- Page 1 Tau-PCI/32 Tau-PCI/32-Lite Adapters for PCI-bus One or two E1/PCM-30 interfaces, built-in cross connector, up to 32 data links, up to 2048 Kbps User Manual Copyright © 2004-2007 Cronyx Version 1.3, June 2007...
-
Page 2: Table Of Contents
Adapter Installation ....................8 Adapter Check ......................9 Software Installation....................9 Adapter Configuration in Linux ................10 Adapter Configuration in OS FreeBSD..............10 List of E1/PCM-30 Interface Signals ..............11 Arrangement of basic components on Tau-PCI/32 adapters and Tau-PCI/32-Lite: Copyright © 2004-2007 Cronyx... -
Page 3: Specifications
Tau-PCI/32 adapter is a multiplexer/cross-connector with two E1 ports and 32 built- in HDLC controllers. The adapter is installed in a computer with a PCI bus. The Tau-PCI/32-Lite is a light version, has one E1 port and a compact design that allows it to be installed in a Low-Profile PCI. -
Page 4: Key Features
Tau-PCI/32 Adapter, User Manual The Tau-PCI/32 adapter is primarily used in the construction of data transmission networks based on E1 channels, and for the creation of specialized E1 flow processing equipment (telephony, signaling). The adapter delivery set includes operating system drivers that implement the primary operation modes of the adapter, which are enough to construct data transmission networks. -
Page 5: Deliverables
7.5V and the tolerated pulse current of 200A, and small self- capacitance. Interior Design of the Adapter Functionally, the Tau-PCI/32 adapter can be divided into six primary structural parts: A transceiver that simultaneously maintains up to 32 logical channels from E1 timeslots;... - Page 6 Tau-PCI/32 Adapter, User Manual Copyright © 2004-2007 Cronyx...
- Page 7 16, and, on the other hand, interacts with the cross connector using a separate parallel data bus. The CAS maintenance block is not included in the Tau-PCI/32-Lite, because its functionality becomes redundant and unrequested with only one E1 interface available.
-
Page 8: Adapter Installation
Only the basic operation modes needed to construct packet transmission networks are implemented in the supplied drivers. To use the other features of the Tau-PCI/32 adapter, you may have to use the Driver Development Kit (DDK). -
Page 9: Adapter Check
After unpacking, install the driver according to the instructions contained in the readme.txt file. For the latest drivers and other accompanying software, you should visit the Cronyx website. Before you install the software, please read all of the attached documentation carefully. -
Page 10: Adapter Configuration In Linux
/etc/cronyx.conf file has to be edited and the modules – restarted. To set up the Tau-PCI/32 adapter modes, the sconfig utility (which is used for other Cronyx adapters) is used in OS Linux. It is recommended to create a command file, which sets the operation modes for the channels during the OS startup by using the examples supplied in the distribution kit. -
Page 11: List Of E1/Pcm-30 Interface Signals
Adapter Tau-PCI/32, User Manual List of E1/PCM-30 Interface Signals Pin No. in DB-15 Connector Signal Name XMT-a RCV-b XMT-b RCV-a Copyright © 2004-2007 Cronyx... - Page 12 Support Service of KB Cronyx: Telephone: +7 (499) 946-99-90 E-mail: info@cronyx.ru Website: http://www.cronyx.ru ftp://ftp.cronyx.ru KB Cronyx Office and Sales Department: Telephone: +7 (495) 742-17-71 Fax: +7 (495) 742-17-73 E-mail: info@cronyx.ru Prices: http://www.cronyx.ru/price Please send all requests and remarks regarding this manual and the use of the software at info@cronyx.ru...
