Summary of Contents for OCZ Sarbe
- Page 2 OCZ Technology provides a limited one year worldwide warranty on this product. Contact OCZ Technology immediately upon discovery of any defects covered by this warranty. Before sending the product in for repairs, contact OCZ Technology. The product will be repaired or replaced with the same or similar model.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ……………………………………………………………………. 4 System Requirements………………………………………………………… 4 Installation Guide……………………… ……………………………………. 4 Display Key Setup and Management…..………………………………….. 13 OLED Display Key Execution and Exiting………………………………….. 17 Uninstall ………………………………………………………………………... 17 Warnings ……………………………………………………………………… 17 - 3 -... -
Page 4: Introduction
Introduction The OCZ Sabre Keyboard device allows the use of symbols on keys that can be changed by software to match interaction in various applications and states. The OCZ Sabre can handle various such devices in a dynamic and abstract... - Page 5 Plug the OCZ Sabre Keyboard into an open USB port. The Found New Hardware Wizard window may open: 3.2.1 If so, click “Cancel”. - 5 -...
- Page 6 Additionally, the following window may open. 3.2.2 If so, click “Open folder to view files”. The Windows File Explorer opens showing a new USB Mass Storage Drive embedded within the device. NOTE: If no windo w opens, open file explorer, locate the new Removable Disk.
- Page 7 The Sabre Manager Setup Wizard opens: - 7 -...
- Page 8 Click “Next>”. The Sabre Manager License Agreement window opens: Select the “I Agree” radio button and click “Next >” to continue loading the software. - 8 -...
- Page 9 The OLED Manager Select Installation Folder window opens. NOTE: Keep the default installation folder path. - 9 -...
- Page 10 Click “Next >”. The Sabre Manager Installing Sabre Manager window opens: - 10 -...
- Page 11 The OLED Manager Installation Complete window opens: Click “Close”. The OCZ Technology SabreManager icon is placed on the Desktop: The drivers and software are now installed and ready for customization. Double click the Sabre Manager icon. - 11 -...
- Page 12 The OCZ Technology Display Key Manager (Sabre Manager) and a simulated Display Key window opens: OLED Manager Simulated Display Keys - 12 -...
-
Page 13: Display Key Setup And Management
Display Key Setup and Management Introduction The Display Key Manager (DKM) is comprised of a menu bar, three tabs (Configs, Layers and Tasks) and a run button. The Config tab is for future expansion. Layers define an array of nine display keys to defined tasks. Tasks associate images and define actions. - Page 14 and browsing for the image. Image formats must be either bmp or jpg. • Click in the Name column and input the task name. • Click twice in the Action column to reveal a drop down menu and select an action. The following actions are available: “Nothing”...
- Page 15 • The “Next Task” column is used to dynamically change the display key assignment to another task after execution. 4.3.2 Task deletion: Right click on the task image or name then click “Delete”. A window will appear to confirm the action. Layers 4.3.3 Layer Types and creation: There are four layer types:...
- Page 16 • Open the application and dialog window • Right click in the Process column, click “Pick” then click on the application dialog window. NOTE: The “Process” and “Captions” text boxes will automatically populate with the application executable file name and dialog window title.
-
Page 17: Oled Display Key Execution And Exiting
File then Close or click the “X” in the upper right corner of the DKM window. Uninstall Exit the Display Key Manager. Click “start”, “All Programs”, “OCZ Technology”, “Sabre Manager” then “Uninstall Sabre Manager”. Warnings Do not spill liquids on the device. This will void the warranty and could damage the device.
