USER MANUAL

17" IP-65 Marine Display

Sunlight Readable LED B/L LCD

(1st Edition 2009)

All information is subject to change without notice.

Approved by

Checked by

Prepared by

Erik

Hank

Jack

Page 1

Table of Contents

Need help?

Do you have a question about the PC MPC-SL17 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marine PC MPC-SL17

Page 1: User Manual
Marine PC MPC-SL17 USER MANUAL 17” IP-65 Marine Display Sunlight Readable LED B/L LCD (1st Edition 2009) All information is subject to change without notice. Approved by Checked by Prepared by Erik Hank Jack Page 1...
Page 2: Record Of Revision
RECORD OF REVISION Version and Date Page Old Description New Description Remark January 2009 Release 1.0 Page 2...
Page 3: Table Of Contents
TABLE OF CONTENT RECORD OF REVISION ......................2 TABLE OF CONTENT......................3 1.0 INTRODUCTION......................8 2.0 CONTROL AND FEATURES..................... 9 3.0 INSTALLATION ......................10 4.0 OSD OPERATION ....................... 16 5.0 TECHNICAL SPECIFICATION ..................28 Page 3...
Page 4: Important Information
EMC conformance All MarinePC equipment and accessories are de signed to the best industry standards for use in the recreational marine environment. The design and manufacture of Marine PC equipment and accessories conform to the appropriate ElectroMagnetic Compatibility (EMC) standards, but correct installation is required to ensure that performance is not compromised.
Page 5: Packing List
Packing List Before installation, please ensure the following items have been shipped: 1 x MPC-SL17 Marine Display 4 x Mounting bracket lugs and 4 stainless steel threaded studs 1 x Power Cable (5000 mm) 1 x VGA Cable (3000 mm) If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
Page 6 This Page Intentionally left Blank. Page 6...
Page 7: Usage Notice
Usage Notice Precautions To maximize the life and safe use of your unit, always be sure to follow the warnings, precautions and maintenance recommendations in this user’s guide. In a Watercraft or Vehicle: The monitor should be visible to the driver only if it is used for navigation, or system control.
Page 8: Introduction
You will soon become familiar with the quality difference in this bright sunlight readable (0.5 to 1,000 nits) monitor. The range of MarinePC Sunlight Viewable Marine Displays has been developed to be used as part of an integrated marine navigation system and/or within an entertainment system.
Page 9: Control And Features
2.0 CONTROL AND FEATURES Your MarinePC Sunlight Viewable Marine Display has the following controls and features: Front View Back View Page 9...
Page 10: Installation
3.0 INSTALLATION It is important that your new display is installed and operated in accordance with the instructions provided in this handbook. Failure to do so could result in poor product performance and may invalidate your warranty. When planning the installation the following points must be considered: •...
Page 11 Mounting holes on the MarinePC MPC-SL17 allow the monitor to be mounted by rear mounted using VESA75 or VESA100 mount PANEL (Flush) MOUNT For installation, there are four tapped mounting holes on the two sides of the unit’s panel. The mounting hardware packet is included with the product accessories in the shipping box.
Page 12 Installing the display 1. Carefully insert the monitor into the aperture, ensuring that your gasket on the rear of the fascia lays flat against the aperture edge. IMPORTANT: The gasket must lay flat against the aperture edge to ensure watertight integrity.
Page 13 4. Connect all cables as required - see “Rear connections” below. Rear connections The rear connectors are: 1. FUSE 2. Power Input 3. DVI-1 Input 4. DVI-2 Input 5. VGA-1 Input 6. VGA-2 Input 7. CVBS-1 Input (Composite Video) for AV input 8.
Page 14 Display location and mounting options Your display can be mounted using the flush mounting kit supplied. MarinePC recommends that you power the unit and select a suitable mounting location prior to installing the display. When planning the display location, the following points should be considered to ensure safe, comfortable and reliable operation: •...
Page 15 Typical Installation Diagram Page 15...
Page 16: Osd Operation
4.0 OSD OPERATION Introduction Your MarinePC Sunlight Viewable display can be controlled using the On Screen Display (OSD) menu and/or the 8 buttons on the front bezel of the unit. The OSD menu enables you to change the way in which your display is set up and is accessed using the Menu button.
Page 17 BRIGHTNESS Key When you press the BRIGHTNESS Key, the screen will show the following image You can press the UP /DOWN Key to do the screen brightness adjustment. When the brightness achieve 50 and keeping pressing “UP” Key, the dimming will keep the brightness at 50.
Page 18 NIGHT MODE KEY When you press the “NIGHT MODE” KEY, the dimming will be down to under 0.5 nit directly. And if you press “BRIGHTNESS” KEY or “VR” knob at this moment, it will not function until you press the “NIGHT MODE” KEY again to release this restriction. When you press “MENU”, “DISP”, “PIP”...
Page 19 PIP KEY 1. Default main screen shows at RGB1 & RGB2 Press “PIP” KEY Figure 1 2. Default main screen stays at DVI1 & DVI2 Press “PIP” KEY Figure 2 3. Default main screen stays at VIDEO 1 Press “PIP” KEY Figure 3_1 4.
Page 20 When you enter the “PIP Port Change” screen, the status bar will remain at “OFF” position if you keep pressing the “DOWN” KEY to the end. At the other hand, the status bar will remain at top item of each menu if you keep pressing the “UP” KEY to the end.
Page 21 RGB1 & 2’s setting screen: RGB Setting Item Description: ・ PHASE――― Horizontal Sampling Phase Adjustment。・ CONTRAST――― Contrast Adjustment。・ H_POSITION―― Horizontal Screen Adjustment。・ V_POSITION―― Vertical Screen Adjustment。・ R_LEVEL――― Red Color level Adjustment。・ G_LEVEL――― Green Color level Adjustment。・...
Page 22 DVI 1 & 2’s setting screen: DVI Setting Item Description: ・ CONTRAST―――Contrast Adjustment。・ R_LEVEL――― Red Color level Adjustment。・ G_LEVEL――― Green Color level Adjustment。・ B_LEVEL――― Blue Color level Adjustment。・ TEMPERATURE――― Color Temperature Adjustment。・ DISP MODE――― FULL――― Full Screen。 EVEN―――...
Page 23 VIDEO 1 & 2 & 3’ setting screen: VIDEO Setting Item Description: ・ CONTRAST――― Contrast Adjustment。・ SHARPNESS――― Horizontal edge sharpness ・ HUE――― Color Adjustment ・ R_LEVEL――― Red Color level Adjustment。・ G_LEVEL――― Green Color level Adjustment。・ B_LEVEL――― Blue Color level Adjustment。・...
Page 24 PIP Sub-menu setting screen: PIP Setting Item Description: ・ PIP_SIZE――― Picture in Picture Screen Size Adjustment。・ CONTRAST――― Contrast Adjustment。・ R_LEVEL――― Red Color level Adjustment 。・ G_LEVEL――― Green Color level Adjustment 。・ B_LEVEL――― Blue Color level Adjustment 。・...
Page 25 OSD setting screen: OSD Setting Item Description: ・ H_POSITION―― Horizontal Screen Adjustment。・ V_POSITION―― Vertical Screen Adjustment。・ TRANSLUCENT――― Screen background color can be adjusted as transparent as you want (total 10 scales)。・ BRIGHTNESS――― Selection between “BRIGHTNESS” key or “VR” Button for brightness adjustment。...
Page 26 SYSTEM RETURN setting screen: You may choose “SYSTEM RETURN” selection item on the OSD Screen to restore all of the parameter setting to factory default value. When you press “UP” or “RIGHT” KEY, the parameter will show “YES” and confirm it. Page 26...
Page 27 “KEY LOCK” Mode Function setting screen: When you press “MENU” and “BRIGHTNESS” KEY simultaneously for 3 seconds, you will enter the “KEY LOCK” mode. At the same time, the screen will show “KEY LOCK” image as below for 5 seconds and then disappear. In the “KEY LOCK”...
Page 28: Technical Specification
-20°C~70°C Designed to meet FCC Class A, Certification Marine standard EN60945 * The brightness is measured under the 25°C ambient temperature before touch attached. Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, ambient temperature will influence the optical measurements.
Page 29 5.2 ME Drawing Page 29...
