- Page 1 160109-1 xSender MODEL: DG180-S Wireless Video Sender System LR150 S PLEASE KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERANCE...
-
Page 2: Table Of Contents
DG180-S - Wireless Video Sender System TABLE OF CONTENTS 1. Introduction 2. Unpack Your xSender™ 3. Install The xSender™ Transmitter 4. Install The xSender™ Receiver 5. Using the xSender™ 6. AV Channel Settings 7. Troubleshooting: Picture Problems 8. Troubleshooting: Audio Problems 9. -
Page 3: Introduction
DG180-S - Wireless Video Sender System INTRODUCTION Congratulations on purchasing the xSender™. This product represents state of the art wireless video technology and exceptional value for money. You can now enjoy crisp video and hi-fi stereo sound from your Satellite, Freeview, DVD or VCR in another room in your home. -
Page 4: Unpack Your Xsender
DG180-S - Wireless Video Sender System STEP 1 Unpack your xSender™ All packs are computer weigh checked when packed. However, it is a good idea to check all kit con- tents are present before proceeding with the installation. Magic Eye... -
Page 5: Install The Xsender™ Transmitter
STEP 2 Install the xSender™ Transmitter The DG180-S Transmitter will send the sound and video from a connected source (Satellite, Freeview, DVD, VCR, etc.) to the DG180-S Receiver, located in another room in your home. Insert the DigiConnector™ into the SCART socket Ensure that the A/V Channel switch on the back labelled ‘TV’... - Page 6 DG180-S - Wireless Video Sender System continued... Important Note: Avoid positioning the DG180-S Transmitter near to other wireless devices operating on 2.4GHz. These can include Wireless Routers, Laptops, Games Consoles, DECT Phones or Bluetooth devices. Connect the Power Supply Unit (PSU) to the sock- Connect the Power Supply Unit (PSU) to an avail- et labelled ‘PSU’...
-
Page 7: Install The Xsender™ Receiver
Locate a vacant SCART socket on the back of your Ensure that the A/V Channel switch on the back receiving TV and insert the DigiSender® SCART of the DG180-S Receiver is set to 1. cable. Connect the Power Supply Unit (PSU) to the sock- Connect the Power Supply Unit (PSU) to an avail- et labelled ‘PSU’... -
Page 8: Using The Xsender
To control your source equipment, use its origi- assigned to the SCART socket that you plugged nal remote control i.e. your Satellite remote, the DG180-S Receiver in to. This may be labelled Freeview remote, DVD remote, VCR remote, etc., as SCART, AUX, AV, VIDEO, VCR or while pointing it at the xSender™... -
Page 9: Av Channel Settings
DG180-S - Wireless Video Sender System A/V Channel Settings The xSender™ features 4 Audio/Video Channels. Each of these A/V Channels changes the frequen- cy on which the xSender™ operates and is useful for when other wireless devices are present in your home. -
Page 10: Troubleshooting Picture Problems
DG180-S - Wireless Video Sender System TROUBLESHOOTING Picture Problems Q: What do you see on your second television? The picture is present but I see black or blank screen poor quality POOR RANGE Switch OFF your DigiSender® TRANSMITTER What do you now see at the second TV? 1. - Page 11 DG180-S - Wireless Video Sender System cont... I see a snowstorm effect or I see lines over the picture plain blue screen INTERFERENCE Switch OFF your DigiSender® RECEIVER. Q: What do you now see at the second TV? This indicates one or more elec- trical devices are interfering with the DigiSender®.
-
Page 12: Troubleshooting Audio Problems
DG180-S - Wireless Video Sender System TROUBLESHOOTING Audio Problems 1. Disconnect both the transmitter AND receiver SCART’s. Reconnect the leads ensuring they are pushed into the sockets firmly. I can see the picture but 2. If you are using a home cinema DVD player with surround sound, can’t hear anything. -
Page 13: Troubleshooting
DG180-S - Wireless Video Sender System TROUBLESHOOTING Problems Controlling the Source Equipment If you have any difficulty operating your source equipment remote control in your second room please follow the advice below below: 1) Ensure the IR Emitter is connected to the socket labelled ‘IR’ on the xSender™ Transmitter. -
Page 14: Technical Support
DG180-S - Wireless Video Sender System Technical Support AEI Security & Communications Ltd is dedicated to providing our customers with first class customer care and technical support. We have provided you with 2 methods of obtaining technical advice on this product. -
Page 15: Upgrades & Accessories
DG180-S - Wireless Video Sender System Upgrades & Accessories Additional Receiver - Part DG20RX Aerial Convertor - Part MOD01PIS • Get your Satellite channels to additional • Connect a DigiSender® Receiver to an TV’s in your home! aerial socket on your TV •... -
Page 16: Rear Panel Descriptions
DG180-S - Wireless Video Sender System REAR PANEL DESCRIPTIONS xSender™ Transmitter Figure 6.1 xSender DG180-S Transmitter Page 16 Please read this instruction manual carefully prior to installation... - Page 17 DG180-S - Wireless Video Sender System REAR PANEL DESCRIPTIONS xSender™ Receiver Figure 7.1 xSender DG180-S Receiver Please read this instruction manual carefully prior to installation Page 17...
- Page 18 DG180-S - Wireless Video Sender System Notes Page 18 Please read this instruction manual carefully prior to installation...
- Page 20 AEI Security & Communications Ltd Weslake Industrial Park Rye Harbour Road, Rye East Sussex TN31 7TE United Kingdom xSender and DigiConnector are trademarks of AEI Security & Communications Ltd. DigiSender is a registered trademark of AEI Security & Communications Ltd.
