guide in post mode to clear the settings or upgrade the firmware. 35 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 36: Faq
Call Mode: support SIP and Lifeline， SIP means the call will use sip protocol， Lifeline means the call will use the PSTN line. 36 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 37 “Prefix Number: *; Length: 1” in the Digital Map. (Refer “How to use AG-188N’s Lifeline Function?”) 179 rule: when you dial 179 , the call with send to 192.168.1.179, suit for LAN application without set up a sip server. 37 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 38: How To Use Speed Dial Function
----Forward Always: Select Always in the Call Forward Field, and Key in the destination phone number in the Forward Number, then any one calls this gateway will be forward to the destination 38 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 39: Vlan Implement
Different implement of VLAN function: 1: if “Data/Voice VLAN differentiated” is undifferentiated. Device will set the same vlan ID for voice and data. As show below 39 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 40 2. if “Data/Voice VLAN differentiated” is Tag differentiated but the DiffServ is disable. Device won’t distinguish the voice, signaling and data stream. It will add the same data vlan id to them. As below: 40 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 41 3. if “Data/Voice VLAN differentiated” is Tag differentiated and diffServ are both enable. Then device will distinguish the voice, signaling and data stream to VLAN ID setting. As below: 41 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 42 If “VLAN ID check” is disable, AG188 will handle the packets even from different vlan ID. Please notice that VLAN ID check is enable in default. 42 / 42 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
