Diagnostic error codes

Refer to the following diagnostic error codes when using the diagnostic tests. See
"Running tests" on page 52 for the specific type for information about the
Diagnostic programs.
In the following index, X can represent any number.
Diagnostic Error Code
000-000-XXX
BIOS Test Passed
000-002-XXX
BIOS Timeout
000-024-XXX
BIOS Addressing test failure
000-025-XXX
BIOS Checksum Value error
000-026-XXX
FLASH data error
000-027-XXX
BIOS Configuration/Setup error
000-034-XXX
BIOS Buffer Allocation failure
000-035-XXX
BIOS Reset Condition detected
000-036-XXX
BIOS Register error
000-038-XXX
BIOS Extension failure
FRU/Action
No action
1. Flash the system. See "Flash update
procedures" on page 375
2. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. Boot block
3. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. Boot block
3. System board
1. Run Setup
2. Flash the system. See "Flash update
procedures" on page 375
3. Boot block
4. System board
1. Reboot the system
2. Flash the system. See "Flash update
procedures" on page 375
3. Run memory test
4. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. Boot block
3. System board
1. Flash the system. See "Flash update
procedures" on page 375
2. Adapter card
3. System board
